Model 01164
Model 01164
User's Instructions
The MMT Wireless Data Transfer
User's Instructions
3700 Sagamore Parkway North
P.O. Box 5729 • Lafayette, IN 47903 USA
Tel: 765.423.1505 • 800.428.7545
Fax: 765.423.4111
E-mail: info@lafayetteinstrument.com
www.lafayetteinstrument.com
Rel. 10.30.07
Fax: 765-423-4111 . www.lafayetteinstrument.com . E-mail:eval@lafayetteinstrument.com
copyright © 2007 by Lafayette Instrument Company, Inc. All Rights Reserved -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMT and is the answer not in the manual?

Questions and answers

Summary of Contents for Lafayette Instrument MMT

  • Page 1 3700 Sagamore Parkway North P.O. Box 5729 • Lafayette, IN 47903 USA Tel: 765.423.1505 • 800.428.7545 Fax: 765.423.4111 E-mail: info@lafayetteinstrument.com www.lafayetteinstrument.com Rel. 10.30.07 Fax: 765-423-4111 . www.lafayetteinstrument.com . E-mail:eval@lafayetteinstrument.com copyright © 2007 by Lafayette Instrument Company, Inc. All Rights Reserved -...

  • Page 2: Minimum System Requirements

    1. You must first open the application you wish to transfer data to (i.e. Microsoft Excel or Access) in order for it to appear as an option in your MMT Data Transfer software. Then, open the MMT Data Transfer software by double-clicking the MMT LI icon on your computer desktop, or through “Start”...
  • Page 3 Model 01164 User’s Instructions 2. Select the way you want the data to be presented (horizontal or vertical). 3. Select the data you would like transferred. Each selection will require a separate cell. Fax: 765-423-4111 . www.lafayetteinstrument.com . E-mail:eval@lafayetteinstrument.com Fax: 765-423-4111 . www.lafayetteinstrument.com . E-mail:eval@lafayetteinstrument.com...
  • Page 4 The MMT Wireless Data Transfer The MMT Wireless Data Transfer 4. Check the box notifying you that all data will be erased from the MMT storage bank. This only erases the data from the hardware device to enable you to store the next set of data. All data will be archived in the folder presented at the bottom of the screen.

  • Page 5: Storing The Data

    Model 01164 User’s Instructions Storing the Data: The MMT can store test data in memory one of two ways, manual or automatic. Manual Store: To manually store data, press the STORE button. This will place the reading on the Main Measurement Screen into storage. A single beep indicates successful storage.
  • Page 6 When the Auto-Store function is activated, data is automatically stored by the MMT after every test. The MMT detects when a new test begins and stores the data for that test. Only the peak force and peak time for each test are stored into the memory.
  • Page 7 With the Auto-Store enabled, there is a possibility that unwanted data may inadvertently be stored. The MMT will store all tests including test trials and force readings from inadvertent pressing of the load cell. If a test requires that only a select number of tests be recorded, the Auto-Store function can be disabled and the tests can be stored manually by pressing the STORE button.

  • Page 8: Downloading The Data

    MMT must be pointed directly at the data transfer box. The MMT can not be more than 12 feet from the data transfer box. If the MMT is more than 12 feet away, errors may result in the data transmission.
  • Page 9 The software then checks the data for validity and reports the checksum back to the MMT. Once the MMT receives the correct checksum, the data registers are cleared. If the correct checksum is not received, the error message is given and the data is not cleared.
  • Page 10 The MMT Wireless Data Transfer The MMT Wireless Data Transfer 4. If the transfer is successful, a dialog box will appear asking you to select a starting position on your spreadsheet application (i.e. Microsoft Excel). You must select a position in said data file before clicking “OK”...
  • Page 11 Students, individuals and private companies may misuse, negligence or abuse, normal wear or call for a credit application. accident. In no event shall Lafayette Instrument be liable for incidental or consequential damages. INTERNATIONAL PAYMENT INFORMA- There are no implied warranties or merchant- TION ability of fitness for a particular use, or of any...
  • Page 12 The MMT Wireless Data Transfer The MMT Wireless Data Transfer Model 01164 User’s Instructions 3700 Sagamore Parkway North P.O. Box 5729 • Lafayette, IN 47903 USA Tel: 765.423.1505 • 800.428.7545 Fax: 765.423.4111 E-mail: eval@lafayetteinstrument.com www.lafayetteinstrument.com Lafayette Instrument Co. Europe 4 Park Road, Sileby, Loughborough, Leics., LE12 7TJ.
