Oil Burner Installation
and Operation Instructions
ALL C2100A SERIES DRYERS
C C O N T E N T S
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Compressor assembly . . . . . . . . . . . . . . . . . . . .4
Air manifold assembly . . . . . . . . . . . . . . . . . . . . .4
Oil pump assembly . . . . . . . . . . . . . . . . . . . . . . .4
Burner test fire . . . . . . . . . . . . . . . . . . . . . . . . . .4
Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Burner literature . . . . . . . . . . . . . . . . . . . . . . . . .61
Division of ffi Corporation
5900 Elmwood Ave. • Indianapolis, IN 46203
© 1999, 1998 ffi Corporation
Printed in USA
C2100AEO-01-2
REVISED 11-24-99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C2100A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Farm Fans C2100A Series

Summary of Contents for Farm Fans C2100A Series

  • Page 1: Table Of Contents

    Oil Burner Installation and Operation Instructions ALL C2100A SERIES DRYERS C C O N T E N T S Specifications ......3 Compressor assembly .

  • Page 3: Specifications

    Specifications Oil Specifications Orifice Pump Burner Diameter Pressure Pressure Pressure oil flow million oil flow Model (inches) (psi) (psi) (psi) (gal/hr) btu/hr (liter/hr) Mjoules minimum 24" 0.039 maximum 25.0 18.0 68.1 2,659 minimum 28" 0.043 maximum 28.0 23.0 87.1 3,397 minimum 10.5 36"...

  • Page 4: Compressor Assembly

    Oil Burner Installation and Operation Instructions to the oil tank. With compressor circuit breaker Compressor Assembly off, turn pump switch ON and check for pressure • Locate the compressor in a clean on outlet gauge. Pressure should read 100 psi. operating area away from the dryer.

  • Page 5: Illustrations

    is achieved when fire color begins to turns from bright orange to purple or blue. The highest firing rate is achieved with the high fire valve wide open. If the fire becomes dark or smoky at maxi- mum rate, reduce the burner valve opening slight- ly.
  • Page 6 contpanel.tif Fig. 3 Control panel airmanassy.tif Fig. 4 Air manifold assembly...
  • Page 7 compassy.tif Fig. 5 Compressor assembly...

  • Page 8: Schematic

    aoburnersc.tif Fig. 6 Air / oil burner schematic...

  • Page 9: Wiring Diagrams

    4b0484a.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 1 of 6.
  • Page 10 4b0484b.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 2 of 6.
  • Page 11 4b0484c.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 3 of 6.
  • Page 12 4b0484d.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 4 of 6.
  • Page 13 4b0484e.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 5 of 6.
  • Page 14 4b0484f.tif Fig. 7 Power circuit - C21AE, 1 Y-D 1 oil burner, page 6 of 6.
  • Page 15 4b0485a.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 1 of 8.
  • Page 16 4b0485b.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 2 of 8.
  • Page 17 4b0485c.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 3 of 8.
  • Page 18 4b0485d.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 4 of 8.
  • Page 19 4b0485e.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 5 of 8.
  • Page 20 4b0485f.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 6 of 8.
  • Page 21 4b0485g.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 7 of 8.
  • Page 22 4b0485h.tif Fig. 8 Power circuit - C21AE, 2 Y-D 2 oil burner, page 8 of 8.

  • Page 23: Parts

    4d0246a.tif 4d0246b.tif Fig. 9 Layout assembly, C2120AE, single burner.
  • Page 24 4d0252a.tif 4d0252b.tif Fig. 10 Layout assembly, C2120AE, dual burner.
  • Page 25 4d0247a.tif Fig. 11 Fuel oil pkg., OBP1, C2125AE, page 1 of 2.
  • Page 26 4d0247b.tif Fig. 11 Fuel oil pkg., OBP1, C2125AE, page 2 of 2.
  • Page 27 4d0253a.tif Fig. 12 Fuel oil pkg., OBP2, C2125AE, page 1 of 2.
  • Page 28 4d0253b.tif Fig. 12 Fuel oil pkg., OBP2, C2125AE, page 2 of 2.
  • Page 29 4d0251a.tif Fig. 13 Layout assembly, C2140 & 30AE, single burner, page 1 of 2.
  • Page 30 4d0251b.tif Fig. 13 Layout assembly, C2140 & 30AE, single burner, page 2 of 2.
  • Page 31 4d0250a.tif Fig. 14 Layout assembly, C2140 & 30AE, dual burners, page 1 of 3.
  • Page 32 4d0250b.tif Fig. 14 Layout assembly, C2140 & 30AE, dual burners, page 2 of 3.
  • Page 33 4d0250b.tif Fig. 14 Layout assembly, C2140 & 30AE, dual burners, page 3 of 3.
  • Page 34 3c0817.tif Fig. 15 Manifold assembly - air compressor, (single / dual burner).
  • Page 35 3d0516a.tif 3d0516b.tif Fig. 16 Compressor assembly - air, fuel oil burner.
  • Page 36 390569a.tif 3d0569b.tif Fig. 17 Pump assembly - fuel oil, 50HZ & 60HZ applications.
  • Page 37 3c0816b.tif 3c0816a.tif Fig. 18 Manifold assembly - fuel oil, (single / dual burners).
  • Page 38 3c0812.tif Fig. 19 Plumbing assembly - burner, (fuel oil burners).
  • Page 39 3d0538.tif Fig. 20 Fuel oil, nozzle/cone assy, 28”, 36” & 39” (fuel oil burners).
  • Page 40 4c0342.tif Fig. 21 Honeywell burner control assembly.
  • Page 41 4c0366a.tif Fig. 22 Power chassis, C2120AE, 25AE, 380 / 415, 1 Y-Delta 1 oil burner, page 1 of 2.
  • Page 42 4c0366b.tif Fig. 22 Power chassis, C2120AE, 25AE, 380 / 415, 1 Y-Delta 1 oil burner, page 2 of 2.
  • Page 43 4c0364a.tif Fig. 23 Power chassis, C2130AE, 40AE, 380 / 415, 2 Y-Delta 2 oil burner, page 1 of 2.
  • Page 44 4c0364b.tif Fig. 23 Power chassis, C2130AE, 40AE, 380 / 415, 2 Y-Delta 2 oil burner, page 2 of 2.
  • Page 45 4d0249a.tif Fig. 24 ASC Control panel, C21AE, page 1 of 3.
  • Page 46 4d0249b.tif Fig. 24 ASC Control panel, C21AE, page 2 of 3.
  • Page 47 4d0249c.tif Fig. 24 ASC Control panel, C21AE, page 3 of 3.
  • Page 48 3c0815a.tif Fig. 25 Burner box assembly, fuel oil, page 1 of 2.
  • Page 49 3c0815b.tif Fig. 25 Burner box assembly, fuel oil, page 2 of 2.
  • Page 50 3d0580a.tif Fig. 26 Fan-heater assembly, 24”, 10hp, fuel oil, page 1 of 3.
  • Page 51 3d0580b.tif Fig. 26 Fan-heater assembly, 24”, 10hp, fuel oil, page 2 of 3.
  • Page 52 3d0580c.tif Fig. 26 Fan-heater assembly, 24”, 10hp, fuel oil, page 3 of 3.
  • Page 53 3d0577a.tif Fig. 27 Heater assembly, 28”, fuel oil, page 1 of 3.
  • Page 54 3d0577b.tif Fig. 27 Heater assembly, 28”, fuel oil, page 2 of 3.
  • Page 55 3d0577c.tif Fig. 27 Heater assembly, 28”, fuel oil, page 3 of 3.
  • Page 56 3d0576a.tif Fig. 28 Heater assembly, 36”, fuel oil, page 1 of 3.
  • Page 57 3d0576b.tif Fig. 28 Heater assembly, 36”, fuel oil, page 2 of 3.
  • Page 58 3d0576c.tif Fig. 28 Heater assembly, 36”, fuel oil, page 3 of 3.
  • Page 59 3d0575a.tif Fig. 29 Heater assembly, 39”, fuel oil, page 1 of 2.
  • Page 60 3d0575b.tif Fig. 29 Heater assembly, 39”, fuel oil, page 2 of 2.

  • Page 61: Burner Literature

    PART NO. 006-1388-5...
  • Page 62 Division of ffi Corporation 5900 Elmwood Ave. • Indianapolis, IN 46203 © 1999,1998 ffi Corporation Printed in USA...
