ADIRONDACK ROCKER
I N ST R U C T I O N S
ASSEMBLY
STEP 1. Place Chair Back on Chair Seat, push back up against notch
on seat. Use (2) 2" screws to attach chair back to chair seat.
CHAIR
SEAT
CHAIR
BACK
2" SCREWS
HARDWARE PACK
Hardware Pack Weight: 6.4 oz.
CHAIR PARTS
• CHAIR BACK
• CHAIR SEAT
• LEFT CHAIR ARM
• RIGHT CHAIR ARM
• SPREADER BAR
• LEFT RUNNER
• RIGHT RUNNER
SUGGESTED TOOLS
• RUBBER MALLET
• PHILLIPS HEAD SCREWDRIVER
• DRILL
(8) 1.5" BARREL BOLTS
(8) BARREL NUTS
(4) 2" SCREWS
(2) PEGS
(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
Advertisement
Summary of Contents for Hatteras Hammocks ADIRONDACK ROCKER HHAC1TQ
- Page 1 HARDWARE PACK Hardware Pack Weight: 6.4 oz. (8) 1.5” BARREL BOLTS ADIRONDACK ROCKER (8) BARREL NUTS I N ST R U C T I O N S (4) 2” SCREWS (2) PEGS (1) ALLEN WRENCH ASSEMBLY STEP 1. Place Chair Back on Chair Seat, push back up against notch (1) SQUARE-HEAD BIT on seat.
- Page 2 ASSEMBLY STEP 2. Place chair on it’s side and use (1) peg, STEP 3. Use (2) 1.5” barrel bolts and (2) barrel STEP 4. Place and secure spreader bar using (1) barrel bolt and (1) barrel nut to attach the nuts to attach right &...
