LTR MTI 801 Operating Instructions

Operating Instructions
MTI 801
(041710_1)
Insulation Resistance Tester

Safety Information

MTI 801 Insulation Resistance Tester is a handheld and battery operated,
Average RMS insulation multimeter capable of testing Insulation, AC or DC
Voltages, Resistance and Continuity.
This manual contains information and warnings that must be followed for
operating the meter safely and maintaining the meter in a safe operating
condition. If the meter is not used in a manner specified in this manual, the
protection provid ed by the meter may be impaired.
This meter complies with UL 61010-1 : 3
rd
No. 61010-1-12:3 Edition,IEC/EN61010-1:2010;Overloadprotection
CAT IV 600V and CAT III 1000V.
TERMS IN THIS MANUAL
A Warning identifies conditions and actions that could pose serious hazards
to the user. A Caution identifies conditions and actions that could cause
damage the meter or the equipment under test.
rd
Edition, CAN / CSA - C22.2
SAFETY INFORMATION
WARNING
Do not expose the meter to rain or moisture in order to reduce the risk of
fire or electric shock.
Observe the proper safety precautions when working with voltages above
30 V ac rms, 42 V ac peak, or 60 Vdc. These voltage levels pose a potential
shockhazardtotheuser.
Inspect test leads, connectors and probes for damaged insulation or exposed
metal before using the meter.
Check the test leads for continuity before use. Do not use if the readings
are high or noisy.
Keep your fingers behind the finger guards of the test leads during
measurement.
Disconnect the test leads from the points before changing functions.
Disconnect circuit power and discharge all high voltage capacitors before
testing resistance.
Always use the proper terminals, switch position, and range for measurements
before connecting the meter to circuit under test.
When servicing the meter, use only specified replacement parts.
Remove test leads from the meter before you open the battery cover.
Donotoperatethemeterwiththebatterycoverremovedorloosened.
Toavoidfalsereadings,whichcouldresultinpossibleelectricshockorpersonal
injury, replace the battery as soon as the low battery indicator appears.
Avoid working alone.
CAUTION
Disconnect the test leads from the points before changing functions.
Disconnect circuit power and discharge all high voltage capacitors before
testing resistance, or continuity.
Always set the meter to the highest range and work downward for an
unknown value in the manual ranging mode.
INTERNATIONAL ELECTRICAL SYMBOLS
