Moosoo MX30 Instruction Manual

Hide thumbs

Advertisement

Table of Contents

INSTRUCTION MANUAL
Every appliance have passed the water test in factory.
It is normal if you found some water leave in appliance. Please feel free to use
it. Use the rapid cleaning program 2-3 times before first household use.
For any questions and malfunctions of the appliance during use, please contact our customer
service email: usa@imoosoo.com
DISHWASHER
MX30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX30 and is the answer not in the manual?

Questions and answers

Related Manuals for Moosoo MX30

Summary of Contents for Moosoo MX30

  • Page 1 DISHWASHER INSTRUCTION MANUAL MX30 Every appliance have passed the water test in factory. It is normal if you found some water leave in appliance. Please feel free to use it. Use the rapid cleaning program 2-3 times before first household use.

  • Page 3: Table Of Contents

    CATALOGUE IMPORTANT SAFEGUARDS PACKAGE LIST & SPECIFICATIONS OVERVIEW INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS DETERGENT AND TABLEWARE MAINTENANCE AND CLEANING MAINTENANCE GUIDE WARRANTY...

  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS ● Read the user manual carefully before using the appliance. Contact customer service if necessary. ● Do not disassemble the appliance by yourself. ● Plug the appliance into a grounded socket. A grounded socket can reduce the current at most when there is a accidental electricity leakage which it can protect the user at most.

  • Page 6: Package List & Specifications

    ● Do not clean the dishwasher with corrosive detergent in case of damaging it. ● Do not use detergents other than exclusive ones for dishwasher. ● Cut the ribbon on the power cord and the water pipe with flat scissors when unpacking the package in case of hurting the pipes and cords.

  • Page 7: Overview

    OVERVIEW Housing Outer door Baseboard The inside top Spray arm Indicating light Filter cup Top spray arm Seal Down sea Distributor Inside door Saucers Basket Cutlery basket Tap seal ring Tap connector Convenient port Convenient port adapter...

  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS 1. The dishwasher can be placed on a flat table or insert into a cabinet 1.1 In a cabinet: Dimension diagram(Unit: mm) Attention: Sink a. The hole holds drain pipe is up to 555 ~ 560 the position of sewage system. Drain pipe b.
  • Page 9 2.1 Injection pipe installation The injection pipe connects to the injection valve of dishwasher and the corner valve of pipe or tap. The injection pipe is supplied with the dishwasher. Attention: Please use the supplied new injection pipe to connect with tap and valve. The old and damaged pipe may cause water leakage.
  • Page 10 2.2.5 Do not twist the drain pipe. 2.2.6 When extending the drain pipe, the extended part of the it should not be over 5 meters in case of affecting the washing results. Placing the dishwasher on the table Ferrule Drain pipe Back of the dishwasher 2.3 Suction pipe installation...
  • Page 11 3. Dishwasher fixation and placement Installation diagram Ventilator at the bottom (550×50 mm) 3.1 Place the dishwasher levelly in 3.2 Adjust the balance of the appliance case of triggering overflowing and by rotating the adjustable electricity leakage. The ventilator screw.(Rotate clockwise to elevate showed in the figure should not be and counterclockwise to lower) placed on the rug.

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS 1. Control panel use 1.1 Icons on the Control panel Water shortage Display Rinse aid Child lock indicator shortage Intense Soft Fast Program Usual Start/Pause Child lock Delay timer Power On/Off Attention: The power indicator light shines when the appliance is plugged in a socket at normal circumstances.
  • Page 13 1.4 Delay start Select this program for a delay start. Steps: Press delay timer for 3 seconds to reset it as "H:00" shows on the screen. 4. The display shows 5. Press the Start/Pause 1. Power on present delay time button to count down with 3 seconds no operating.

  • Page 14: Detergent And Tableware

    DETERGENT AND TABLEWARE 1. Detergent powder/ pod (Dishwasher exclusive) 1.1. Function and amount Use exclusive detergent powder, pod for dishwasher for removing grease and food residues on the tableware. The amount of detergent depends on the actual conditions of tableware. If there are many sets of tableware in the dishwasher and too much dirt on them, the recommended amount of detergent powder is 23 gram.
  • Page 15 3. Bowl basket use Dinner plate Butter plate Knife Serving bowl Oval platter Teacup Salad fork Teaspoon Glasses Dessert bowl Saucer Serving spoon Soup spoon Dinner fork Attention: Do not pile up tableware in case of edges are stacked up to result in blocking water from spray arm.

  • Page 16: Maintenance And Cleaning

    5. Tableware placement • Large residues such as bones, fishbone and vegetable leaves, etc on the tableware should be removed before putting tableware into the dishwasher. • Do not pile up the tableware, place them one by one into each groove. •...
  • Page 17 2. Rinse Clockwise 1. Rinse the filter under tap 2. Rinse the filter cup and 2. After rinsing the filter cup, after removing the dust on filter with water. put it back to the dishwasher it. It is recommended that and turn it clockwise to fix it use soft brush for cleaning until the triangle sign on the...

  • Page 18: Maintenance Guide

    MAINTENANCE GUIDE ● Error code Error code will be displayed in the screen when the dishwasher malfunctions. Error code Possible cause Potential solutions Thermistor short circuit Contact customer service for help Thermistor short circuit Contact customer service for help The appliance can't Do not place the tableware leveled in case they may collect water heat the water resulting in the lack of water which fail heating in the dishwasher.
  • Page 19 Problem Possible cause Potential solutions 1. Tableware is not placed correctly as Refer to the "Tableware placement introductions". they may be stacked up. 2. The washing process has not done yet. Wait for the process to complete. Tableware is still wet 3.
  • Page 20 Problem Possible cause Potential solutions 1. Inappropriate placement of tableware Refer to "Tableware placement introductions". causes them piled up. 2. The selected program is incorrect. Select appropriate program. 3. The detergent is not exclusive dishwasher Use the dishwasher detergent and put correct detergent or the amount of detergent is amount of detergent according to the reference.

  • Page 21: Warranty

    WHAT IS NOT COVERED 1. Under your MOOSOO guarantee, MOOSOO shall not be liable for costs of repair or replace- ment of a product incurred as a result of: Accidental damage, faults caused by negligent use or care, misuse, neglect, careless operation or handling of the MOOSOO appliance which is not in accordance with this MOOSOO Operation Manual.
