Android Car Navigation

User Manual

The use of certain features of these devices depends on your

network service provider's network settings and performance.

In addition, due to the different network service providers,

Table of Contents

Need help?

Do you have a question about the TR2260 and is the answer not in the manual?

Questions and answers

Summary of Contents for tradetec TR2260

Page 1 Android Car Navigation User Manual The use of certain features of these devices depends on your network service provider's network settings and performance. In addition, due to the different network service providers, ...
Page 2: Table Of Contents
And please contact your network service provider for consulting the network functions and availability of this device. This mark indicates that the product used a label which is...
Page 3 Time and Date Setting..............8 1.7 Text Entering..................9 2. Function Operations................10 2.1 Basic Settings.................10 2.1.1 User Defined Home Screen..........10 2.1.2 Setting Wallpaper..............10 2.1.3 Shortcut.................10 2.1.4 Widget..................11 2.2 General.....................11 2.2.1 Steering Wheel..............11 2.2.2 Screen Calibration..............12 2.2.3 Navigation application............13 2.2.4 factory settings..............14 2.3 Navigation..................14...
Page 4: Quick Review
2.8.3 CD Player................40 2.8.4 iPod Play................41 2.8.5 Audio Play................42 2.8.6 Video Playing...............43 2.8.7Picture Browse..............45 2.8.8 Digital TV................48 2.8.9 Analog TV................48 2.9 AUX IN Function................49 2.10 Rear View..................49 2.11 E-mail....................50 2.11.1 Email Setting..............50 2.11.2 Sending E-mail..............53 2.11.3 E-mail input................54 2.12 Message Functions..............55...
Page 5: Panel Function Button
When you plug in the car keys, switch on ACC START Turning On or the car's ACC power, the device will be automatically turned on, displaying the boot animation LOGO. When you take off the key, switch to ACC OFF, or turn...
Page 6: Tips For Using Touch Screen
①Connect other devices by USB socket. USB Socket ②Connecting an external WIFI/3G dongle RESET Reset Button Click reset button to reset system and re-start. Microphone Receive voice from bluetooth telephone call. Remark: All long press means press time at least lasting 3 seconds;...
Page 7: Main Screen
1.4 Main Screen You can use the touch screen operation to use the various functions of the device. This equipment has a total of five main screen, left or right sliding can be switched with each other. Any interface press the HOME physical buttons on the panel to...
Page 8: Time And Date Setting
Then you could click the message and view the content. Indicators on Description Indicators on Description the left the right Network signal Network signal strength New Message USB connection instructions WIFI signal indicator...
Page 9: Text Entering
1.7 Text Entering When edit text, you could use existing method of entering and Android keyboard to edit English, numbers, and symbols etc., such as editing message, searching key words etc. Tip: The display format would be different according to different status and keyboard of the entering, please refer the actual one.
Page 10: Function Operations
Click in the editing area, then the editing menu would appear. According to the input method, input method you want to use the midpoint of the input method menu, you can choose the Android keyboard or install third-party input method.
Page 11: Setting Wallpaper
2.1.2 Setting Wallpaper Click the blank area of main screen> Wallpaper > Wallpaper or Pictures Bank Choose your preferred wallpaper and click to set as wallpaper. 2.1.3 Shortcut Click the blank area of main screen> shortcut > Choose Shortcut Click the shortcut needed.
Page 12: Widget
2.1.4 Widget In application interface, slide to the right page> Widget Long press and then drag the chosen widget to add it in main menu. 2.2 General 2.2.1 Steering Wheel Users could set the steering wheel according to hint. Note: Steering wheel interface is special for cars with buttons, but some cars’...
Page 13 Steering Wheel Interface a. First to click “ ” Start b. Click the buttons as you want. c. Click the corresponding button on the wheel, if the study displays successful, there will be a change on the corresponding color on the main screen.
Page 14: Screen Calibration
2.2.2 Screen Calibration (For resistive screen only) Applications> Settings > General Settings > Touch screen calibration Enter the calibration screen to calibrate the screen interface, please click as close as possible to the cross until a successful calibration, then exit the calibration screen.
Page 15: Factory Settings
> : GO For example 2.2.4 factory settings When the system is unable to work or there is problems after user used the system, it can be restored to the factory settings. Once it’s restored to factory settings, all the third- party software would be deleted, and the current system settings would be lost.
Page 16: Navigation
2.3 Navigation 2.3.1 Navigation Software Installation 1. Copy the application program with suffix name “APK” to SD card or U disk. There are two installation methods:  Click into the document management interface to find SD card or U disk directory and select “APK” application, and click install directly.
Page 17 Application Program Interface Application > Settings > Applications > Application Program Installation Note: Please copy the navigation map software to the system storage memory first, and then install the navigation APK. Steps are as follows: 1) Insert navigation data packets to the SD card or a...
Page 18 Go back to the "/sdcard/" directory, choose the paste command Waiting for the copy is complete (30 minutes approximately /3.5G ) ...
Page 19: Radio
After successful installation required to choose you need to use the navigation application program, association panel on navigation physical keys NAVI and interface of the main navigation application icon ( see 2.2.4navigation options ). 2.4 Radio 2.4.1 RADIO...
Page 20 Icon Button Name Function Description Band Switching Click BAND to switch between mode FM1/FM2 /AM. Search Click to search channel backwards then stop Channel when find clear channel Backwards Search Click to search channel forwards then stop when Channel find strong and clear channel.
Page 21: Rds
Locate and DX Change between locate and DX models. Click enter the EQ setup Audio settings list of radio List of radio stations, according to the storage for the playing frequency point stations Forward tuning Forward tuning radio...
Page 22: Bluetooth Wireless Connection
Click PTY symbol to light up ， RDS radio display type Program When the received RDS station, the corresponding PTY Type information is automatically displayed. Click REG symbol, it will only search the RDS stations with the same national area code (PI 8-bit representation of the Regional high country area code) of the current RDS station.
Page 23: Bluetooth Pairing
2.5.2 Bluetooth pairing The whole information of the Bluetooth interface, the mobile search auto- complete matching (the default passkey: 0000) Matching refers to the mutual recognition process of two Bluetooth devices for the first communication. After the first connection, the subsequent communication connection will automatically pair and not have to pair every time.
Page 24: Bluetooth Phone Book
Bluetooth icon besides the successful connected Bluetooth devices Note: The following operations are performed in the Bluetooth pairing success and connect under the conditions of operation: 2.5.3 Bluetooth Phone Book In the Bluetooth interface, click “...
Page 25 A list of dial-up operation when long names and numbers are used to scroll the display Bluetooth Phone Book Interface Download the phone book Again after the download is complete, click the phone is the...
Page 26: Phone
2.5.4 Phone 2.5.4.1 To achieve the dialing function via Bluetooth In the Bluetooth interface, click “ ”to enter into the Bluetooth Dial interface. Bluetooth phone Dial Records Interface ① Click numbers on the interface, if the input is wrong,...
Page 27 When the mobile When phone is connected with Bluetooth device and there is an incoming call, the interface is divided into two situations: ① In the Bluetooth Application Interface ② In other function interfaces automatically disappear. ...
Page 28: Call Record
2.5.5 Call Record In the Bluetooth interface, click “ ” to enter into bluetooth call history interface. Click for doing dial operation, Call recording interface Remark: When the names and numbers are long, they would be displayed rollingly.
Page 29: The Whole Bluetooth Hardware Settingss
When connected with bluetooth mobile phone, it can operate play/pause/down music function. Bluetooth Music Interface Note: Some kind of mobile phones need to start playing music player for bluetooth music when using bluetooth music function. 2.5.7 The whole Bluetooth hardware settings In Bluetooth interface, enter the Bluetooth settings screen.
Page 30 Automatic answer ...
Page 31: Application
Click to back to main menu. Click to go back to last interface. Back to matching the main interface 2.6 3G Application Applications> Settings > Wireless and Network > Mobile network > Access Points 2.6.1 Allow data roaming Applications>...
Page 32 Use 3G, please 3G module connected to the USB interface, and available to confirm insert a 3G card. a.Enter the system main interface, b. Select the "Settings" to enter the main interface. c. Select "Wireless networks", access to the network selection screen.
Page 33 Select Mobile networks ", enter the mobile network settings of the main interface, e.First make sure the " Data roaming "is selected, if you have no choice, point the" Data roaming "pop-up prompt menu, select" Ok ", f.
Page 34 Access Point Names ", enter the name of the network access point settings to the main interface. Press the "Menu" button on the machine panel, pop-up menu option. ...
Page 35 Select "New APN" new "APN" into the "APN" to set the main interface. j.Select the "Name" set Apn name, "Name" can easily set, input is complete, select "OK" to the end of the name set ...
Page 36 K. Select "APN", enter "the Apn access name in the Chinese mainland of China Unicom's 3G the APN settings for:" 3gnet "in Hong Kong, Macao and Taiwan and foreign, should be consulted local 3G network supplier, enter the correspondingAPN value.
Page 37 "Menu" button on the machine panel, pop-up menu option. Select "Save" to save the settings content, and return to the main interface of Apn settings ...
Page 38 When the following interface pops up, make sure that Step 1 is complete, press Home to return to the main interface, then repeat 1- 15 steps: o.In the Apn the main interface, select New APN network behind the circle, so that it is selected can.
Page 39: Wlan
Back to the main interface, the3G network has opened, the search to the 3G signal, can use3G network. 2.7.1 WLAN You can use the WLAN high-speed Internet access and download. Applications> Settings > Wireless & networks setting...
Page 40 Click on the link to the connectivity of the network If required, enter wireless password, click on the link, as shown below: The first input password to connect successfully, then don't do this, reboot the system will automatically connected to a matching wireless network.
Page 41: 2Wifi Hotspot
Successful connection interface 2.7.2 Wi-Fi Hotspot You can use the Wi-Fi hotspot function for high-speed Internet access and download. ① Insert the 3G Dongle ② Applications> Settings > More > Portable hotspot Then device will send our Wi-Fi signals.
Page 42: Multimedia
Connection and Setting interface 2.8 Multimedia 2.8.1 Equalizer Applications > Equalizer Click equalizer application icon into the equalizer interface. Or click to enter into EQ Setup operation in all audio or video playing interface. Equalizer settings interface is divided into two functions: namely, equalizer and sound field settings function.
Page 43: Dvd Play
Equalizer settings interface Note: In the Normal mode, users can customize effects model through the effect adjuster. ② In a field setting interface the user can freely adjust the bass and loudness of the contrast, the user can also on the front left, front...
Page 44 DVD Play Interface Function details as below: Icon Button Name Function Description Play/Pause When playing, click it to pause. when pause, click it to continue playing. Next Track Click to play the next track or next chapter. Last Track Click to play the last track or next chapter.
Page 45: Cd Player
Random play Options for ON and OFF, ON, switch on the next song, random play mode Channel Switch Click to switch in different languages and audio tracks(need disk support). Subtitle Click to switch subtitle display(need disk support) EQ Setup Click to enter into EQ setup interface.
Page 46: Ipod Play
Next Track At one time to play the next song, press down roll list for tracks Cycle Play Click to set up playback mode Mode Random play Click to set the random playback mode mode Last Track Click to play the last track or next chapter.
Page 47 Icon Button Name Function Description Play/Pau Click to play or pause. Next Track Click to play the next track. Click one time to replay the current track; Click Last Track twice to play the last track. Fast Forward Press to fast forward.
Page 48: Audio Play
Cycle Play Click to set up play modes: sequential play, single cycle, the whole catalog circulation. Mode Click to start random play mode or cancel Random play random play mode Click to play the iPod's song in the form of an Artist artist.
Page 49: Video Playing
Music Play Interface Function details as below: Icon Button Name Function Description Click to play or pause. Play / Pause Next Track play the next track. Last Track play the last track. Cycle Play Click to set up play mode: sequential play, single cycle, the whole catalog circulation.
Page 50 The detail of the button function of video playing interface Icon Button Name Function Explanation Press Pause when play Play/Pause Press Play when pause Forwards Fast Click to forwards fast Backwards Fast Click to backwards fast ...
Page 51: 7Picture Browse
2.8.7Picture Browse Applications > photo Album. Click the symbol under the application menu to enter into picture browse interface, the detail as below. Picture Browse Interface Click back into last content, you can move the picture at random or click to skimming picture right and left.
Page 52 Picture Skimming Interface(Personality display) Click any picture enter into single picture skimming mode, detail as below. To move the picture left and right by one’s hand to view the photo, under the normal states to double-click the photo to change the photo’s size. Click symbol to enter into the skimming mode for all photos.
Page 53 Single Picture Skimming Interface(Other Function Operation) Function Explanation, Icon Icon Name Function Instruction Delete To delete the selected picture. Share Photo sharing Play Slide play Rotate pictures according to your own view Image rotation Zoom in Shrink images...
Page 54: Digital Tv
Note: hot-swappable SD card is prohibited, otherwise it may cause data loss. 2.8.8 Digital TV Application > Digital TV Click analog TV application icon into the digital TV interface The details of digital TV function interface are as below.
Page 55 Icon Name Function Instruction Main Menu Click to back into menu Auto search Automatic search and save Last channel Switch to last channel Next channel Switch to last channel Search previous Click on the search on previous channels...
Page 56: Aux In Function
2.9 AUX IN Function To ensure after video source under the normal state when it works. Application > AUX IN Press screen to come out a hide menu, click to enter into EQ setting interface, it can adjust EQ effects,...
Page 57 2. Click to manual setting, select the type of E-mail account.(For example: POP3、IMAP、Exchange) 3. Set the receiving server, port. etc ...
Page 58 4. Set the outgoing server, port, etc. 5. Establish the new account ...
Page 59 6. Enter E-mail Interface ...
Page 60: Sending E-Mail
2.11.2 Sending E-mail You can give one or more recipients to send mail. You can manually add the recipient and choose from your address book before sending E-mail. Application > E-mail Press the "MENU" panel, open the mail message editing screen 1.It needs to input recipient, click recipient, put in recipient e-...
Page 61: E-Mail Input
2.Click the topic, enter a subject, click the letter input area, enter the desired content. According to the panel "MENU", the pop-up function keys, add an attachment , select the desired option, and insert the required documents 3. Click “...
Page 62 Press the “ ” in “MENU” or use the mouse to slide to the end of inbox and click “ ”. 1.Instruments link the server and download the E-mails, and then save the received E-mails information in the inbox.
Page 63: Message Functions
2.12 Message Functions You can send and receive short messages or MMS which contains multimedia documents. 2.12.1 Compose New Mails Application> information >Messaging Button >New message Enter into the interface of composition, and follows as below. ...
Page 64: E-Mails Reply
1. Input the E-mail receiver 2. Input the words information you want to send. 3. Click “send” and send the E-mails 2.12.2 E-mails reply When you receive new inbox, instructions column will display at the top of the computer and issue the prompts.
Page 65: Applications
2.13 Applications 2.13.1 Weather Application> Weather Interface> long press interface >Widgets > Fancy widgets 4*2 Enter the region selection, in the input box, enter the query you want to determine the area, click the icon to search as shown in the figure: ...
Page 66: Calculator
Search interface 2.13.2 Calculator Application> Calculator There are two display Panel, basic and senior on the calculator, press MENU> senior or basic, or move from left to right, to chance freely in the two panel. ...
Page 67: Electronic Reader
Remark, press MENU> delete the record 2.13.3 Electronic reader According to the user’s requirement to install the electronic reader, users can also install the third party reader software. The system's user manual is placed in the electronic reader.
Page 68: Update System
3.2.3Wait for the upgrade is completed. The system will automatically restart after the upgrade is completed, please don’t Ignition or shut down during the upgrade process. 3.3 Update system 3.3.1. copy "u-boot-skip.bin、uImage、uramdisk.img、 system.img" to the root directory of SD card，and Inserted into the machine SD card slot.
Page 69: Update Dvd
3.3.4 The system will automatically restart after update. (The system will enter the touch screen calibration interface after the restart, please complete it.) 3.3.5、If one or more errors occur，please Ignore and repeat step 2 to step 4. 3.4. Update DVD 3.4.1 Burn "dvdrom.bin"...
Page 70: Trouble Handle
4. Trouble handle When your equipment met troubles, please check the problems as below. Problem Solution See 3G Card is installed correctly ① to make sure the correct and proper 3G terminal ② operator’s SIM card Unable connect to weather launched 3G card data ③...
Page 71 First, please copy the application files with suffix ".APK" to your SD or U disk. And the following are installation methods: Click into the document management interface to find the SD card or U disk directory, and then select the How to install ".APK"...
Page 72: Specification
5.Specification Operating voltage: DC 12V Operating voltage range: 10.8V ~ 16V Maximum operating current: 10A Installation size：167*178*100mm Installation angle: The front and rear inclination is less than 30° FM radio part Frequency range: 87.5-108MHz (Europe) 87.5-107.9MHz (America) 36 stations preset...
Page 73 Mechanical shock protection: 10~200Hz, X/Y/Z:1.0G Power output: 4*45W, impedance 4 Ohm SRN: 70dB Display screen part Screen dimension:7”/6.2” Screen type: TFT Response time: Response =30ms, fall =50ms Pixel: 384,000 Pixels Angular field: Top view =65°, bottom view =40°，Left view =65°, Right view=65°...
