Quick
Installation
Guide
For INFINITY 401
Package Contents
QIG x1
INFINITY401 x1
Power Adapter x1
RJ-45 Cable x1
(12V/2A )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITY 401 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Claro INFINITY 401

  • Page 1 Quick Installation Guide For INFINITY 401 Package Contents QIG x1 INFINITY401 x1 Power Adapter x1 RJ-45 Cable x1 (12V/2A )
  • Page 2: Front Panel & Leds

    Front Panel & LEDs There are Light-Emitting-Diodes (LEDs) located on the front panel to indicate the status information of cable modem. NAME COLOR MODE STATUS TEL on-hook TEL2/TEL1 Green TEL disable Blinking TEL provisioning or off-hook Blinking WPS in paring Blue WPS enabled WPS disabled...
  • Page 3 Rear Panel and Hardware Connection The following describes the proper steps for connecting your cable modem. Please be sure to follow the steps in the sequence outlined below. Failure to do so could result in improper operation or failure of your cable modem. Step 1: Connect a cable by feeding the F-connector on the back of the cable modem.
  • Page 4 3. The Log In page appears. Type the user name (admin) and your password (password) in the respective fields. Configuring Your WAN Connection The DHCP page allows you to activate/deactivate the DHCP server function of the INFINITY 401 , and, if the DHCP server is activated, to see DHCP leases it has provided.
  • Page 5 Check your INFINITY 401 Access Information There is a label pasted to the bottom of INFINITY 401 case. In that label, you can obtain following information. Please note, following label is just an example, each INFINITY 401 has their own label and setting value. Please follow your label information to access and configure INFINITY 401.
  • Page 6: Federal Communication Commission Interference Statement

    Note to CATV Sysrem Installer "The EUT must be bonding the screen of the coaxial cable to the earth at the building entrance per ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.” Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 7: Fcc Statement

    FCC Statement This device complies with Class B Part 15 of the FCC Rules. The device generates, uses and can radiate radio frequency energy and, if not installed and used as instructed, may cause harmful interference to radio communication. Only Coaxial cables are to be used with this device in order to ensure compliance with FCC emissions limits.
