Summary of Contents for TOUGH-WORKS DC-D
- Page 1 DC-D 1200W 50 LITRE DUST EXTRATOR IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines and Operating Instructions before operating MANUAL this product.
- Page 2 DC-D BD4603 TABLE OF CONTENTS TABLE OF CONTENTS ....................SPECIFICATIONS ....................... SAFETY GUIDELINES ....................ELECTRICAL SAFETY ....................PACKAGE CONTENTS ....................KEY PARTS DIAGRAN....................A S S E M B L Y / M O U N T I N G ..................
- Page 3 DC-D BD4603 medications that cause drowsiness. WORK AREA PREPARATION For your own safety, read and understand • Keep work area clean. Cluttered work areas all warnings and operating instructions before invite accidents. using any tool or equipment. • Do not use power tools in dangerous en- vironments.
- Page 4 DC-D the tool is in the “OFF" position before plugging • Never leave tool running unattended. • Know your tool. Learn the tool’s operation, application and specific limitations before using it. CAUTION Think safety! Safety is a combination of operator common sense and alertness at all times when tool is being used.
- Page 5 DC-D BD4603 plug when installing or removing from outlet. • Plug must be plugged into matching outlet Do not connect dust collector to the power source that is properly installed and grounded in until all assembly steps have been completed.
- Page 6 DC-D ELECTRICAL CONNECTIONS All electrical connections must be performed by a qualified electrician. Make sure tool is off and disconnected from power source while motor is mounted, connected, reconnected or anytime wiring is inspected. Motor and wires are installed as shown in wiring schematic (See Figure B).
- Page 7 DC-D BD4603 No. Description Qty. Motor Housing Collection Canister Locking Band Collection Hose Hose Clamps Filter Cartridge Filter Bag Hose Coupler 1 Stackable Hose Adapters 4 Owner's Manual (not shown)
- Page 8 DC-D Motor Housing Locking Band Collection Canister Inlet Hose Clamp Hose Collection Canister Hose Clamp Hose Coupler...
- Page 9 DC-D BD4603 BASIC ASSEMBLY Do not attempt assembly if parts are missing. Call the Customer service line to obtain replacement parts. • Do not operate dust collector until completely assembled. • Do not operate this tool until you have completely read and understood this manual.
- Page 10 DC-D BASIC OPERATIONS Before Starting • Place the dust collector near the dust prod- ucing machine to be used. • There are four hose adapters supplied. Select the hose adapter that best fits the machine outlet and attach it to the hose coupler.
- Page 11 DC-D BD4603 GENERAL MAINTENANCE Make sure the machine is turned off and the cord is disconnected from the power source before servicing and removing/replacing any components on the machine. • Check the dust collector daily for loose connections,damaged wires, worn switch, full collection canister, dirty filter cartridge/ bag and any other unsafe condition.
- Page 12 DC-D BD4603 PROBLEM PROBLEM CAUSE SUGGESTED CORRECTIVE ACTION 1. Low voltage 1. Check power line for proper voltage 2. Open circuit in motor Motor will 2. Inspect all lead connections on motor or loose connections not start for loose or open connection 3.
- Page 13 DC-D BD4603...
- Page 14 DC-D Description Size Q’ty Power cord Cord bush Switch Left guard Lock nut Philips screw M5X25 Philips screw M5X45 Right guard Circle sponge Long sponge Rubber washer Philips screw M5X8 Motor 120V Rubber washer Filter Dust bag Drum lid Philips screw ST5.5X18 3...
- Page 15 DC-D ONE-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : info@toolots.com After the phone：(844) 866-5687...
