CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual Rev 2.3 October 2013
CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BODY GUARD 545 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CME Medical BODY GUARD 545

Summary of Contents for CME Medical BODY GUARD 545

  • Page 1 Operation Manual CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual Rev 2.3 October 2013 CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 2: Table Of Contents

    7.13 Alarms, Alerts and Troubleshooting 30-31 7.14 Review Pump Set Up 7.15 Change Pump Set Up 7.16 Keep Vein Open (KVO) 7.17 MAINTENANCE AND SERVICE APPENDICES 34-44 10.0 INDEX CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 3: Bodyguard Pump Overview

    MediGuard™ protection ensures protocol is appropriate to patients weight  512 Event Log plus detailed patient history (1024 events log is optional)  Ability to output history to PC (printer or file) using BodyComm™ communication software (optional) CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 4: Pump Description And Functions

    Administers bolus dose during PCA regimes (this function is normally performed using the remote bolus cable) b. Activates clinician (CA) bolus when pump in STOP mode. (Can only be activated under code conditions) CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 5 9. DOWN ARROW a. Scrolls down through options on menu screens 10. NUMERICAL KEYS a. Enters numeric parameters during programming b. Enter access code CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 6 Shows direction of fluid flow BODYGUARD PUMP IN CHARGING UNIT Charger display Displays major pump messages and operation values Release handle Push to release the pump from the charging unit CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 7: System Safety Checks

    Level Three authority. Alternatively you can choose to simply limit either the rate or number of boluses delivered over either a 0, 1, 4, or 24 hour period according to local practice. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 8: Symbols And Labels

    The use of single-use disposable components on more than one patient is a biological hazard. Do not reuse single-use disposable components Type CF applied part Date of manufacture Serial number Expiry date of disposable Lot number STERILE Sterilised with Ethylene Oxide CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 9: Intended Use, Warnings, Notes And Precautions

    Other external factors such as varying back pressure, temperature, head height, set usage, fluid restrictions, solution viscosity or combinations of these factors, may re- sult in deviations from the performance data enclosed. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 10  CME Medical will assume no responsibility for incidents which may occur if the product is not used, stored or transported in accordance with the environmental conditions stipulated in this document and on the package labelling.

  • Page 11: Installation And Set-Up (Including Battery Charging And Powering Up)

    WARNING: Voltage present on internal components may cause severe shock or death upon contact. Disconnect the charger from the mains, prior to opening the casing. Only trained service personnel should open the pump cover. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 12 WARNING: Voltage present on internal components may cause severe shock or death upon contact. Disconnect the charger from the mains, prior to opening the casing. Only trained service personnel should open the pump cover. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 13: Operating The Bodyguard Pump

    Press START (to restart the infusion), press and hold INFO (to remove keypad lock), then press and hold STOP until prompted for the access code to return to the main menu. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 14: Setting Up And Modifying Protocols

    You may also ask CME Medical representatives or service personnel to assist with the set up of the pump which can be done prior to delivery.
  • Page 15 Protocol name: Protocol A Bupiv + Fent Then either: 7. Press to accept your new name and return to protocol selection or 8. Press to return to edit mode CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 16 ‘Change Set Up’ using the Level Three access code to ensure other users cannot accidentally programme the pump to deliver above the safe ceiling for your commonly used drugs. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 17 Settings can be changed in ‘Change Set Up’ using the relevant code. CME Medical recommend this is done only by the lead clinical person or your local electronic engineering department. Please see the later section on ‘Change Set Up’ for further information.

  • Page 18: Administration Sets

    NOTE: A kinked/occluded administration set may impair operation of the pump and the accuracy of the infusion. Before operation, verify that the set is not kinked or occluded. BodyGuard sets are manufac- tured from kink resistant tubing. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 19: Loading The Administration Set

    WARNING: The key can only be fitted into the keyway one way. If you are having trouble fitting it do not force it in. Check to ensure you have correctly lined up the tubing with the direction of flow. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 20: Powering Up And Priming A Set

    Increasing the priming rate may cause excessive turbulence in the set on priming and make it difficult to purge all air from the system. CME Medical recommend a priming rate of <425ml/h. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 21: Selecting A Protocol

    Bolus 2ml NOTE: If MediGuard feature is turned on the user is prompted for patients weight. Enter in kilograms then press START. Refer to Appendices for MediGuard set up. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 22: Interpreting Display Screen Whilst Infusing

    Enter and Press OK 3. The pump beeps to confirm acceptance of the change and the new Bupiv + Fent Rate 8 ml rate is confirmed on the display Bolus 2ml CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 23: Bolus Dose Delivery: Patient Controlled/Clinician Activated

    512 event log. Using the information key (see next section). It allows the user to check boluses given vs. attempts in order to check patient’s current regime is sufficient for their pain status. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 24 Volume 2 ml (On completion of bolus delivery the screen reverts to the main menu). 4. In the main menu, scroll to Select Protocol and proceed with set up CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 25 Volume 2 ml Bolus delivery status displays: Once BodyGuard has delivered the CA Bolus the infusion continues running the current protocol. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 26: End Of Infusion And Bag Change

    Start Infusion? 8. To continue the current patient’s infusion, press Bupiv + Fent Rate 8 ml 9. The infusion is now running and the summary screen will display Bolus 2ml CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 27: Using History Functions: Current Patient And 512 Event Log

    Press 3: Chart of bolus delivery during the last 24 hours, hour-by-hour Press 4: Chart of volume (incl. boluses) delivered during the last 24 hours, hour-by-hour 2. Press to return to ‘STOPPED’ screen CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 28 Pressure DELTA: locked out and what the pressure settings and readings Pressure CAP: were at that time. Pressure Baseline: Actual Pressure NOTE: To return to the previous screen, press CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 29: Eliminating Air During Operation

    After an air alarm always check the set for the visible presence of air. If no air is visible exclude the possibility of the set being occluded/pinched/clamped between the pump and the fluid reservoir. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 30: Alarms, Alerts And Troubleshooting

    (This alert alternates with the infusion running screen) 3. The LED will blink red NOTE: Near end of infusion alert commences when there is approximately 5ml volume to be infused (VTBI). CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 31 Infusion stops. has occurred to obtain error message. Record LED blinks red. Error (Number) error code and summary of fault Send for Service and return pump to Service Centre CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 32: Review Pump Set Up

    To use the automatic KVO at the end of a protocol, make sure that the fluid bag contains overfill beyond the volume to be infused. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 33: Maintenance And Service

    Refer to page 11/12, (battery and charging instructions) for further storage information and precautions. SERVICING CME Medical recommends that the BodyGuard pump should be calibrated once a year by a CME Medical Service representative or by your local engineers if they have been trained and certified to carry out this work by CME Medical personnel.

  • Page 34: Appendices

    G. Setting a Protocol Based on Rate when the Bolus is set to Zero H. Setting a Protocol Based on a Combination of Boluses and Basal Rate (or Bolus Only) I. Auto-Bolus Set-Up J. Accessories 43-44 CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 35: Cme Medical Contact Details

    CME Medical UK Limited Kincraig Business Park Kincraig Road Blackpool FY2 0PJ WEBSITE: www.cmemedical.co.uk GENERAL ENQUIRIES EMAIL: info@cmemedical.co.uk SERVICE DEPARMENT EMAIL: service@cmemedical.co.uk PHONE: 01253 894646 FAX NO: 01253 896648 CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 36: Pump Specifications

    Temperature: +18ºC to +45ºC (+59ºF to +113ºF) Humidity: 20% to 90% R.H. at +40ºC, non- condensing Air Pressure 70kPa to 110kPa Administration set Dedicated administration set with anti-siphon valve and key CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 37: Limited Warranty

    Limited Warranty. 0344 Manufacturer: Caesarea Medical Electronics Ltd. European Address: Staufenburgstr. 23 72805 Lichtenstein, Germany Intern. Toll free: +800-323-575-00 Email: sales@cme infusion.com www.cme-infusion.com CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 38: Default Settings And Parameters

    Handset Key Type Maximum pressing time = Min pressing time 0.2 seconds 1.5-5.0 seconds 1.5 seconds Max pressing time 3.0 seconds 0.1-5.0 seconds Min interval 1.0 second Min interval 1.0 seconds CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 39: Pump Accuracy - Start-Up And Trumpet Curves

    Short-term fluctuations in rate accuracy may have clinical impact depending on the shelf-life of the drug being infused and the degree of inter-vascular integration, the clinical effect can- not be determined from the trumpet curves alone. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 40 CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 41: Mediguard Set-Up

    The software will calculate the maximal rate allowed for the specific patient based on his weight (multiplied by the maximal MediGuard rate). The calculated values will be displayed as “drug limit” in programmed accumulation screen and during programme operation. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 42: Setting A Protocol Based On Rate When The Bolus Is Set To Zero

     The bolus delivery can be stopped at any time by pressing CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...

  • Page 43: Accessories

    The range of accessories available for BodyGuard pain management pumps are listed below, for full, up-to-date information of all accessories, codes and pricing, view the CME Medical website or contact CME Medical head office. Contact details can be found on page 35.
  • Page 44 Programme one pump and upload settings to all other pumps. WARNING: Unsafe operation may result from using improper accessories. Use only accessories provid- ed by CME Medical and designed for use with the BodyGuard pump. CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 45 CME Medical. To order additional copies of this manual, or other related manuals, contact CME Medical Head Office, contact details on page 35.

  • Page 46: Index

    Trumpet curves/ flow rate 39-40 History, patient 27 Volume infused/to be infused 5, 27 Infusion rate 16, 22 Warnings 9 Installation and set up 11 Warranty 37 Intended use 9 CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
  • Page 48 Tel: 01253 894646 Kincraig Business Park Kincraig Business Park Fax: 01253 896648 Fax: 01253 896648 Kincraig Road Kincraig Road Email: info@cmemedical.co.uk Email: info@cmemedical.co.uk Blackpool FY2 OPJ Blackpool FY2 OPJ www.cmemedical.co.uk www.cmemedical.co.uk CME Medical BodyGuard™ 545 Epidural Infusion Pump Operation Manual/Rev 2.3/October 2013...
