King Pigeon R10 User Manual

4g wireless industrial router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4G Wireless Industrial Router
Wireless Data
Connectivity for
Industrial
applicatioons
4G Wireless Router
User Manual
Ver 1.0
Date Issued: 2019-11-20
King Pigeon Hi-Tech. Co., Ltd.
www.iot-solution.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R10 and is the answer not in the manual?

Questions and answers

Summary of Contents for King Pigeon R10

  • Page 1 Wireless Data Connectivity for Industrial applicatioons 4G Wireless Industrial Router 4G Wireless Router User Manual Ver 1.0 Date Issued: 2019-11-20 King Pigeon Hi-Tech. Co., Ltd. www.iot-solution.com...

  • Page 2: Table Of Contents

    5.4 VPN Setting..............................28 5.4.1 PPTP..............................28 5.4.2 L2TP..............................29 5.5 LAN Setting..............................30 5.5.1 Basic Setting............................30 5.5.2 IP&MAC Address Binding........................32 5.5.3 DHCP table............................34 5.6 Media Setting..............................34 5.7 Wireless 2.4G..............................34 Page 2 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 3 5.11.7 Password............................57 6. Warranty.................................57 【UPGRADE HISTORY】 DATE FIRMWARE VERSION HARDWARE VERSION DESCRIPTION 2019.11.20 V 1.0 V 1.0 First edition Model List Model Serial Port WAN/LAN WIFI × √ optional √ Page 3 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 4: Description

    Do not use the unit when using GSM/3G/4G equipment is prohibited or might bring disturbance or danger. Interference All wireless equipment might interfere network signals of the unit and influence its performance. 1.4 Standard Packing List (1) Router R10 or R20 X1; Page 4 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 5 (3) 4PIN Serial Terminals x 1(R20) (4) 12V DC Adaptor X1; (5) GSM/3G/4G Antenna X1; (6) 2.4G WIFI Antenna X2; User Manual X1; (7) Wall-mounted snap kit x 2(R20) Page 5 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 6: Main Features

    R20:1*WAN/LAN,3*LAN Type RJ45 Integrated 10/100M,MDI/MDIX ETH0: WAN interface / LAN interface Ethernet ETH1: LAN interface Function ETH2: LAN interface ETH3: LAN interface Protection ESD contact: 8KV, surge: 4KV (10/1000us) Page 6 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 7 WCDMA：B1,B2,B5,B8 Network 4G (AU version) FDD：B1,B2,B3,B4,B5,B7,B8,B28 TDD：B40 WCDMA：B2,B4,B5 4G (A version) FDD：B2,B4,B12 FDD：B4,B13 4G (V version) WCDMA：B1,B3,B8,B18,B19，B26 FDD：B2,B4,B12 4G (J version) TDD: B41 GSM/EDGE：900,1800MHz 4G (CE version) WCDMA：B1,B8 TD-SCDMA：B34,B39 Page 7 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 8 Working -40～85℃,5～95%RH Temperature&Humidity Environment Storage -45～105℃,5～95%RH Temperature&Humidity Enclosure Metal Size R10 90*86*28 mm R20 133*110*28 mm Others IP level IP30 Net Weight R10: 280g R20: 460g Installation Wall-amount/ rail-amount Page 8 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 9: Physical Layout And Installation Diagram

    2. Physical Layout and Installation Diagram 2.1 Unit size 2.2 LED Indicator light LED Indicator light Name Status Description flick Router is running Router stop running VPN connected VPN disconnected Page 9 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 10: Power Input

    2.4 Ethernet Port R10 has 2 Ethernet ports, 1 WAN/LAN port and 1 LAN port; R20 has 4 Ethernet ports, 1 WAN/LAN port and 3 LAN ports; WAN/LAN can be used WAN port in "standard route mode",used LAN in other modes.

  • Page 11: External Antenna Connection

    Antenna WIFI Antenn 2.8 Router GND The router ground wire helps prevent electromagnetic interference. This product should be mounted on a well-grounded device surface such as a metal plate. Page 11 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 12: Installation

    3.2 Rail installation (R10) (R20) 3.3 Buckle installation (R10) (R20) 4. Parameter Configuration The router supports web page configuration. supports IE6.0 or above, Google and Firefox, Linux 2.6 and above, Page 12 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 13: Wired Connection

    Following example is Windows 7 system configuring.Windows system is similar: Step1: Click Start - Control Panel - Network and Sharing Center, then double-click Local Connection Step2: In the "Local Connection Status" window, click Properties. Page 13 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 14 Step3: Select "Internet Protocol Version 4 (TCP/IPv4)" and click "Properties". Step4: Two ways to configure the IP address Obtain an IP address automatically from the DHCP server and click "Obtain an IP address automatically"; Page 14 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 15 4G Wireless Industrial Router Wireless Data Connectivity Manually configure the PC with a static IP address on the same subnet as the router address, click and configure "Use the following IP address". Page 15 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 16: Wifi Connection

    4G Wireless Industrial Router Wireless Data Connectivity Step5: Click "OK" to complete the configuration 4.2 Wifi Connection Step1: Detect Router Wireless Network Connection Step2: Click “connect” to establish a connection Page 16 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 17: Default Setting

    Open a browser, such as IE, Google, etc. and enter IP address: http://192.168.10.1 (2).Enter username and password, user name: admin Password: admin After successfully login the R10/R20 router, the page is displayed as below: Page 17 of 57 King Pigeon Hi-Tech. Co., Ltd.

  • Page 18: Router Setting

    4G Wireless Industrial Router Wireless Data Connectivity 5. Router Setting 5.1 Current status System status Display current system running status Page 18 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 19 IP addresses that can be assigned. Whether 3G/4G devices is connected and the device names, 3G/4G module manufacturers, types, and IDs etc.. Internet Time The Internet time of system. Page 19 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 20 Note: After the router is restarted, all recorded logs will be lost. File Sharing Router reserved function,unwork. Video Surveillance Router reserved function,unwork Page 20 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 21: Work Mode

    4G Wireless Industrial Router Wireless Data Connectivity 5.2 Work Mode R10/R20 supports following 4 work modes: Work Mode Item Description Default 3G/4G Wireless The "3G/4G Settings" interface of the router is the WAN setting √ Router Mode interface, and the "Internet access mode" only has 4G dial-up;...

  • Page 22: 4G Setting(Wan Setting)

    Page 22 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 23 Manually add items that are automatically executed when AT dials. empty Extra AT cmd Standard Wireless Router Mode •Dynamic Internet Access Page 23 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 24 Static address DHCP IP address Provided by the ISP. LAN customization. 0.0.0.0 Subnet Mask Provided by the ISP. LAN customization. 0.0.0.0 Default Gateway Provided by the ISP. LAN customization. 0.0.0.0 Page 24 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 25 We can use the router as a bridge AP to bridge the previous level of the wireless router. Connect to the LAN interface through the network cable, enter the router <work mode>, and select the wireless AP + client mode. Page 25 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 26: Break Detection

    4G Wireless Industrial Router Wireless Data Connectivity Wireless AP Client Mode 5.3.2 Break Detection WAN Break Detection: Interval how many times to detect WAN network status and the allowed re-connection times. Page 26 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 27: Wan Mac Clone

    If you have already registered the domain name gg.3322.org on www.3322.org, the method for establishing a dynamic correspondence between the domain name and the router's WAN port IP address is as follows: Page 27 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 28: Vpn Setting

    The status shows whether the connection is successful. Only the status displayed “Connected”, and the DDNS function starts normally. 5.4 VPN Setting In <VPN Settings> you can set: • PPTP settings • L2TP settings 5.4.1 PPTP PPTP@VPN Setting Page 28 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 29: L2Tp

    Automatically dial the VPN when the WAN port is connected. Only use L2TP to All data pass the VPN gateway, work with "VPN NAT" you can use Untick connect WAN network port forwarding\DMZ L2TP Server Required empty Page 29 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 30: Lan Setting

    LAN port IP address. You can access the router web interface IP address 192.168.10.1 through this IP address. Subnet mask Subnet mask corresponding to the IP address of the LAN port 255.255.255.0 Page 30 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 31 If the IP address of the router LAN port is set between the DHCP start address and the end address, the router will automatically set the DHCP-assignable IP start address to the last address of the router LAN Page 31 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 32: Ip&Mac Address Binding

    • Write the file in the format ".cfg" first, then click the <Import> button to import. Note: The format of the .cfg file is "MAC Address - IP Address - Username [Example] 00:00:e8:f5:6e:3a -192.168.10.22- host 00:00:00:00:11:11- 192.168.10.111- host 1 Page 32 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 33 LAN with the corresponding MAC address). Step3: Tick <Address Binded> → <Not allowed to Modify>. Step4: Tick < Address not binded> → <Not allowed to pass>. Page 33 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 34: Dhcp Table

    • Disable • Open System • WPA-PSK • WPA2-PSK • WPA-PSK/WPA2-PSK (WPA-PSK and WPA2-PSK mixed mode) Open System In this security mode, the encryption types are: None and WEP. Page 34 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 35 Key Setting: 64bit encrypt: 10-digit hexadecimal or 5-digit character. 128bit encrypt: 26-digit hexadecimal or 13-bit character. WPA-PSK This security mode is WPA-PSK encryption mode. WAP-PSK @ Security Item Description Default Page 35 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 36 WPA-PSK key hexadecimal numbers (0~9, a~f or A~F). Key Interval Set key update interval time,unit is second 3600 WPA-PSK/WPA2-PSK WAP-PSK/WAP2-PSK @ Wireless Security Item Description Default Security Mmode WPA-PSK/WPA2-PSK Page 36 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 37: Advanced

    MAC access can set the router's wireless white list and black list. If set to "Allow", only the MAC in the list can be connected to the wireless, and the others cannot access. If set to "Disable", the Page 37 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 38: Security

    IP address to prevent PING behavior from the WAN side. If the firewall function is disabled, all firewall settings will be invalid and the router will be in danger. Page 38 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 39: Access-Restrictions

    If it is met, it will no longer be compared with the later rules. It is determined by this rule whether the data is passed or blocked. Page 39 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 40 If the host wants to browse the web, it needs to allow the protocol to be TCP, and the data of port 80 is passed. When its data arrives at the router, the router looks for rules and compares it. It turns out that 1-4 does not Page 40 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 41 Web services (port 80), and other computers are not allowed to access the Internet. Note: All computer IP address is 192.168.10.2~192.168.10.254. Set as follows: Step1: Add an access control archive,allow computers with IP addresses 192.168.10.2 to 192.168.10.50 to access the Internet: Page 41 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 42 4G Wireless Industrial Router Wireless Data Connectivity Step2: Click <Add> to add this rule. Step3: Prevent other computers from accessing the Internet. Step4: Click <Add> to add this rule. Page 42 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 43: Port Triggering

    The port here includes the source port and the destination port, so the packet will be discarded by the router regardless of whether the source port or destination port of the packet is within the range. 5.8.4 DOS Page 43 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 44: Server

    DMZ host. • Port triggering allows the wireless router to automatically open inbound service ports based on the LAN's access to the Internet. Page 44 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 45: Virtual Server

    Note: The external port of each setting item cannot be repeated, and the number of internal ports and external ports must be the same, that is, the internal port and the external port correspond one-to-one. For example, Page 45 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 46: Special Application

    • When a computer in the LAN establishes a connection with the external network through the trigger port, its corresponding external port will also be opened, and the computer of the external network can access the LAN through these ports. Page 46 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 47: Dmz Setting

    • After the DMZ feature is enabled, the DMZ host is exposed to the Internet and the security is reduced. • The port number of the DMZ host should be the same as the service port number actually opened by the DMZ. Page 47 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 48: Com Server

    DMZ Host IP empty Note: Only one DMZ host can be set in the LAN. 5.9.4 Com Server The UART2 interface is the physical interface of the serial communication service. Page 48 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 49: Wifi Dog

    The router serial port service is used as the client, and the LAN connected Client Mode device is used as the serial port server. Server Mode Router serial port used as serial server, LAN connected device as client 5.9.5 WIFI DOG Page 49 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 50: Routing

    Static routes manually set the destination address, subnet mask, next hop address, and outbound interface to make the packets destined for the specified destination address go to the specified path. Page 50 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 51 A.The company computer needs to be able to access both the external network and the internal network server without modifying the IP address and gateway of the local connection. Configuration example is as follows: Page 51 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 52: Admin

    LAN communicates with the Internet through the wireless router, the wireless router can automatically add and delete the NAT mapping table as needed, so that some traditional services (such as MSN voice and video) cannot be traversed. The problem with NAT. Page 52 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...
  • Page 53 SSH default is enabled, telnet management default is disabled and needs to be manually opened. Instructions: Take PUTTY as an example. As shown below, you can choose one of ssh or telnet. Page 53 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 54: Time-Setting

    IP address or domain name) of the NTP server in the text box. Untick Server below The wireless router updates the time to the specified NTP server. 5.11.3 Backup & Restore Backup Settings Page 54 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 55: Firmware Upgrade

    Step3: If you need to upgrade and restore the factory, click the <Factory-Defaults> button. Note: The upgrade and factory reset must meet two conditions at the same time. (1).Version number changes. (2).Click the <Factory-Defaults> button during the upgrade. Page 55 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 56: Restart

    This function is generally used when the device is switched from one network environment to another. The device is restored to the factory settings and then re-set to better suit the current networking. Page 56 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

  • Page 57: Password

    2) This warranty does not extend to any defect, malfunction or failure caused by abuse or misuse by the Operating Instructions. In no event shall the manufacturer be liable for any router altered by purchasers. The End! Any questions please help to contact us feel free. Http://www.IOT-SOLUTION.com Page 57 of 57 King Pigeon Hi-Tech. Co., Ltd. Ver 1.0...

This manual is also suitable for:

R20
