Metal Wine Rack with Glass Shelf
Assembly Instructions -
543/3830
Please keep for future reference
Dimensions
Width - 42cm
Depth - 33.5cm
Height - 92cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 2 - 15/08/16
Advertisement
Table of Contents
Related Manuals for Argos 543/3830
Summary of Contents for Argos 543/3830
- Page 1 Metal Wine Rack with Glass Shelf Assembly Instructions - 543/3830 Please keep for future reference Dimensions Width - 42cm Depth - 33.5cm Height - 92cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
- Page 2 • Keep these instruction for future reference. • If the glass is chipped or broken, stop using the product and consult the manufacturer or suppliers. • Imported by: Argos Ltd. • Batch No:12052016 489-400 Avebury Boulevard. • Date of Manufacture: May 2016 Saxon Gate West.
- Page 3 Components - Parts If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Side Frame x 2 Top Frame x 1 Metal Wine Frame x 5 Tempered Glass x 1 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 4 Assembly Instructions Step 1 Insert Round End Cap and Retangular End to Side Frame Assemble Adjustable Feet to PP Cover and put into the bottom part of Side Frame See fig. 1 fig. 1 Step 2 Tighten Top Frame Metal Wine Frame using Flate Screw Allen Key See fig.
- Page 5 Assembly Instructions Step 3 Use Rubber Sleeve on Top Frame See fig. 3 Use Bracket to ensure the unit is fixed on the wall securely to prevent overturning. See fig. 4 Please refer to a guide for using wall mounting and fixings.
- Page 6 Revision 2 - 7/10/09...
