STEEL COMPANY
R
Axial / Centrifugal
Heater
Owner's Parts and Instruction Manual
For the Following Heater Controls:
Thermostats
Modulating Gas Valves
High-Low Fire
Dual Control (Thermostat/Humidistat)
Sioux Steel Company
Sioux Falls, South Dakota 57101
800-557-4689
Manual No. 169169
Rev F/17-153/9-28-17/KAG
3-3-03/GDS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S17623 and is the answer not in the manual?

Questions and answers

Related Manuals for Sioux Tools S17623

Summary of Contents for Sioux Tools S17623

  • Page 1 STEEL COMPANY Axial / Centrifugal Heater Owner’s Parts and Instruction Manual For the Following Heater Controls: Thermostats Modulating Gas Valves High-Low Fire Dual Control (Thermostat/Humidistat) Sioux Steel Company Sioux Falls, South Dakota 57101 800-557-4689 Manual No. 169169 Rev F/17-153/9-28-17/KAG 3-3-03/GDS...

  • Page 3: Table Of Contents

    CONTENTS Heater Model List ........... . . Safety .

  • Page 4: Heater Model List

    HEATER UNITS COVERED IN THIS MANUAL AXIAL HEATERS PART # DESCRIPTION WITH THERMOSTAT CONTROL S17623 24" DIA. LP VAPOR 2.0 M BTU/HR WITH THERMOSTAT CONTROL S17286 24" DIA. LP LIQUID 2.0 M BTU/HR WITH THERMOSTAT CONTROL SCH24N-T 24" DIA NATURAL GAS 1.6 M BTU/HR WITH THERMOSTAT CONTROL S27608 28"...
  • Page 5 HEATER UNITS COVERED IN THIS MANUAL (cont.) CENTRIFUGAL HEATERS PART # DESCRIPTION WITH THERMOSTAT CONTROL (50F-180F TEMP RISE UNLESS NOTED) S27763 7.5 -15 HP LP VAPOR 2.7 M BTU/HR WITH THERMOSTAT CONTROL S17518 7.5 - 15 HP LP LIQUID 2.7 M BTU/HR WITH THERMOSTAT CONTROL S17839 7.5 -15 HP NATURAL GAS 2.2 M BTU/HR WITH THERMOSTAT CONTROL S20352...
  • Page 6 READ AND SAVE THESE INSTRUCTIONS GENERAL SAFETY STATEMENTS Thank you for choosing a Sioux Steel Company product. It is designed to perform and serve you for many years. It is the goal of Sioux Steel Company to improve our products whenever it is possible and practical to do so. Sioux Steel Company reserves the right to change, improve, and modify products at any time without obligation to make changes, improvements, and modifications on previously sold equipment.

  • Page 7: Safety

    SAFETY RECOGNIZE THE SAFETY ALERT SYMBOL The above symbol means “ATTENTION! BE ALERT! YOUR PERSONAL SAFETY IS INVOLVED!” Note this symbol in instructions for important issues concerning your personal safety. Read each message carefully to avoid personal injury or death. FOLLOW MACHINE SAFETY SIGNS &...
  • Page 8 WARNING: To reduce the risk of fire, electric shock, or injury to persons, observe the following: Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally.
  • Page 9 DANGER: Never enter bin, unless all power is locked off and another person is present. Rotating augers can kill or dismember! DANGER: Flowing grain may trap and suffocate. If you enter a bin of flowing grain you can be completely submerged in grain in seconds.
  • Page 10 SAFETY DECAL LOCATIONS FOR AXIAL HEATER Safety decals and shields are mounted whenever possible at factory. Please check that all decals are in place according to these drawings and in good legible condition. To order replacement decals or shields (NO CHARGE) contact your dealer or Sioux Steel Company, 196 ½...
  • Page 11 Safety- In Case of Fire Instructions IMPORTANT: TO MAINTAIN GRAIN QUALITY AND AVOID RISK OF BIN FIRE, DRYING TEMPERATURE SHOULD NOT EXCEED 130 DEG. F FOR IN-BIN STIR DRYING OF CORN, OR 180 DEG. F FOR IN- BIN CONTINUOUS-FLOW SYSTEM. LOWER TEMPERATURE MAY BE REQUIRED DEPENDING UPON DRYING CONDITIONS.

  • Page 12: Heater Selection

    HEATER SELECTION DETERMINE THE RIGHT SIZE FAN FOR YOUR BIN SIZE FIRST WARNING! Determining the correct size fan for the size of the bin, type of grain and needs, is the key to successful drying. Your heater selection only needs to match your fan size, fuel source at hand, and type of heater controls desired.
  • Page 13 CONTINUOUS FLOW DRYING. High-low or modulating valve (continuous flame) is recommend for high temperature continues flow drying. High-low burners cycle between high and low flame for more even temperature control. It is NOT for low temperature drying. BATCH-IN-BIN OR STIR DRYING: Thermostat, high-low or modulating valve units may be used for these styles of drying.

  • Page 14: Installation, Operating, & Maintenance

    INSTALLATION, OPERATING, & MAINTENANCE SOLID STATE CONTROL HEATER FOR OPERATION WITH PROPANE VAPOR, PROPANE LIQUID, AND NATURAL GAS DANGER: THESE UNITS OPERATE WITH FLAMMABLE AND EXPLOSIVE GASES, IMPROPER INSTALLATION, OPERATION, OR MAINTENANCE CAN CREATE POTENTIAL DANGER. READ ALL INSTRUCTIONS CAREFULLY, AND OBEY ALL CAUTIONS AND WARNINGS.
  • Page 15 Heaters Using Liquid Propane When the propane storage tank will not provide sufficient vapor to operate the heater continuously, a model with a preinstalled vaporizer should have been purchased. The purpose of the vaporizer is to convert the liquid propane to a vapor by using the heater flame to heat the propane. The dealer selling the heater usually knows if a vaporizer is needed, and should recommend a model that incorporates one.
  • Page 16 Upstream centrifugal heaters should be mounted on the inlet side of the centrifugal fan using the bracket kit (S187794), sold separately. See page 44 for assembly instructions for use of bracket kit. When using a high-temp heater in an upstream centrifugal configuration, never burn heater above 200 degrees (F).
  • Page 17 3. Red light located on heater control panel comes on indicting solenoid valves; transformer and spark plug are energized. – Heater lights and fires. 4. Unlock locking nut of heater regulator. Adjust gas pressure setting according to your models controls (thermostat, modulation gas valve, high-low thermostat –...
  • Page 18 MAINTENANCE KEEP ALL GUARDS AND SCREENS IN PLACE DISCONNECT ALL POWER SOURCES BEFORE DOING ANY REPAIR, MAINTENANCE OR INSPECTIONS! BEGINNING OF EACH DRYING SEASON: Remove inlet screen. With power off, check for foreign material on fan blade. Turn fan by hand to be sure it rotates freely.

  • Page 19: Low Temperature Drying Information

    NOTES ON LOW TEMPERATURE DRYING LOW TEMPERATURE DRYING: Low temperature drying is used to achieve a 25% drop in relative humidity. Raising the outside temperature (ambient) by no more than 10 degrees, when using an axial or centrifugal fan producing 2/3 to 3 cfm per bushel, and a Super –Low heater will achieve this. Keep in mind, we suggest a grain spreader for your bin and this type of drying should be in a situation where you are using your bin to dry one full bin per year (not for continuous flow drying).
  • Page 20 second fill is three points or more drier than the initial fill, add layers equal to the initial fill depth every 7-10 days until the bin is full. Continue to operate the fan and heater until grain is dry- or average temperature dips below 30 degrees F and the average moisture content is 18% or less.
  • Page 21 Low Temp Drying Guide Initial Fill Depth (ft.) Bu. Cap. Dia.(ft.) Per Ft. Depth Size 1 CFM/Bu 2 CFM/Bu 3 CFM/Bu 4 CFM/Bu (1) 5HP Axial (1) 5HP Axial (1) 7 1/2HP Axial (1) 5HP Axial (1) 7 1/2HP Axial (1) 10HP Axial (1) 10HP Cent (1) 5HP Axial...

  • Page 22: Automatic Controls (Model Tc-100 & Tc-400, Ht-3000)

    AUTOMATIC CONTROLS FOR USE WITH DRYING HEATERS MODEL TC-100, TC-400, & HT-3000 THERMOSTAT CONTROL WARNING! Although these controls are called “automatic”, they do not sample the grain for proper moisture content! They are designed to cycle the heater on and off to the set of conditions that you select. RESPONSIBILITY FOR THE GRAIN CONDITION IS YOURS! SHIPPING, RECEIVING AND INSPECTION All cardboard cartons are shipped attached to heater, with power cord installed.
  • Page 23 THERMOSTAT CONTROL OPERATING INSTRUCTION (TC-100 & TC-400) WARNING! This automatic control is more simply stated as an automatic switch. The control merely switches the heater on and off. It does NOT adjust the heater gas pressure to changing ambient temperatures or changing airflows. This is YOUR responsibility! The TC-100 and TC-400 contains an automatic thermostat with a temperature range from 70 degrees F (21 C) to 200 degrees F (93 C).
  • Page 24 COMBINATION THERMOSTAT/HUMIDISTAT (HT-3000) The HT-3000 contains a thermostat and humidistat. The controls are wired in series and will over-ride each other when they are “satisfied”. The HT-3000 is designed to activate the heater only when additional heat is needed to provide adequate drying.
  • Page 25 Set humidistat knob for relative humidity, above which you wish to add supplemental heat to the drying air. The thermostat setting overrides the humidistat setting in the event the bin temperature exceeds the thermostat setting, thus acting as a high limit. Whenever shutting down your fan &...

  • Page 26: Solid State High-Low Fire

    SOLID STATE HIGH-LOW FIRE THERMOSTAT DUAL SOLENOIDS WITH L.E.D. DISPLAY WARNING! This control does not sample the grain for proper moisture content! They are designed to cycle the heater on and off to the set of conditions that you select. RESPONSIBILITY FOR THE GRAIN CONDITION IS YOURS! SHIPPING, RECEIVING AND INSPECTION All cardboard cartons are shipped attached to heater, with power cord installed.
  • Page 27 OPERATING INSTRUCTION WARNING! This automatic control is more simply stated as an automatic switch. The control merely switches the heater on and off. It does NOT adjust the heater gas pressure to changing ambient temperatures or changing airflows. This is YOUR responsibility! The thermostat is programmed at the factory to operate with your heater.
  • Page 28 After determining your temperature setting, and adjusting thermostat to reflect that, you are ready to begin. 1. Start fan and heater according to separate instruction in respective manuals. There will be a 45 second delay as the fan purges the heater of any fuel vapors. 2.
  • Page 29 If the heater still will not fire, the problem may not be related to the Thermostat. Review the trouble shooting guide on pages 33-35. Heater Fires But Does Not Cycle Off or Has A Long Cycle: Adjust gas pressure setting just high enough to satisfy the low-fire side of thermostat. Too low of gas flow will cause the heater to burn longer.

  • Page 30: Modulating Gas Valve

    MODULATING GAS VALVE RANGE 90 – 210 DEGREES (F) WARNING! The modulating gas valve is designed to fluctuate with the heaters fuel source to maintain the temperature that you select. RESPONSIBILITY FOR THE GRAIN CONDITION IS YOURS! APPLICATION The modulating valve is intended to automatically control the flow of gas to your heater.
  • Page 31 INITIAL STARTUP To set modulating valve at the start of the drying season: NOTE: The valve and heater were tested at the factory and pre-set to as close to 120 degrees as allowed in relation to that day’s current ambient temperature. You still need to adjust gas pressure and modulating valve to reach your desired range for your crop.
  • Page 32 Can Not Reach Desired Temperature: If maximum desired temperature cannot be reached then the regulator valve may be set too low and should be increased. Caution- use only small changes since the effect of this valve is only known when the modulation valve is calling for full heat.

  • Page 33: Troubleshooting (Solid State)

    TROUBLE SHOOTING GUIDE SOLID STATE – IGNITION BOARD CHECK AND CORRECTION PROCEDURE (FOLLOW ELECTRICAL SCHEMATIC ON PAGE 34) CAUTION Bleed fuel lines before servicing unit. The procedures outlined below are for use only by qualified service personnel. Use caution when checking electrical components. →...
  • Page 34 →SOLENOIDS CHATTER WHEN ENGERIZED In rare cases, solenoids have been known to chatter (open and close rapidly). This could be interference from the transformer located on the control board. If this occurs, lightly pull all wires from the control board away from control board transformer and zip tie off to one side. →BURNER IGNITES, BUT LOCKS OUT IN 10-20 SECONDS Look for cracked porcelain on flame-sensing rod.
  • Page 35 → SPARK PLUG FOWLING, CARBON BUILD UP Carbon build up is a symptom of poor air moment. The heater has been designed to have two locations for the spark plug. From the factory, the plug is mounted in the optimum location for spark in clean air.

  • Page 36: Basic Wiring All Units

    Figure# 1 Basic Wiring For All Units Use key below for all basic wiring of heater See Figure #2 for high limit circuitry See Figure #3 for heater controls circuitry LAMP Lamp XFMR Ends High Limit Circuitry. See Figure 2 Begins High Limit Circuitry.

  • Page 37: Incoming Power Following High Limits

    Figure# 2 Incoming Power Following High Limits Transition High Limit All High Limits Must Be Closed For Incoming Power to Reach Boar LAMP Incoming Power Interlocked With Fan. L1 Pipe Train High Limit PTHL (Liquids Units Only) (LQ ONLY) KEY: Fuse Power Line (115V) - Must be interlocked with fan...

  • Page 38: Temperature Controls

    Figure# 3 Temperature Controls Use key below and match which temperature Control unit pre-installed. Thermostat LAMP High-Low Thermostat High Side Solenoid KEY: (High-Low Only) Thermostat Units Only Modulating Gas Valve Only High-Low Thermostat Only...

  • Page 39: High Fire Upper Manifold

    Figure# 4 High Fire Upper Manifold Note: Liquid propane/vapor or natural gas units *ORIFCES: LIQUID PROPANE NATURAL GAS 24" AXIAL 11/64" 23/64" 28" AXAIL 13/64" 23/64" 7.5 CENT 13/64" 23/64" 20HP CENT 15/64" 23/64" 1/2" 115V SOLENOID VALVE ON ALL LIQUID/VAPOR PROPANE UNITS. PART NUMBER: SCH6080 NOTE: 0-30 PSI GAUGE, BACK CONNECT (COIL COMES WITH SOLENOID WHEN...

  • Page 40: Lower Manifold, Liquid Propane

    Figure# 5 Lower Manifold, Liquid Propane Only NOTE: 18" HIGH PRESSURE HOSE. NOT SHOWN. PART NUMBER: SCH6055 1/4" 115V SOLENOID VALVE ON ALL LIQUID PROPANE UNITS. PART NUMBER: SCH6075 (COIL COMES WITH SOLENOID WHEN ORDERING AS A PART. COIL NOT SHOWN IN DRAWING) 1/4"...

  • Page 41: Upper Manifold, Super Low Fire Gas

    Figure# 6 Upper Manifold, Super Low Fire Gas Only **ORIFICES: VAPOR PROPANE 24" AXIAL 1/8" 28" AXAIL 1/8" 1/4" 115V SOLENOID VALVE ON ALL VAPOR PROPANE UNITS. PART NUMBER: SCH6075 NOTE: 0-30 PSI GAUGE, BACK CONNECT (COIL COMES WITH SOLENOID WHEN LIQUID FILLED.

  • Page 42: Upper Manifold, Modulating Gas Valve

    Figure# 7 Upper Manifold, Modulating Gas Valve MODULATING THERMOCOUPLE NOT SHOWN 90ø-210ø MODULATING GAS VALVE PART NUMBER: 4035500 1/2" PRESSURE REDUCING VALVE ON ALL LIQUID/VAPOR PROPANE UNITS. PART NUMBER: SCH6060 NOT SHOWN. 1/2" 115V SOLENOID VALVE ON ALL LIQUID/VAPOR PROPANE UNITS. PART NUMBER: SCH6080 (COIL COMES WITH SOLENOID WHEN ORDERING AS A PART.

  • Page 43: Upper Manifold, High- Fire Thermostat

    Figure# 8 Upper Manifold, High – Fire Thermostat *ORIFICES: 24" AXIAL 11/64" 28" AXAIL 13/64" 7.5 CENT 13/64" 20HP CENT 15/64" ** 1/2" 115V SOLENOID VALVE. (SHOWN WITHOUT COIL.) NOTE IN & OUT PORTS. ORFICE DRILLED AS FOLLOWS: 24" AXIAL 1/8". PART NUMBER: SCH6085 NOTE: 0-30 PSI GAUGE, BACK CONNECT 28"...

  • Page 44: Super-Low Heater Bracket Kit Assembly S187994

    BRACKET KIT ASSEMBLY S187794 FOR MOUNTING 28” DIA. SUPER LOW TEMP AXIAL HEATERS TO CENTRIFUGAL FANS Remove Fan Guard From Housing Guard Mesh Parts to be Drill Screwed to End Panel Flanges after attaching Heater to Mount Brackets Intake Side of Fan Heater Housing...

  • Page 45: Centrifugal Adapter Frame (208& Scf Series Fans)

    Centrifugal Heater to 208 Series Fan 7.5 & 10HP Adapter Frame Kit S208468 Kit to be used on the following fans 7.5HP - S208057, S208058, S208059 10HP – S208062, S208063, S208064, S208065, S208066, & S208067 Item Part Description Qty. Number 208469 Top- Heater Adapter 208470...
  • Page 46 Centrifugal Heater to SCF Series Fan 10 & 15HP Adapter Frame Kit S208817 Kit to be used on the following fans: 10HP: SCF-10-1CG; 15HP: SCF-15-1CG & SCF-4CG Item Part Description Qty. Number 208818 Top- Heater Adapter HEATER SIDE 208820 Side- Heater Adapter LH 208821 Side- Heater Adapter RH 208819...
  • Page 47 Centrifugal Heater to SCF Series Fan 20HP Adapter Frame Kit S208822 Kit to be used on the following fan: SCF-20-4CG Item Part Description Qty. HEATER SIDE Number 208823 Top- Heater Adapter 208825 Side- Heater Adapter LH 208826 Side- Heater Adapter RH 208824 Bottom- Heater Adapter 177732...

  • Page 48: Replacement Parts

    Replacement: Parts Electrical/Plumbing/Manifolds Electrical: 8 Foot Power Cord SCHD5975 Fuse Holder 3220120 Flame Rod 3036505 High Limit 3435415 Spark Plug SCH5980 Toggle Switch 3435032 Wire Set, Basic Heater SCHZ41 Transformer 3045052 Indictor Light SCH5020 Term Block SCH5010 Control Board SCH5000 Plumbing: Solenoid Valve ½”...
  • Page 49 LP Upper Thermostat 20HP Centrifugal Manifold SCHZ53-20 LP Upper Thermostat 24” Axial Manifold SCHZ53-24 Natural Gas Upper Thermostat 24” Axial Manifold SCHZ55-N LP Upper Thermostat 28” Axial Manifold SCHZ53-28 Natural Gas Upper Thermostat 28” Axial Manifold SCHZ55-28 LP Upper Thermostat Super-Low 24” Axial Manifold SCHZ56-24 LP Upper Thermostat Super-Low 28”...

  • Page 51: Template (Tc-100, Tc-400, & Ht-3000)

    TEMPLATE (TC-100 Thermostat)

  • Page 53: Warranty

    RODUCT ARRANTY LIMITED WARRANTY FOR NEW SIOUX STEEL COMPANY PRODUCTS A. GENERAL PROVISIONS. “Sioux Steel” means Sioux Steel Company, 196 1/2 East Sixth Street, Sioux Falls, South Dakota 57104. The warranties described below are provided by Sioux Steel to the original purchasers of new products purchased from Sioux Steel or from an authorized Sioux Steel Dealer (the “Products”).
  • Page 54 or alteration of the Products; (3) Products that have not been properly installed or not installed in accordance with the instruction manual, improper assembly, or improper construction by any persons other than Sioux Steel employees; (4) depreciation, damage or loss caused by the use of parts, components or accessories not provided by Sioux Steel, unauthorized repairs, normal wear, lack of necessary and proper maintenance, a failure to follow operating instructions/recommendations, misuse, lack of proper protection during storage, vandalism or theft, exposure to the elements or corrosive materials, accidents or acts of nature including lightning, flooding, hail, straight winds and tornadoes;...
