Summary of Contents for JIMTEN FILTMASTER
- Page 1 Operation and maintenance manual Filtration Systems...
-
Page 2: Safety Instructions
During the filtration phase, dirty water flows through the working the automatic filtration station. inlet HDPE manifold and goes through the backwash hydraulic valves into the Filtmaster disc filters, passing 2. Make sure the filter is not pressurized before doing through the discs to the outlet HDPE manifold. - Page 3 Filtered water We recommend the ins- tallation of a manual control valve in the out- let of the filtration sta- tion to make maintenan- ce easier. Drainage Drainage water coming out from the backwash hydraulic valves collected in a common HDPE manifold.
-
Page 4: Installation Recommendations
Operation and maintenance manual Hydraulic operation of IN LINE backwash valves: Hydraulic operation of IN ANGLE backwash valves: Backwash Filtration Backwash Filtration In backwash mode: the hydraulic command [1] pressuri- In backwash mode: the hydraulic command [1], pressuri- zes the lower control chamber [2], moving the diaphragm zes the upper control chamber [2], forcing the diaphragm [3] and the metal axis [4] upwards. -
Page 5: Description And Operation
10 bar. In case that the differential pressure is above 0,6 bar 6. Program the controller following the instructions in (9 psi), activate manually the backwash of the Filtmaster this manual. filtration station. In case that the differential pressure 7. - Page 6 Operation and maintenance manual • Personal protection equipment: safety glasses, gloves, Clean regularly the hydraulic command filter long pants, long sleeved shirt and shoes. The ¾’’ filter installed in the inlet HDPE manifold provides To clean organic and biological deposits, put the discs in clean water to command hydraulically the backwash valves.
-
Page 7: Troubleshooting
Troubleshooting NO BACKWASH OPERATION Check inlet and outlet pressure Check & clean command filter Check controller. Manually operate the backwash cycle No command Functioning Some commands transfer correctly do not function Check electrical source. Check electrical source. Replace battery if Replace battery if needed needed... -
Page 8: Spare Parts
Operation and maintenance manual CONTINUOUS OR NON-STOP BACKWASHING Spare parts Continuous Nonstop backwash and accessories backwash cycle Disconnect the control Check inlet / outlet pressure micropipes from Check pressure differential gauge the valves and replace if needed Check controller described above Force backwash manually Contact your... - Page 9 In this manual, we will cover the installation of the con- troller and the electrical wiring to all elements to be con- trolled. This manual has been prepared by JIMTEN for the exclu- sive use of its customers. It is understood that the user is responsible for use.
- Page 10 Operation and maintenance manual How to install the controller. The Filtmaster filter cleaning controller has a transparent The controller is designed to be installed directly on the protecting cover with a hinge: wall. These are the dimensions: 120mm 190mm Fixing to the wall is done by placing 3 screws according...
-
Page 11: Low Voltage
At the back, there are spare fuses and a wiring connec- 1,6 Amp tion diagram for the controller. Once the Filtmaster filter cleaning controller is situated correctly we proceed to connect to power supply taking into account polarity. There are several options for power supply sources: 220 Vac power supply. - Page 12 24Vac voltage in the these terminal blocks. performance of the controller. • In exceptional cases, conditioned by the power con- sumption of solenoids connected to the Filtmaster fil- In these cases, while the warning message is displayed, ter cleaning controller or by the number of solenoids the controller is paused.
- Page 13 Never use fuses higher than 2Amp. In case it is fused fuse for the manual control of the system. repeatedly, you should contact JIMTEN’s technical ser- vices. Originally, the output fuse is a 1,6 Amp fuse. This value must never be exceeded under any circumstances.
- Page 14 The battery recommended by JIMTEN for this function has a 550mAh charge. 9 Vdc power supply (batteries) There is a model of Filtmaster filter cleaning controller that works with 9 Vdc batteries. NOTE Unlike the previous controller models, it can only work We recommend using longlife well known brand with two-wire latch solenoids (with invertible polarity).
- Page 15 Sleep controller? will be shown The Filtmaster filter cleaning controller can be connec- ted either to continuous consumption solenoids or to latch solenoids. When validating, the screen will turn off, but the contro- The connection is the same for 12 Vdc controllers, ta- ller will be fully operational.
- Page 16 Some manufacturers make specific solenoids for each operation. There are 4 common terminals (internally bridged). The Filtmaster filter cleaning controller, can work with different brands of latch solenoids. If there are many cables to be connected to these ter- minals, we will install an external terminal block for an JIMTEN recommends a solenoid that, for connections appropiate connection to the controller.
-
Page 17: Communication Connections
Furthermore, the installation of an external relay is good The devices shown on the previous table are those in the because this increases the galvanic separation between following diagram: the solenoid and the controller. Another advantage is that the relay can bequickly changed in case of breakdown. INPUTS Electric connection to pumps In addition to the controller, backwash valves and fil-... - Page 18 MTEN has officially approved different GSM modem mo- ICT connection (via radio) dels for the Filtmaster filter cleaning controller. Through a radio connectivity module, this Filtmaster fil- If you have a different modem model, please contact ter cleaning controller model can command an ICT trans- JIMTEN’s technical department to verify its compatibility.
-
Page 19: Technical Characteristics
One of these screens allows the installer to check that ports provided by the Filtmaster filter cleaning controller. the connections are correctly made and, at the same time, to test the devices connected to the Filtmaster fil- The following will appear immediately: ter cleaning controller. - Page 20 Displayed when there is a need for cleaning through this device. WATER METER DETECTED Displayed when it detects a meter pulse (if this device The Filtmaster filter cleaning controller is an easily pro- exists). grammable powerful device designed to process automa- CLEANING PERMISSION ACTIVATED Displayed when it detects water in the network tically all the functions of a modern filtration station.
- Page 21 00:18 FLUSHING ti Out of schedule …The Filtmaster filter cleaning controller is out of the time interval when it is authorised to clean filters (displayed only if a cleaning interval time has been entered). FILTER AND TIME REMAINING...
- Page 22 Operation and maintenance manual The Filtmaster filter cleaning controller keypad has been At this stage, we can activate a manual cleaning to check designed for an easy and intuitive use. setup program and also to check if connected devices work properly.
-
Page 23: Clock Adjustment
filtration station. To do this, we first should be informed about the filter characteristics and the necessary pressure and time for a Allows us to set up time and date of the Filtmaster filter successful cleaning process. cleaning controller. We insert the current time by pressing the numerical... - Page 24 Operation and maintenance manual Asks if we want one of the outputs of the controller to The Filtmaster filter cleaning controller can get into PAU- be permanently connected while the cleaning process of SE mode if there is no need for cleaning the filters be- filters is done or while it is paused.
- Page 25 By default the Filtmaster filter cleaning controller sets identical CLEANING and PAUSE times for all filters. FLUSH INTERVAL V= 0000 T= 00:00...
- Page 26 Special situations If there is an electric voltage drop, the Filtmaster filter cleaning controller keeps all the data in its memory until the electrical voltage recovers. Then, the controller con- tinues working from the last status (after waiting progra- med DELAY AFTER FLUSHING time).
- Page 27 This manual does not have a contractual value and all information is given in good faith. We do not assume any liability for the use of this manual. You will find the most updated version of this manual in our website jimten.com...
- Page 28 Filtration Systems Operation and maintenance manual...
Need help?
Do you have a question about the FILTMASTER and is the answer not in the manual?
Questions and answers
Как правильно подключать FiltMaster 2"?
To properly connect the JIMTEN FiltMaster 2", follow these steps:
1. Mount the Controller:
- Use the included mounting template to mark screw positions on the wall.
- Fix the controller to the wall using the 3 Rawl plug and screw sets.
- Remove the wiring cover to fix the lower screws.
2. Cable Entry:
- Use the 6 packing glands included in the packaging for cable input.
3. Connect Controller and Modem:
- Use the appropriate cable provided by JIMTEN.
- Ensure the cable runs outside areas with possible interference (e.g., power cables, motors).
- Match the pins:
- PIN 2 (Modem) to PIN 1 (Controller)
- PIN 6 (Modem) to PIN 2 (Controller)
- PIN 9 (Modem) to PIN 3 (Controller)
- Set jumpers:
- PIN 7 with 8
- PIN 11 with 12
4. Radio Connectivity Module:
- Required for this model.
- Ensure compatibility with ICT Transmitter version 6.
5. Power Supply Setup:
- Access the power supply area by removing the lower cover.
6. Programming:
- Use the keys to navigate and program the controller.
- Validate entries to save them.
- Default manual cleaning: 5 seconds per output with 4 seconds pause.
Always ensure proper activation awareness due to possible connected pump or fertilizer pump outputs.
