Page 4
Specifications for PDP TV (NTSC-M, PAL-M, PAL-N) Main Features ● High Contrast Ratio & High Brightness ● Built in Tuner ● Built in Speakers (Option) ● HDMI Port Support Up to 1920 x 1080i ● Multi-Scanning RGB(PC) Monitor Support Up to 1024 x 768 / 60Hz 1360 x 768 / 60Hz (nVidia Only) ●...
Page 5
PDP TV Specifications Item 42" SD 42" HD 50" HD Screen Size(Active Area) 50" (1106.5(H) x 622.1(V)±5mm) 42" (920.1(H) x 518.4(V)±5mm) Aspect ratio 16:9 Number of Pixels 852 (H) x 480 (V) 1024 (H) x 768 (V) 1366 (H) x 768 (V) Pixel Pitch 1.080(H) x 1.080(V) [mm] 0.900(H) x 0.676(V) [mm] 0.810(H) x 0.810(V) [mm]...
Page 6
External Speaker (Optional) Specifications Item 42" (A) 42" (B) 50" 90 mm x 721 mm x 68 mm Dimensions (W mm x H mm x D 113 x 626.6 x 82.2 90 x 625 x 68 3 Kg ( L + R ) Weight 5 Kg ( L + R ) 2.9 Kg (L+R)
Page 7
Image Board Trouble Shooting Guide Abnormal TV Signal Replace RF Cable Replace Cable / Check Replace Sub Replace Sub Board (Tuner) Board / Check Replace Main Board Replace Main Board / Check Replace PDP Module...
Page 8
Abnormal HDMI, RGB, Component Video Signal Replace HDMI, Replace Cable RGB, RCA Cable / Check Replace Main Board Replace Main Board / Check Replace PDP Module...
Page 10
Abnormal S-Video Video Signal Replace Cable Replace S-Video Cable / Check Replace Replace Sub Board Sub Board / Check Replace Replace Main Board Main Board / Check Replace PDP Module...
Page 11
Abnormal Video Signal Replace Replace Cable RCA Cable / Check Replace Replace Sub Board Sub Board / Check Replace Main Board Replace Main Board / Check Replace PDP Panel...
Page 12
TV Main is displayed, but Caption is Failed Replace Sub Replace Sub Board (Tuner) Board / Check Replace Main Board...
Page 13
Power On Failure Replace Connector Ass'y Replace Connector Ass'y / Check Replace Control Board Replace Control Board / Check Replace Replace Power Board Power Board / Check Replace Replace Main Board Main Board / Check Replace Replace Sub Board Sub Board / Check Replace PDP Module...
Page 14
None Working Control Key, LED, IR Replace Replace Cable Connector Ass'y / Check Replace Control Board Replace Control Board / Check Replace Main Board...
1. SCOPE 1.1 Introduction Product configuration This specification defines the configuration and performance requirements for the following Plasma Displays. Product Name : PDP-TELEVISION Plasma Displays Display Type : 42” SD / 42” HD / 50” HD Model Name : NP – 42S5 / NP-42H5 / NP-50H5 1.2 Product Definition The top level assembly shall contain : Top Level Assembly...
1.4 Change Control All Engineering changes to the product shall be made in ECR/ECN accordance with the WoosungNextier Corp. ECR/ECN Procedure 1.5 Service Complete Spare Parts List, Schematic, Service Manual, and Documentation / Service Manual Assembly Drawings shall be provided within one month of Mass Production Release.
3. INPUT SIGNAL INTERFACE 3.1 HDMI Interface HDMI Input Connector Type A Female Contacts Type A Connector Pin Assignment Pin 1 TMDS Data 2+ Pin 2 TMDS Data 2 Shield Pin 3 TMDS Data 2- Pin 4 TMDS Data 1 Pin 5 TMDS Data 1 Shield Pin 6 TMDS Data 1-...
3.2 RGB Interface RGB Input Connector D-Sub 15-Pin Jack (Female) Audio Input Connector 3.5mm Stereo Jack D-Sub 15-Pin Cable Connector Pin out Pin 1 Red analog Signal Pin 2 Green analog Signal Pin 3 Blue analog Signal Pin 4 Pin 5 Pin 6 GND for Red signal Pin 7...
Page 23
3.3 RGB Mode Table Mode Resolution Horizontal Vertical Pixel Clock Frequency Frequency(kHz) Frequency (Hz) (MHz) 640 x 350 31.469 70.087 25.175 37.861 85.08 31.5 640 x 400 37.861 85.08 31.500 720 x 400 31.469 70.087 28.322 37.927 85.039 35.5 640 x 480 31.469 59.94 25.175...
Page 24
3.4 Component Interface Component Input Connector RCA(YPbPr/YCbCr) Jack x 2 Audio Input Connector RCA(L+R) Jack x 2 Component Signal Y : 1V[p-p] Pb/Cb : 0.7V[p-p] Pr/Cr : 0.7V[p-p] Component Signal Impedance 75 Ohms Audio Input 0.5[rms] (L+R) Audio Input Impedance 470K Ohms Component Signal Type SDTV : 525i(480i), 625i(576i)
3.6 S-Video Interface S-Video Input Connector Mini DIN4-pin S-Video Signal Y : 1V[p-p] C : 0.286V[p-p] (NTSC) C : 0.3V[p-p] (PAL/SECAM) S-Video Signal Impedance 75 Ohms 3.7 Composite Interface Composite Input Connector RCA(Video) Jack x 2 Audio Input Connector RCA(L+R) Jack Composite Input Signal V : 1V[p-p] Composite Audio Input Level...
4. POWER 4.1 Power Supply Model Name NP-42S5 NP-42H5 NP-50H5 Input Voltage Range AC 100 ~ 240V AC 100 ~ 240V AC 100 ~ 240V Input Frequency Range 50/60 Hz 50/60 Hz 50/60 Hz Power Consumption Tpy : 290W Tpy : 350W...
5. CONTROLS AND INDICATORS 5.1 Hardware Controls Main Power Switch None Power / Standby : Red Operation Lamp : Green Controls Switch Input Menu VOL- VOL+ CH- Power Infrared Receiver Arrival Distance : Min 7m Resonance Frequency : 38 KHz 5.2 Remote Control Distance Angle...
7. Display Cell Defect Specification 42” SD Cell Defect Specifications ☞1) Non-Ignition Dot(Dark Defect) is defined as “A cell of which more than 50% area is not ignited” ☞2) Unstable Dot (Flickering) is defined as “A cell which repeats On and Off” ☞3) Uncontrollable Dot is defined as “A cell which is distinctly brighter or darker than other cells around it”...
42” HD Cell Defect Specifications ☞1) Non-Ignition Dot(Dark Defect) is defined as “A cell of which more than 50% area is not ignited” ☞2) Unstable Dot (Flickering) is defined as “A cell which repeats On and Off” ☞3) Uncontrollable Dot is defined as “A cell which is distinctly brighter or darker than other cells around it” and/or “A cell of which color is distinctly different from that of other cells around it”...
50” HD Cell Defect Specifications ☞1) Non-Ignition Dot(Dark Defect) is defined as “A cell of which more than 50% area is not ignited” ☞2) Unstable Dot (Flickering) is defined as “A cell which repeats On and Off” ☞3) Uncontrollable Dot is defined as “A cell which is distinctly brighter or darker than other cells around it” and/or “A cell of which color is distinctly different from that of other cells around it”...
8. MECHANICAL 8.1 Fan Fans N/A (No Fans are used in the unit) 8.2 Dimensions (without stand) Model Name NP-42S5 NP-42H5 NP-50H5 Width 1028mm 1028mm 1205mm Height 625mm 625mm 721mm Depth 89.8mm [A-type] 107.4mm 114.3mm[C-type] 107.4mm[B-type] 114.3mm[D-type] 8.4 Weight(without stand)
800~1100hpa (Altitude : 0 ~ 2,000 m) Storage Atmospheric Pressure 700~1100hpa (Altitude : 0 ~ 3,000 m) 10. PACKAGING 10.1 Package Specifications Model Name NP-42S5 NP-42H5 NP-50H5 The ink shall not rub off after a suitable drying time. Shipping Carton Type One Piece Construction...
11. AUDIO SYSTEM 11.1 External Speaker System (Option) NP-42S5 NP-42H5 NP-50S5 Dimension(W × H × D) 113 mm × 626.6 mm × 82.2 mm 90 mm × 721 mm × 68 mm Weight 5 kg (L+R) 3 kg (L+R) Type...
Page 38
Control Board Ver.01 INPU 2006.03.16 MENU - VOL + - CH + E2PROM Flash ROM RS-232C EEPROM(DDC) I2S HDMI AUDIO LVDS1 HDMI HDMI IN HDMI Input 24BIT RGB EEPROM(DDC) LG PDP TMDS LVDS2 PANEL MST3388M RGB_IN RGB Input SCALER PW218 Component_1IN 2LED COMPONENT1...
Page 39
Project : 218 Main Version : A1 Date Date Date CONFIDENTIAL CONFIDENTIAL CONFIDENTIAL Friday, February 10, 2006 Friday, February 10, 2006 Friday, February 10, 2006 Title Title Title Sheet Sheet Sheet Size Size Size Document Number Document Number Document Number <Doc>...
Page 49
Stby_5V Stby_5V Mechanical EMI용 저항 MMBZ5V6ALT1 MMBZ5V6ALT1 MMBZ5V6ALT1 MMBZ5V6ALT1 T NS T NS T NS T NS //BAV99 //BAV99 //BAV99 //BAV99 BAV99 BAV99 R619 R619 R620 R620 Detect : HIGH AV1_DET AV2_DET JACK4 JACK4 RCA-623(GBRx2) RCA-623(GBRx2) R623 R623 R621 R621 AV2_CVBS_IN 1 FB14 FB14...
Page 50
[NP-42S5**] TANGO TRI-BOM 06. 03. 20 March. 20. 2006 Kim Myung Kyu Part Code Part Name Description Q'ty Remark PPM42V7M462 PDP Module PDP42V7M462(V7 SEM) RPFG42SSSC7 Filter Glass PS08OZ001 RPBAMA42STR Board Ass`y Main SIGMACOM TANGO_TRI 42"SD MAIN Board Ass`y RPBASUTRI00 Board Ass`y Sub...
Page 51
[NP-42H5**] TANGO TRI-BOM 06. 03. 20 March. 20. 2006 Kim Myung Kyu Part Code Part Name Description Q'ty Remark PPM42X32000 PDP Module PDP42X32000 (X3 HD Ver.) RPFG42SSSC7 Filter Glass PS08OZ001 RPBAMA42STR Board Ass`y Main SIGMACOM TANGO_TRI 42"SD MAIN Board Ass`y RPBASUTRI00 Board Ass`y Sub SIGMACOM TANGO_TRI SUB Board Ass`y...
Page 52
[NP-50H5D*] TANGO TRI-BOM 06. 03. 20 March. 20. 2006 Kim Myung Kyu Part Code Part Name Description Q'TY Remark PPM50X34012 PDP Module PDP50X34012 (50 X3 Rev.01) PFG50NAA05 Filter Glass FG510NAA-05 PBAMA50HTR Board Ass`y Main SIGMACOM TANGO_TRI 50"HD MAIN Board Ass`y PBASUTRI00 Board Ass`y Sub SIGMACOM TANGO_TRI SUB Board Ass`y...
Page 53
[NP-50H5C*] TANGO TRI-BOM 06. 03. 20 March. 20. 2006 Kim Myung Kyu Part Code Part Name Description Q'TY Remark PPM50X34012 PDP Module PDP50X34012 (50 X3 Rev.01) PFG50NAA05 Filter Glass FG510NAA-05 PBAMA50HTR Board Ass`y Main SIGMACOM TANGO_TRI 50"HD MAIN Board Ass`y PBASUTRI00 Board Ass`y Sub SIGMACOM TANGO_TRI SUB Board Ass`y...
Page 58
1. Coverage These specifications apply to PDP-TV products manufactured by WoosungNextier Corp. 2. Applicable Models: TRI MODEL (NP-42S5, NP-42H5, NP-50H5 Series) General Instructions This inspection is subject to change depending on the scale of the mass-production. However, any changes should be based on reasonable requests from the production departments and decisions by the research departments through appropriate review.
Page 59
6. Inspection of Standardization 6.1 General Specification 1) In/Out Terminals Spec. 2) Speaker Output Spec. 6.2 Inspection of Standardization 1) Pattern 2) Speaker Output 3) Input 6.3 Inspection of Circuit Functions 1) LED On/Off Test 2) KEY PAD / REMOTE CONTROL Test 3) TV Input 4) VIDEO Input 5) S-VIDEO Input...
Page 60
6.4 Out Going Specification 1) Menu Mode Setting...
Page 61
7. Inspection Method 1) In/Out Terminals Spec. ITEM SPECIFICATION RS-232C TXD/RXD(1:1) 3.5MM JACK x 1 Digital RGB : TMDS (Videl + Audio) HDMI Jack x 1 MAX : Video – 720p, 1080i (Type A) HDMI Input Audio - 48kHz / 2 Channel (L + R) Audio : 0.5V[rms](Normal)/2 Channel (L+R) RCA Jack x 1 Analog RGB : 0.7V[p-p](75Ω), H/CS/V:TTL(2.2 kΩ),...
Page 63
7.2 Inspection of Standardization 1) TEST PATTERN (1) MONO SCOPE ITEM Condition Standard MONOSCOPE Resolution 400 (H) or Higher Normal Screen Mode OVER SHOOT Same as above Recognizable PRE SHOOT ″ ″ More than±120lines and less than Horizontal ±480lines Synchronous Lead-in MONOSCOPE Range More than –15 lines and less than –9...
Page 64
(2) Stair 10-Steps - Check the left/right black/white patterns for saturation (Brightness, Contrast test) - Should be saturated less than Step 2 black and less than step 2 white to the left and to the right. - Check if any unnecessary chrominance signals other than black and white enter the picture. - No distortion or noise on the screen <...
Page 65
(4) Multi Burst - Check frequency response for the range. - Check the screen for any distortion or noise. < Multi burst> Color System NTSC, NTSC-4.43MHz PAL, PAL-M, PAL-N, SECAM Multi-Burst 0.5-1.0-2.0-3.0-3.58-4.2MHz 0.5-1.0-2.0-3.0-4.0-4.8MHz Frequency Frequency Within 1.0dB Within 1.0dB characteristic Setup 7.5%NTSC only White REF Signal...
Page 66
(5) Cross Pattern - Check the horizontal/vertical lines for any loss. - Check that the intervals between the crosshatches are regular. - Check the screen for any distortion or noise. < Cross Pattern 16:9> Aspect ratio 16:9 White Level 0%setup White Level 0%setup 714.3mV 700.0mV...
Page 67
(6) 64-gradation block glay - Check each splinter for saturation areas. - Check the brightness and contrast for differences. - Check the screen for any distortion or noise. <64-Gradation Block Gray> (7) Crosshatch & circle & gray <Crosshatch & Circle & Gray>...
Page 68
- Check the crosshatches for any loss in the horizontal/vertical lines. - Check that the intervals between the crosshatch lines are regular. - Check if the circle is properly displayed. - Check the brightness and contrast based on the gray patterns on the screen. - Check for any distortion or noise on the screen.
Page 69
<8-black Crosshatch> (10) Display Position < Display position> - Check to ensure that the corresponding areas at the top, bottom, right and left are balanced, based on the vertical line in the center. - Check if the central horizontal line matches the physical center of the PDP panel. - Check for any distortion or noise on the screen...
Page 70
(11) SMPTE RP-133 - Check the cross patterns for any loss. - Check if there is any problem dealing with high frequencies. - Check multi-burst for its signal frequencies. - Check for any distortion or noise on the screen. < SMPTE RP-133> (12) 256Gray+RGBW Color Bar - Check each color bar for the boundary nesting.
Page 71
※ Patterns (1) to (5) are based on signals from ShibaSoku (TG 848). ※ Patterns (1) to (5) are applied to VIDEO, S-VIDEO, SCART or TV Input. ※ Patterns (6) to (12) are based on signals from ASTRODESIGN (VG-848). ※ Patterns (6) to (12) are applied to RGB, DIV or Component Input. 2) Speaker Output Item Condition...
Page 72
3) Input Input Condition Standard Digital RGB No distortion or noise on the screen HDMI Input Audio Audio In No distortion or noise in the audio output Video Input V Signal No distortion or noise on the screen Y Signal No distortion or noise on the screen S-Video Input C Signal...
Page 73
7.3 Inspection of Circuit Functions 1) LED 0n/Off Test (1) Check if the red LED indicating the standby status lights is out when connected to the power. (2) Check if the green LED indicating the operation status lights is out when the power switch is turned on 2) KEY / REMOCON Test Press the front keys and the MENU key on the remote control and...
Page 74
(7) Check that broadcasting of TV is accordant with TV frequency by pushing “Auto Searching” in remocon. (8) Check that video signal of TV mode in screen is OK. (9) Choose “Add” or “Delete” through Add/Delete Key. (10) Choose “Detail adjustment” through Fine. (11) Check that changing channel is O.K through pushing “control key”...
Page 75
4) VIDEO Input (1) Connect the video input signals to the VIDEO Input terminals using the RCA cable. (2) Turn on the power by pressing the front key or the POWER key on the remote control. (3) Select “Video” port using front panel button or Remote Controller. Input Sources AV1 (AV2) (4) Check if the video signals display properly on the screen for each mode.
Page 76
6) COMPONENT Input (1) Connect the Component Video Input terminal to the video signal generator’s output terminal using the RCA cable (2) Connect the Audio Output terminal of the video signal generator to the Component Audio Input using the RCA cable (3) Turn on the power by pressing the front key or the POWER key on the remote control.
Page 77
Horizontal Frequency Vertical Frequency Pixel Clock Mode Resolution (kHz) (Hz) Frequency (MHz) SDTV 480i 720 x 15.730 29.970 13.5000 SDTV 576i 720 x 15.630 25.000 13.5000 SDTV 480p 720 x 31.470 59.940 27.000 SDTV 576p 720 x 31.250 50.000 27.000 44.964 59.94 74.176...
Page 78
Horizontal Frequency Vertical Frequency Pixel Clock Frequency Mode Resolution (kHz) (Hz) (MHz) 31.469 70.087 25.175 640 x 350 37.861 85.08 31.5 640 x 400 37.861 85.08 31.500 31.469 70.087 28.322 720 x 400 37.927 85.039 35.5 31.460 50.000 25.170 640 x 480 31.500 60.000 25.175...
Page 79
Horizontal Frequency Vertical Frequency Pixel Clock Frequency Mode Resolution (kHz) (Hz) (MHz) SDTV 480p 720 x 480 31.470 59.940 27.000 SDTV 576p 720 x 576 31.250 50.000 27.000 44.964 59.94 74.176 HDTV 720p 1280 x 720 45.000 60.00 74.25 33.750 60.0 74.25 33.176...
Page 80
9) Picture Menu (1) Enter into “Picture Menu” by pushing “front Key” or “Menu Key of Remocon.” Picture Size Picture Mode Brightness Contrast Sharpness Tint Color Color Tone (2) Check that any mode you can control is O.K by pushing front key or key of remocon. - Size : Wide/Panorama/Zoom/4;3/14:9 - Picture Mode : Standard/Movie/Mild/Custom/Dynamic You can enter into “Custom Mode”...
Page 81
11) Sound Menu (1) Enter into “Sound Menu” by pushing front key or “menu key” of remocon. Sound Sound Mode Equalizer Auto Volume (2) Check that any mode you can control is O.K by pushing front key or key of remocon. - Sound Mode : Standard / Music / Movie / Speech / Custom You can enter into “Custom Mode”by pushing “Enter key”...
Page 82
12) Setup Menu (1) Enter into “Setup MENU” by pushing “the front key” or “Menu Key” of Remocon. Setup Time Blue Screen Language Screen Wiper Pixel Shift Caption V-Chip (2) Time : You can enter into Sub Menu by pushing “Enter Key”. Clock : Setting on current time On Timer : TV is automatically on when it is appointed.
Page 83
16) Remocon Key Test Function (1) MUTE : Once it is pushed there is no sound. Once it is pushed again it return to default. (2) Source Select - TV : TV Hotkey - PC/HDMI : PC/HDMI Hotkey - AV.SEL : Component, S-Video, Video Source toggle - SOURCE (3) Screen Function - PIC.SIZE : Controlling Screen Size...
Page 84
7.4 Out Going Specification 1) Menu Mode Setting (1) TV, Video, S-Video, Component Input Menu Function Default REMARK Picture SIZE WIDE PICTURE MODE STANDARD BRIGHTNESS CONTRAST SHARPNESS TINT COLOR COLOR TONE NORMAL Sound SOUND MODE STANDARD EQUALIZER AUTO VOLUME SETUP TIME BLUE SCREEN Language...
Page 85
(2) TV INPUT Menu Function Default REMARK CHANNEL Color System AUTO Air/Std/Hrc/Irc Auto Search Add/Delete Fine Tune < Chart 2 > ※ Picture, Window, Sound, Setting Menu is the same condition as Chart 1.
Page 86
※TV Broadcasting System ( )※ Country Afghanistan Madeira China Argentina Brazil Angola Albania Majorca islands Korea Paraguay Botswana Algeria Malaysia, Malawi (North) Uruguay Hong Kong Australia Mozambique South Africa Austria, Azores Netherlands Zanzibar Bahrain New Zealand Bangladesh Nigeria, Norway Oman Brunei, Cameroon Pakistan Canary Islands...
Page 88
PDP TV Firmware Update A. The method of Firmware update 1. Remove AC Power Cord from PDP for Power Off. 2. Connect the serial cable with between PC-TV. - Connect the D-Sub Conn of cable of Main FW update being provided to PC Connect 3.5mm Jack to PDP-TV.
Page 89
6. Sellect the port of PC and the speed of communication. (It can be adjustable per setting of PC) 7. Sellect installing " Inf file". Sellect "WARE3_boot.inf" at this time.
Page 90
8. Connect Power Cord by pushing "Flash" button. Connect Power Cord of your TV...
Page 91
펌웨어 업데이트가 진행됩니다. Updating firmware is done completely. 9. Disconnect the updated cable. The Power of TV can be On according to above Options at this time.
Page 92
B. TV System Reset You must do system reset after updating the firmware of main board. 1. Push the button as following order after Power On in TV. MUTE -> SLEEP -> PIC.MODE -> MENU -> INFO(ENTER)
Page 93
2. Following as below 1. Calibration 2. Option Table 3. Color Control 4. Device Adjustment 5. Heatrun 6. Version 7. Reset 3. Check firmware update by choosing the 6.Version. 4. Do reset by choosing the "7.Reset" 7. Reset Press Enter To Reset Factory Default...
Page 94
