Method 2: Wired frames
We recommend watching a video of
the embedding process before
starting:
youtu.be/a-ElrV6SR4s
Step 1: Assemble and wire frames.
Assemble frames using preferred method of
assembly (nails, staples, etc.).
Prior to wiring, consider how the wire will be
heated. The ends of the wires need to be
positioned so they can be electrified by a 12-
volt power source. An illustration is shown
below.
Deep Frame Wire Routing:
Medium or Shallow Frame Wire Routing:
Use quality steel frame wire between 26 and
28 gauge. Install eyelets in side bars, thread
wire, and then stretch wire tight. Anchor firmly
with a wedge nail at each end. Wire frames
completely: 4 wires for deeps, or 2 wires for
mediums. Use two nails to anchor the wire
such that the wire is an "open circuit" that
can be electrified with 12 volts. See
illustrations above.
Betterbee • 8 Meader Rd, Greenwich, NY 12834 • (800) 632-3379 • betterbee.com
Step 2: Prepare Comb.
Determine orientation of comb as described in
previous section. Set the comb on the
installation shim, making note of which side is
the top. Place the wired frame on top of the
comb so that the wires rest on the comb, and
double check that the cell orientation is correct
with respect to the top of the frame.
Step 3: Embed Wires.
Slide the frame into contact with the 12-volt
power source. The wires will heat up
immediately. Press down on the frame until all
wires melt into the center wax core of the
comb. Slide the frame away from the power
source, and allow the wires to cool for two to
three seconds.
