NexSens G2-HYDROMET Quick Start

G2-HYDROMET Quick Start

For best results, setup your new product in the office/lab. Collect a few
data points and become familiar with the system prior to field deployment.
1 Go to V2.WQDataLIVE.com/Getting-Started
2 Create a new account or sign into an existing
account and enter the Claim Code found on
the serial label to access the device's data
3 Place the HYDROMET in an area with strong
cellular coverage and connect the antenna
4 Connect the Solar Pack's UW-6 to the
HYDROMET's UW-6 pigtail to power the device
(device will beep once when powered)
5 Refresh WQData LIVE and confirm the Diagnostic
Data Last Contact timestamp has been updated
(May take up to 1 minute*)
6 Deploy the device by screwing it onto a
leveled 2" NPT pole and orienting it
north using the Airmar alignment mark
7 Angle the solar panel by removing the
outter angle adjustment bolt with the
included 3/16" hex wrench, tilting to the
desired angle (30° or 45°), and replacing the bolt
Connect Optional Hydrological Sensor
8 Connect the Hydrological sensor to the UW-8 pigtail
9 On WQData, click the G2-HYDROMET's
righthand Site List panel to access the Remote Device
Configuration dialog and queue a Detect Sensors and Sensor
Read command (check the boxes and click SAVE)
10 Cycle power (UW-6 pigtail) to
execute the remote command
11 Confirm the new parameters
are online (May take up to 3
minutes for detection and
upload)
icon in the
Serial Label
