Summary of Contents for Vesta Precision Imersa Tower
- Page 1 Imersa Tower User Manual Precision Appliance Technology, Inc. Website: www.vestaprecision.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION ............. 2 BENEFITS OF COOKING SOUS VIDE ............. 3 OVERVIEW OF COOKING SOUS VIDE ..........3 PRODUCT COMPONENTS ..............4 CONTROL PANEL ................... 6 CONNECTING WI-FI ................9 COOKING SOUS VIDE ................. 10 MAINTENANCE ..................12 HOW TO DESCALE ................ -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION When using this electrical appliance, basic safety precautions should always be followed including: 1. Read and understand all instructions. 2. Operate the appliance indoors only on a dry, stable, hard surface. 3. Connect to a grounded outlet of the correct rating only. 4. -
Page 4: Benefits Of Cooking Sous Vide
BENEFITS OF COOKING SOUS VIDE Developed in France in the 1970s, sous vide is a culinary technique in which food is vacuum-sealed and cooked in a water bath at a consistent low temperature for an extended period of time. Ideal for families with busy schedules and health-conscious lifestyles, sous vide cooking delivers easy meal solutions that make dinnertime virtually foolproof. -
Page 5: Product Components
PRODUCT COMPONENTS ○ ○ ○ ○ ○ 1. Control Panel 2. Quick Screw 3. Main Body 4. Water Inlet 5. Pump Outlet... - Page 6 ○ ○ ○ ○ ○ 6. Handle 7. Vents 8. Quick Screw 9. Screw Clamp 10. Water Inlet...
-
Page 7: Control Panel
CONTROL PANEL 1. Power Button When plugged in, all buttons and indicators will flash for 2 seconds before the device enters power saving mode (with only the “Power” button illuminated). When the device is in power saving mode, press the “Power” button to activate standby mode. - Page 8 3. Temperature and Timer Selection Button (Temp/Time) Press the “Temp/Time” button to toggle between setting temperature or time. When pressed once, the temperature display blinks and pressing “+” or “–“ sets the target temperature. When pressed a second time, the timer display blinks and pressing the “+”...
- Page 9 5. Temperature and Timer Adjusting Buttons (- Press the “Temp/Time” to select which value to set, then press “+” or “-” to adjust to the target temperature or time. 6. Current Temperature Display (Upper) 7. Target Temperature Display (Lower) 8. Timer Display When in standby mode, the target time is displayed.
-
Page 10: Connecting Wi-Fi
3. Open the Vesta app and register or login to your account. 4. Plug in the Imersa Tower and press the Power button to switch to standby mode. While logged in to the app with the Imersa Tower in standby mode…... -
Page 11: Cooking Sous Vide
COOKING SOUS VIDE 1. Select an appropriate sized container and fit the Imersa Tower to the side. a) Secure the device to the side of the container by pressing the Control Panel Release button (Product Component ④) to rotate the Control Panel up (open the gap between it and the main body). - Page 12 9. When the water reaches the target temperature, the device will beep for 3 times. Place the vacuum-packed food into the water. 10. Press the “Start/Stop” button to start the timer. The Flames icon will continue to glow signifying the heater and pump are running.
-
Page 13: Maintenance
MAINTENANCE To avoid possible injury from hot surfaces, please power off the appliance and allow it to cool down before performing any maintenance. Place the device vertically after cleaning to allow it to drain completely, do not place it horizontally or upside down. Do not use abrasive cleansers or scouring pads to clean the machine to avoid scratching the surface. - Page 14 How to Disassemble 1. Loosen two knobs on each side. Undo each side 2. Carefully slide the stainless steel housing down to expose the pump, heating coil, and temperature probes. 3. Clean any scale and build up from the exposed components with a mild detergent and soft sponge or brush.
-
Page 15: How To Descale
HOW TO DESCALE Dissolved minerals in water can adhere to the metal components inside your Imersa Tower and over time will adversely impact its performance. Periodic cleaning and descaling will keep your device in top working order. 1. Fill a container with 75% water/25% vinegar mixture up to the “MAX”... -
Page 16: Troubleshooting
TROUBLESHOOTING Error Code Cause Troubleshooting Steps If the water level is too low, The water level is appropriate lower than amount of water to the Minimum level or container. If the water level is higher than the high, remove some Maximum level water from the container. -
Page 17: Technical Parameters
TECHNICAL PARAMETERS Rated voltage: 110-120 V~ / 220-240 V~ Rated frequency: 60HZ / 50HZ Rated power: 1800 W / 2300 W Temperature Range: 5 - 95 °C / 41 - 203 °F Time Range: 5 min to 99 hours Accuracy: ±.1 °F Size: 2.9x4.8x13.5 in (73x122x344mm) Weight: 1.7 lb. -
Page 18: Limited Warranty And After Sales Service
• Full refunds can only be provided within 30 days of purchase directly from Vesta Precision. Devices purchased through resellers, retail partners, or other websites are not eligible for a return and full refund. Please consult their return policies for more information. -
Page 19: Warranty Replacements
Retail exchanges can only be provided within 30 days of purchase directly from Vesta Precision. Products purchased through resellers, retail partners, or other websites are not eligible for a retail exchange. Please consult their exchange policies for more information. We cannot provide a retail exchange for any damaged devices not covered under our limited warranty. -
Page 20: Damaged And Defective Items
Damaged and Defective Items If you received a damaged or defective product, notify us immediately for assistance via phone, email, or web support. Please note that if we do not have an exact replacement for your unit, we will replace it with a similar unit of equal or greater value. What Does This Limited Warranty Not Cover? This limited warranty does not cover damages directly or indirectly arising or resulting from or during... - Page 21 Precision Appliance Technology, Inc. Questions or Problems? Contact support via Website: www.vestaprecision.com Email: support@vestaprecision.com...
