SET UP
GUIDE
ELECTRIC VEHICLE
SERVICE EQUIPMENT
(EVSE) TEST SYSTEM
PRODUCT:
CATALOG NO. TS400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS400 and is the answer not in the manual?

Questions and answers

Related Manuals for Tesco TS400

Summary of Contents for Tesco TS400

  • Page 1 SET UP GUIDE ELECTRIC VEHICLE SERVICE EQUIPMENT (EVSE) TEST SYSTEM PRODUCT: CATALOG NO. TS400...
  • Page 2 ELECTRIC VEHICLE SERVICE EQUIPMENT (EVSE) TEST SYSTEM QUICK SETUP GUIDE CATALOG NO. TS400 © 2021 TESCO - The Eastern Specialty Company All Rights Reserved. Specifications are subject to change without prior notice. Revision TESCO – The Eastern Specialty Company 925 Canal Street Bristol, PA, 19007 Phone: 215.228.0500...
  • Page 3 SETUP GUIDE 1.1 Introduction TESCO’s CAT. TS400 Electric Vehicle Service Equipment (EVSE) Test System is a complete system that consists of the CAT. T4000 EVSE Tester and the CAT. PL4000 Programmable Load, which tests the accuracy of energy delivery using a transactional mode compatible with HB44 provisions both for AC and DC.

  • Page 4: General Safety Summary

    This manual contains information and warnings that must be observed to ensure safe operation and keep the TS400 in a safe condition. Operation or service in conditions or in a manner other than specified could compromise safety. For the correct and safe use of this device, it is essential that both operating and service personnel follow accepted safety procedures in addition to the safety precautions specified, including PPE guidelines.
  • Page 5 SETUP GUIDE 1.6 T4000 Front Panel View NAME J1772 DUO Inlet CHADEMO Inlet TESLA Inlet Auxiliary Power 7”, 1024x600, high brightness, daylight readable LCD RS232 Com Port Ethernet Com Port USB A Port USB B Port Function Keys Navigation Keys Alphanumeric Keys Power Button Air Inflow...
  • Page 6 SETUP GUIDE Navigation Keys SYMBOL DESCRIPTION • Selects the NEXT or PREVIOUS menu item • Moves the SELECTED LINE UP or DOWN • Selects an Item from a dropdown menu • Moves the cursor left/right of the current character in text boxes •...
  • Page 7 SETUP GUIDE 1.7.1 PL4000 Front Panel NAME Power Status Indicator Communication Status Indicator Load Status Indicator Left Fan for Load Heaters (Big Fan 1) CombiTac Connector CombiTac Park Station Holder Strap Handle CombiTac Conduit Holder Right Fan for Load Heaters (Big Fan 2) Fan for Variable Load (VL) Controller (Small Fan) Table 1.2 PL4000 Front Panel Sections...
  • Page 8 CAT. PL4000 Programmable Load COMBITAC cable Figure 1.0 Suggested TS400 Setup sitting on the ground. WARNING PL4000 air outflow can be extremely hot particularly when testing at higher load current or power. Please allow a separation distance between the T4000 and PL4000 of at least 2 feet (0.7 meters) making sure that the COMBITAC cable doesn’t obstruct air outlet.

  • Page 9: Cooling Considerations

    PL4000 air outflow can be extremely hot particularly when testing at higher load current or power. Please allow back space of at least 6.5 feet (2 meters) for the PL4000 air outflow. Figure 1.1 TS400 Airflow 1.8.3 Cooling Considerations CAUTION Damage caused by overheating may occur if the area around the air intake is restricted, the intake air is too warm, or the air filter becomes clogged.

  • Page 10: Connection And Power-Up

    SETUP GUIDE 1.9 Main and Auxiliary Power Supply The Instrument is powered by an internal rechargeable battery. The battery charge status icon can be seen in the top right corner of the T4000 LCD screen. The battery can be easily removed and replaced in the field with a spare one (sold separately).
  • Page 11 SETUP GUIDE 1.10.2 Power-Down and Sequence of Disconnection WARNING T4000 must be turned off properly before the connectors are disconnected. To turn off T4000, return to Main Menu and press the power button for at least 2 seconds. A dialog box appears to confirm shutdown. Disconnect the Coupler of EVSE to the J1772 connector of T4000.
  • Page 12 SETUP GUIDE 1.11 GUI Screen Sections Upon powering on the T4000, you will find the following Graphical User Interface. The user interface is divided into four sections. In the screen, any field or button that is grayed out cannot be changed or accessed by the user. NUMBER DESCRIPTION Screen Title...

  • Page 13: Manual Mode

    SETUP GUIDE 1.11.2 MANUAL MODE SCREEN DESCRIPTION MANUAL MODE SELECT CONNECTION TYPE FUNCTION KEYS Select CCS1 (AC & DC) connection CCS1 type Select Chademo connection type CHADEMO Select Tesla connection type TESLA SELECT CHARGE TYPE FUNCTION KEYS Select AC charging type Select DC charging type SELECT TEST TYPE FUNCTION KEYS...
  • Page 14 SETUP GUIDE SCREEN DESCRIPTION ACCURACY TEST FUNCTION KEYS START Starts the Manual Test Wait until the test completes and the Test Results shows. FUNCTION KEYS BACK Returns to the previous screen +1 215 228 0500 tescometering.com support@tescometering.com...
