Atco LPX-1000 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Revision A.0
Copyright © 2008-2012 ATCO. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPX-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atco LPX-1000

  • Page 1 Revision A.0 Copyright © 2008-2012 ATCO. All Rights Reserved.

  • Page 2: Table Of Contents

    Recommended Spare Parts ............. 11 Copyright © 2008-2012 ATCO. All Rights Reserved.

  • Page 3: System Introduction

    LPX-1000 scanner system for field use. Section 1 Introduction Section 2 Scanner Components This section describes some of the components of the LPX-1000 system. It is recommended that you read this section and familiarize yourself with the system. Section 3 Scanner Field Use and Operation This section describes important information about the field use of the system and should be read prior to use in the field.

  • Page 4: System Components

    LPX-1000 Scanner System User Manual Section 2 System Components This section describes the components that make up the LPX-1000 System. Reading this section will help you to become familiar with the parts of the system. Scanner Y Axis Pivot Adjustment...

  • Page 5: Clamping Chain

    Combinations of links will accommodate virtually any diameter of pipe. Links Use the table in Appendix C to determine the combination of links required for the diameter piping Rubber Tires you are working with. Copyright © 2008-2012 ATCO. All Rights Reserved. Page 3 Revision A.0 850-004134...

  • Page 6: Scanner Field Use And Operation

    Section 2 Scanner Field Use and Operation This section describes some essential considerations and guidelines for using the LPX-1000 Scanner System in the field. It is recommended that you read this section thoroughly prior to using the scanner in the field.
  • Page 7 The number of links specified in the table do not include the short links that are attached to each side of the LPX-1000 (shown right). Once the number of long and/or short links has been determined, connect them all by hooking the ends of the links together (shown right).

  • Page 8: Adjusting The Y-Axis

    1/4-28 x 1 ½" Socket Hd Screws 6-32 x ½” Socket Hd Screws 6-32 x 3/8" Socket Hd Screws Copyright © 2008-2012 ATCO. All Rights Reserved. Page 6 Revision A.0 850-004134...
  • Page 9 The scanner can be moved using the arrow keys on the MCU-P500 by using the A-JOG menu option. The orientation and movement direction for each arrow key is shown below. Copyright © 2008-2012 ATCO. All Rights Reserved. Page 7 Revision A.0...

  • Page 10: Maintenance And Storage

    The sprocket must be pulled back to allow the slide block to move past the sprocket (Figure 14). Without moving the sprocket, the belt mounting clip cannot move past it. Belt Mounting Clip Slide Sprocket Back Figure 14 Copyright © 2008-2012 ATCO. All Rights Reserved. Page 8 Revision A.0 850-004134...
  • Page 11 (Figure 16). Belt Clip Mounting Point Screw Spacing for Screw Figure 17 Fastening the Belt Clip Copyright © 2008-2012 ATCO. All Rights Reserved. Page 9 Revision A.0 850-004134...
  • Page 12 Tension the Belt and Secure the Screws bracket. on the Sprocket Plate DO NOT OVERTENSION THE BELT! Figure 20 Tensioning the Belt Copyright © 2008-2012 ATCO. All Rights Reserved. Page 10 Revision A.0 850-004134...

  • Page 13: Y Axis Drive Belt Tension

    The Y Axis drive belt must be secure, but not over-tightened. There should be minimal play in the transducer slide block. X Axis Maintenance The X Axis should be inspected prior to use. Copyright © 2008-2012 ATCO. All Rights Reserved. Page 11 Revision A.0 850-004134...
  • Page 14 ENC A + ENC B - ENC B + Y-Axis (DB9M) PIN # Description MTR - MTR + ENC A - ENC A + ENC B - ENC B + Copyright © 2008-2012 ATCO. All Rights Reserved. Page 1 Revision A.0 850-004134...
  • Page 15 LPS-1000 Scanner System User Manual Appendix B Transducer Mounting Plate Bolt Hole Dimensions 6-32 (8 PLCS) 0.500 0.688 1.563 1.750 2.250 Copyright © 2008-2012 ATCO. All Rights Reserved. Page 1 Revision A.0 850-004134...
  • Page 16 15.25 16.13 17.625 18.5 19.25 Short Long 20.875 21.625 22.375 23.25 24.75 25.5 Short Long 26.375 27.25 28.75 29.5 30.375 31.125 Short Long 32.75 33.5 34.25 Short Long Copyright © 2008-2012 ATCO. All Rights Reserved. Page 1 Revision A.0 850-004134...
