EZR33L SERIES QUICK GUIDANCE
EZR33L SERIE SCHNELLLEITUNG
EZR33.OutdoorRouter.com/v/33l
Scan QR code or visit URL link to see the
complete edition of the online manual.
Scannen Sie den QR-Code oder besuchen Sie den URL-Link,
um die vollständige Ausgabe des Online-Handbuchs zu sehen.
PACKAGE CONTENTS
PACKUNGSINHALT
Check and count the package contents.
STEP
1.1
Outdoor Router
4G & Wi-Fi Antennas
Außen-Router
Rundum-Antennen
PLUG
for UK / EU
/ US / AU
PoE Injector
L-Bracket & T-Wrench
PoE-Injektor 48Volt
Halterung & Schlüssel
INTERFACE OVERVIEW
PORTS & SCHNITTSTELLEN AM ROUTER
1
4G ANTENNA
MAIN
HEXAGON
BOLT
STEP
2.4
CLOSE THE ENCLOSURE
Use T-wrench to tighten
bolts in clockwise direction
2.4G ANTENNA
4
BREATHER VALVE
ARE EMBOSSED NUMBERS
1
~
6
ON THE ENCLOSURE
10-Meter LAN Cable
LAN-Kabel 32,8-Fuß
Mounting Kit
Montagesatz für außen
3
4G ANTENNA
LOCKHOLE
STEP
1.2
OPEN THE ENCLOSURE
Use hexagon head on the
T-wrench to lose bolts in
anti-clockwise direction
6
2.4G
ANTENNA
5
GLAND
5MM HEX
T-WRENCH
