- Page 1 I n s t a l l a t i o n I n s t r u c t i o n s D E S I G N A S M A R T M O V E V e r s i o n : 1 .
- Page 2 Grenzen des Urheberrechtsgesetzes ist ohne system, or translated into any language in any form by any Zustimmung der DESIGNA Verkehrsleittechnik GmbH means without the written permission of DESIGNA unzulässig. Dies gilt insbesondere für Vervielfältigungen, Verkehrsleittechnik GmbH. Übersetzungen, Mikroverfilmungen und die Einspeicherung...
-
Page 3: Table Of Contents
Connecting the beacon in the DCT casing body ........... 17 CONFIGURING THE IN AND OUT DEVICES ..............18 Configuration at the factory ....................18 Retrofitting the IN and OUT devices with SMART MOVE ..........18 Decommissioning and disassembly ................... 19 Disposal ..........................19 VERSION OVERVIEW ...................... -
Page 4: General
DESIGNA parking management system and provides important information on the installation and configuration of the respective SMART MOVE components. Installation work may be carried out by skilled workers or DESIGNA trained and authorised electricians only. To ensure safe and reliable operation, please read this manual ... -
Page 5: Customer Service & Service
Customer service & service Your DESIGNA Service is available to you for technical information. For the address, see invoice, delivery note or imprint. In order to enable fast handling note the data of the type plate such as device type, order number, identity number, serial number, etc. -
Page 6: Safety
The smart device can be used to enter and exit car parks after prior registration. The beacons installed in the car parks communicate with the SMART MOVE app on your smart device via Bluetooth Low Energy. -
Page 7: Safety Standards
Scope of delivery Safety standards The SMART MOVE system has been tested according to the following standards: EN 300 328 V2.1.1 Standard on the use of the radio spectrum. EN 62479:2010 Assessment of the compliance of low power electronic and electrical equipment with the basic restrictions related to human exposure to electromagnetic fields (10 MHz to 300 GHz). -
Page 8: Smart Move System
SMART MOVE access data. Car park customers can then log into the SMART MOVE app using the access data sent to their email address stored in the system. The SMART MOVE server assigns a unique ID number to each user. Additionally, the app receives a list of available beacons from the SMART MOVE server. -
Page 9: System Requirements
ServiceDBeaconREST.svc/Callers/ System software In order to be able to use the SMART MOVE app, the data of the app user, e.g. email address, must be stored in the WinOperate system software. Further, to set up the app user in the system software, it is necessary for the operator to be given the appropriate user rights in the rights management. -
Page 10: Setting Up App Users
Setting up app users SMART MOVE app users are listed as customers in the WinOperate system software. A season parker card is also created in WinOperate for SMART MOVE users. To be able to identify themselves with the SMART MOVE app in the system, the email address of app users must be stored in the WinOperate customer master data. - Page 11 For the logged-in operator to be able to assign the card, the operator must have the appropriate user rights (see above). Using the Assign function, the SMART MOVE server generates a unique identification number (ETC number) for the season parker card.
-
Page 12: Technical Data
This identification number is subsequently used by the app to recognise the beacon. A label with the assigned ID number is affixed to the beacon box to guarantee correct beacon installation in the right lane. © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... -
Page 13: Installing Beacons In The Lane
If an ID number was not assigned to the beacon upon delivery, service technicians can reconfigure the identification number on site using a tool. After installation, remove the labels from the beacons. © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... -
Page 14: Installation
Contact with live components may result in death. Installation has to be carried out by electrical technicians or − DESIGNA electrical technicians or electrical technicians of DESIGNA trained and authorized dealers and partners. − Make sure that the power supply is externally disconnected and that it cannot be switched on. -
Page 15: Installing The Beacon Box On The Entrance /Exit Control Terminal
Two holes for installation on the device One hole for the cable duct Fig. 6: Beacon box installation on entrance /exit control terminal– holes (dimensions in mm) Open the beacon box to screw the box to the device. © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... - Page 16 Opened beacon box without any contents Mounting plate Casing body Glue the seal to the outside of the entrance /exit control terminal according to the holes Seal Fig. 8: Seal between device and beacon box © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx...
-
Page 17: Connecting The Beacon Box On The Entrance /Exit Control Terminal
Connecting the beacon box on the entrance /exit control terminal For data transfer (serial communication) and the power supply, connect the supplied cable to the SBC (Single Board Computer) and the beacon: Plug the 6-pole micro-match connector into the beacon. © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... -
Page 18: Example: Installing The Beacon In The Dct Casing Body
The second beacon box is located in the DCT casing body. Power is supplied by a battery. Fig. 11: Beacon in DCT casing body Attach the beacon box with hook-and-loop tape behind the acrylic glass panel of the DTC. © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... -
Page 19: Connecting The Beacon In The Dct Casing Body
Insert the batteries into the holder on the mounting panel. Connection Fig. 13: Connection of beacon in DCT to battery Plug the female connector onto the male connector of the beacon (as shown above). © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... -
Page 20: Configuring The In And Out Devices
The beacon (radio transmitter) on the device is connected to the SBC (Single Board Computer) via a serial interface. The parking data received from the beacon is forwarded to the DESIGNA system via the SBC. The DESIGNA system then sends the data to the SMART MOVE server. -
Page 21: Decommissioning And Disassembly
Configuring the IN and OUT devices Decommissioning and disassembly Disassemble the SMART MOVE components in reverse order to that described for installation (see Section 7.1. Installation) Disassemble the device into its individual parts. For decommissioning and disassembly, refer to the separate operator manuals of the devices. -
Page 22: Version Overview
Version overview Version overview Version 1.00 Creation of the document. 07/2020 (KS) Version 1.10 Adaptation to German version 09/2020 (KS) © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx... - Page 23 Version overview © DESIGNA Verkehrsleittechnik GmbH DESIGNA SMART MOVE_Installation_110_ENG.docx...
