User Manual V1.0
Bax Bangeetar Guitar Pre-EQ
Safety
Important Safety Information
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarised or grounding-type plug. A polarised plug has
Advertisement
Table of Contents
Summary of Contents for ORANGE Bax Bangeetar
- Page 1 User Manual V1.0 Bax Bangeetar Guitar Pre-EQ Safety Important Safety Information 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth.
- Page 2 The voltage selector switch and mains fuse are set at the factory for the country or region in which this Orange product is intended to be sold. To prevent serious damage to the product, ensure that the rated AC mains voltage indicated on the product's rear panel agrees with the mains voltage from your AC mains outlet before connecting the mains cord/plug.
- Page 3 Different operating voltages may require the use of different types of line cord and attachment plugs. If you are unsure, contact your Orange Dealer. This Orange product fulfils the requirements of IEC 60065:2001 (Seventh Edition) + A1:2005 + A2:2010 for Audio, Video and Similar Electronic Apparatus.
- Page 4 Adds CabSim filtering to the overall tone which emulates the sound and frequency curve of an Orange 4×12” cabinet. This is particularly useful for 3. CABSIM OUTPUT recording or plugging directly into a PA.
- Page 5 (regulated). The barrel plug should be a ‘standard 2.1mm pedal type’ with 13. DC a centre negative polarity (centre –). The maximum current draw of the INPUT Bax Bangeetar at 9 Vdc is 81 mA. Make sure the power supply meets these specifications.
- Page 6 QUICK START GUIDE The parametric mid controls are powerful tone-shaping tools and can be used to broadly affect the midrange response of your rig, or to fine-tune a narrow range of frequencies to your taste. ‘Cutting’ the frequencies you don’t want to hear can often be more effective than ‘boosting’ those you do want to hear.
- Page 7 The effect will depend on the Q. Again, use your ears! OUTPUTS The Bax Bangeetar’s two outputs can be used in a number of ways for both live and studio use: OUT connected to the input of a guitar amplifier as a boost/distortion/EQ pedal;...
