Summary of Contents for Raycus RFL-P500
- Page 1 版本号 密级 内部 阶段 标记 RFL-P500 会签 朱超 500W 脉冲光纤激光器 英文说明书 朱泓旭 RFL-P500·JS02 部 门 脉冲激光器技术研究部 编 写 刘 红 20210225 校 对 帅维文 20210225 审 核 李 科 20210225 标 审 李其军 20210305 批 准 黄 保 20210305 旧底图登记号...
- Page 2 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 RFL-P500 Pulsed Fiber Laser User Guide Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 3: Table Of Contents
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 TABLE OF CONTENTS 1 Safety Information ........................1 1.1 Security Warning ......................1 1.2 Laser Safety Grade ......................1 1.3 Safety Identification ......................2 1.4 Optical Safety ........................3 1.5 Electrical Safety ....................... - Page 4 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 7.3 Service and Repair ......................23...
-
Page 5: Safety Information
User Guide of RFL-P500 1 Safety Information Thank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly. -
Page 6: Safety Identification
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 1.3 Safety Identification Figure 1 : Safety identification position Table 1: Safety identification English Label（500W） English Label English Label Chinese Lable Chinese Lable Chinese Lable（500W） 3: Class 2M Laser Product... -
Page 7: Optical Safety
There are no user serviceable parts, equipment or assemblies inside the product. All service and maintenance shall be performed by Raycus. In order to prevent electric shock, please do not break the seal or uncover the shield. Failure to comply with this instruction will void the warranty. -
Page 8: Product Description
Please refer to package accessoriesare in the packing box. 2.3 Unpacking and Inspection Raycus fiber laser is delivered in a package, which is designed to offer the maximal safety. Upon the delivery, please inspect all packaging for evidence of mishandling or damage. If you find any evidence of mishandling, please keep the damaged material and contact the shipping agent and Raycus immediately. -
Page 9: Operation Environment
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 pull the output cable when unpacking the device; and avoid any collision to the head of laser output. CAUTION: The fiber optic cable and output head are precise optic instrument, ANY vibration or impact to the output head, and twist or excessive bend to the cable will damage the instrument. -
Page 10: Attentions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 2.5 Attentions a) Make sure that the correct voltage of 220V AC is used. Failure to connectly connect power supply will damage the device. b) The output laser is collimated by the collimating lens, it is important to keep the collimating lens clean, otherwise it will damage the device. -
Page 11: Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 Repetition 10-50 Frequency Red Guide Laser 0.1~1 Power Optical Output Characteristics of QBH head Output Fiber Core* Square Delivery Cable Length <25 mm*mrad Divergence Half <0.13 Angle Electrical Characteristics Power Supply AC 220V±... - Page 12 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500...
-
Page 13: Dimensions Of Output Head
User Guide of RFL-P500 Figure 2: Dimensions of 200W Product (unit:mm) 3.2 Dimensions of Output Head The output head of RFL-P500 is QBH, the following figure 3 show the details of the QBH output head. Figure 3 QBH Output head (unit: mm) CAUTION: a) Keep the protective cap properly, prevent it from contamination;... -
Page 14: Cooling Requirements
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 3.3 Cooling Requirements Table 4 Cooling Requirements Parameter Unit Value ≥1500 Cooling Capability Minimum Flow L/min Maximum Pressure Pagoda-Typepipe connector, Water-cooling pipe connector outside diameter 12mm a) Temperature setting of cooling water:25±1℃... - Page 15 Check the output head and clean it before installation. This procedure must be performed by Raycus personnel or person authorized by Raycus. f) Prevent the delivery cable from treading, pinching or excessive bending during installation.
-
Page 16: Using The Product
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 CAUTION: All the cables can only be connected when power supply is off. Hot plug may damage the device. CAUTION: a) Ensure that there are no fiber bends in radius less than 30cm when the product is installed. -
Page 17: Rear Panel
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 1. REM/OFF/ON: Key switch, the power switch of the laser. Insert the key and then turn the key clockwise to the 'ON' to active the laser. 2. POWER:Power Indicator, indicates that the power is switched on when the green LED illumines. -
Page 18: Power Connection
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 protective cover and a lock catch. Please use the protective cover and lock catch when not use the laser device. 2. POWER:Air switch. Controlling the on-off of AC. 3. CTRL-INTERFACE: Control interface. This interface provides all... -
Page 19: Interface Definitions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 Figure 6 : The Power Cord of the Laser One end of the power cord is a plug; insert it into the socket ‘AC INPUT’ on the rear panel when using the laser. Notice that the plug is wrong-side preventing. -
Page 20: 2Control Interface
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 Figure 7: SERVICE Definitions The pin definitions are shown in Table 5: Table 5: SERVICE Definitions Unit Definition Comments Equivalent front panel Remote key switch SWITCH. INTERLOCKA Six and seven legs need to be short-jointed before the laser is emitted. - Page 21 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 Table 6: DB25 Control Interface Definition Function Description Data parallel transmission 8bit，D0 is the lowest level，D7 is the highest level；Range：0-255 （Hexadecimal system：0X00-0XFF）； Power Settings 1-8（D0-D7） 0：Minimum power output； 255：Maximum output power Digital Grounding Aignal（Digital ）...
- Page 22 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 b) Pin 17 is an external 5V power input, which supplies power to the output optocoupler of the alarm signal; the input current is more than 20mA. c) The external input signals (Pin 1-8, 18, 19, 20, 22) of the laser are all connected with optocouplers inside the system to ensure that the input level is high in the range of 3.3V-5V and low in the range of 1.7V.
-
Page 23: Rs-232 Serial Port
Figure 11 RS-232 serial port schematic diagram. The pins are defined as follows: Table 9 RS-232 PIN Description Function Description Laser Data Receiver Laser data transmitter Laser data reference Others Unconnected in suspension RS232 interface is a special interface for Raycus internal personnel debugging. -
Page 24: Application Steps Of Laser Device
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 5 Application Steps of Laser Device Pre-inspection a) Check whether the size and connection of water pipe are correct, mainly including water temperature, water flow rate, maximum input pressure, refrigeration capacity, whether the water cooler meets the system requirements (see Section 3.3 for details), whether the water cooler valve is... -
Page 25: Attention In The Process Of Operation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500 5.3 Attention in the process of operation a) The repetition frequency range of the laser should not exceed 10-50 kHZ. b) Do not adjust the laser repetition frequency during marking. -
Page 26: Warranty, Return And Maintenance
The warranties start on the date of shipment from Raycus for a period of time as set forth in the applicable purchase contracts or product specifications. Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. - Page 27 All service and maintenance shall be performedby qualified Raycus personnel. Please contact Raycus as soon as possible when problems under warranty about maintenance happened to the product. The product returned with permission should be placed in a suitable container.
