Swingline 48200 Operating Instructions page 3

Please keep this manual in a safe place for easy reference.
How to Use:
Electric Power Source
Insert adapter plug into input jack on back of stapler. Plug
adaptor into electrical outlet
(120 VAC). Use battery for portable applications.
Loading Staples
Press button on back of stapler to release staple
channel. Pull channel forward and load standard
staples. Push channel back until it clicks into place.
For best results, always
® ®
use Swingline S.F. 4 Premium Staples.
LOW STAPLE INDICATOR
Plug-In Adaptor Power Operation
Light on: normal operation
Continuous flashing: Low on staples,
or open magazine
Light off: no power
Battery Power Operation
Light off: unit operating by power
Continuous flashing: Low on staples or
open magazine.
(NOTE: batteries must be installed)
Avoiding Jams
Use only standard size staples.
Do not staple more than 20 sheets
of 20 lb. paper at a time.
Allow stapler to complete
its cycle before removing
paper from front opening.
Use quality alkaline batteries.
Replace batteries if stapler stalls.
Please read instruction manual before use.
Insert adaptor plug here
Loading Batteries
Slide the battery cover in the direction of the
arrow. Insert the batteries as shown on the battery
compartment. Observe polarity. Load 6 AA alkaline batteries
(do not mix old and new batteries). Maximum battery life
8,000 staples. When stapler is not in use for extended
periods, remove the batteries.
Stapler Operation
Adjust the adjustment slide to the desired location. Slide
can be adjusted from 1/4" to 1-1/2". Simply insert paper
into front opening to staple documents instantly. This model
staples up to 20 sheets of
20 lb. paper at a time.
Clearing Jams
If stapler jams, press
button on back of stapler
to release staple channel.
Pull channel out and
remove jammed staples.
Important
Do not remove documents during stapling.
Do not attempt to staple without paper.
DRY ALKALINE MANGAN BATTERY
BATTERY
NICKEL CADMIUM
BATTERY
