18 GAUGE 2 INCH BRAD NAILER
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or
grind materials such as wood,
paint, metal, concrete, cement,
or other masonry. This dust
often contains chemicals
known to cause cancer, birth
defects, or other reproductive
harm. Wear protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead,
known to the State of California
to cause cancer and birth
defects or other reproductive
harm. Wash hands after
handling.
Important!
When using equipment, a few
safety precautions must be
observed to avoid injuries and
damage. Please read the
complete operating manual with
due care. Keep this manual in a
safe place, so that the information
is available at all times. If you give
the equipment to any other
person, give them these operating
instructions as well. We accept no
liability for damage or
accidents which arise due to
non-observance of these
instructions and the safety
information herein.
SPECIFICATIONS
Operation Pressure: 60-100PSI
Magazine Capacity: 100
Fastener Length: 3/8" - 2"
Air Consumption: .5 CFM
Air Inlet: 1/4" NPT
Fastener Gauge: 18 Gauge
CAUTION:
FOR YOUR OWN SAFETY,
READ INSTRUCTION MANUAL
COMPLETELY AND
CAREFULLY BEFORE
OPERATING THIS BRAD
NAILER.
Any failures made in following
the safety regulations and
instructions may result in an
electric shock, fire, and/or
serious injury.
Common sense and caution
are factors which cannot be
built into this product, but
must be supplied by the
operator.
feedback@natitools.com
Model: 7555
SAFETY INSTRUCTIONS
1) Read and understand tool
labels and the manual. Failure
to follow warnings, dangers,
and precautions could result in
death or serious injury.
2) Use safety equipment such
as eye protection, ear
protection, gloves, and/or hard
hat when applicable.
3) Only use compressed air.
Use of any air source other
than compressed air may
cause the tool to explode,
which will cause death or
serious personal injury.
4) Use clean, dry, regulated,
compressed air at 60-100psi.
Do not use pressure which
could exceed 100psi.
5) Keep the Air Nailer away
from all flammable liquids and
gases.
6) Stay alert while operating
the tool. Do not use while
under the influence of drugs or
alcohol.
8807555
02/13
