PRESENTATION
This handbook is designed to familiarise you with the new vehicle
from the moment you get behind the wheel and to describe the
operating features.
Reading the handbook is made easy by a content consisting of
10 identified chapters which can be located by means of a colour
code specific to each one. Its sections cover, by theme, all of the
functions of the vehicle in its most complete specification.
Chapter 8 indicates all of the technical data relating to your
vehicle. At the end of the document, diagrams of the outside
and inside of the vehicle will assist you in locating equipment or
functions and page numbers refer you to the relevant section of
the handbook.
PEUGEOT COMMUNICATION
PUTS AN INTERNET SITE AT YOUR DISPOSAL
The technical data, equipment and accessories may change
during the year. To obtain this new data, refer to the "Latest
Information" section on the SERVICE BOX Internet site free of
charge.
Within the chapters symbols draw your attention to specific
information:
directs you to the chapter and section which contains detailed
information concerning a function,
indicates important information relating to use of the equipment,
alerts you to the safety of individuals and equipment on board.
http://public.servicebox.peugeot.com , select:
-
your model,
-
the body type: saloon, CC, SW, estate, van...,
-
the period corresponding to the date of first registration,
-
the "Latest Information" section.
