LOUIS VUITTON HORIZON SPEAKER

Advertisement

loading
Need help?

Need help?

Do you have a question about the HORIZON and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Louis Vuitton HORIZON

  • Page 1 LOUIS VUITTON HORIZON SPEAKER...
  • Page 2 French English Japanese/ Chinese (traditional) Chinese (simplified) Korean Russian...
  • Page 3 La versione italiana di questo manuale si trova sulla scheda tecnica degli auricolari Louis Vuitton Horizon disponibile sul sito web www.louisvuitton.com. La versión española de este manual se encuentra en la ficha de producto de los auriculares Louis Vuitton Horizon, disponible en la página web www.louisvuitton.com.
  • Page 4 ค่ ู มื อ ภาษาไทยมี อ ย่ ู ในเอกสารข ้อม ลผลิ ต ภั ณ ฑ์ ห ฟั ง ของ Louis Vuitton Horizon ที ่ เ ว็ บ ไซต์ www.louisvuitton.com. www.louisvuitton.com ، ‫ المتو ّفرة على موقع االنترنت‬Louis Vuitton Horizon...
  • Page 5 For the best experience, download the LV app from your local app store. Pour une expérience optimale, téléchargez l'application LV dans votre store d'applications.
  • Page 6 A Power button B Multifunction button Single tap to Play or Pause audio playback Double tap to skip track Triple tap to go to the previous track Connect button (Wi-Fi/Bluetooth pairing) D Microphone Red: Muted White: Active E Volume control ring Increase volume: turn ring clockwise Decrease volume: turn ring counter- clockwise...
  • Page 7: Power Off

    The Louis Vuitton Horizon speaker may take up to 30 seconds to fully power ON. POWER OFF To power OFF your Louis Vuitton Horizon speaker, hold your finger to the power icon ( ) for five seconds. All icons and LEDs will turn OFF.
  • Page 8: Bluetooth Pairing

    Download and launch the LV Horizon app. With the Horizon Speaker powered on, hold the connect ( ) button until the Horizon Speaker’s LEDs begin blinking and a pairing tone is heard. Follow the instructions on the app to connect the Louis Vuitton Horizon speaker to Wi-Fi.
  • Page 9: Recharge The Battery

    Recharge the battery The LV Horizon Universal Charger can provide power to your speaker in two ways, by USB-C cable or by using the charging dock. To recharge or provide power to your speaker, plug the USB-C cable into the back of the speaker and plug the other end into the provided universal charging adapter.
  • Page 10: Included Accessories

    Included accessories UNIVERSAL CHARGING PACK The Louis Vuitton Horizon Speaker comes with a charging dock, two USB-C Power cables and a universal power supply. •1-meter USB-C to USB-C cable is provided for portability •3-meter USB-C to USB-C cable is provided for stationary use.
  • Page 11 Use Spotify Connect Listen out loud with Spotify Connect Connect your LV Horizon Speaker to your WIFI network Open up the Spotify app on your phone, tablet or laptop using the same WIFI network Play a song and select Devices Available Select your LV Horizon Speaker and start listening The Spotify Software is subject to third party licenses found here: http://www.spotify.com/connect/third-party-licenses...
  • Page 12: Legal Information

    Legal information FCC Statement (USA) / Part 15 of the FCC Rules FCC ID: 2ALDGQAC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •This device may not cause harmful interference, and •This device must accept any interference received, including interference that may cause undesired operation.
  • Page 13 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 14 FCC RF Radiation Exposure Statement: This equipment complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the ISED.
  • Page 15 Operation is subject to the following two conditions: • This device may not cause interference • This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage;...
  • Page 16 China CMIIT ID: 2019DJ8965 Caution: It is only suitable for non-tropical use and for use below 2000 meters above sea level. Names of hazardous substances contained in the product Table TBC...
  • Page 17 EU Importer address and company name: Louis Vuitton Malletier, 2 rue du Pont Neuf 75001 PARIS, FRANCE. Hereby, Louis Vuitton Malletier declares that the radio equipment type Louis Vuitton Speaker is in compliance with Directive 2014/53/EU. The full text of the CE declaration of conformity is available...
  • Page 18 Japan Japanese Radio Law Compliance. This device is granted pursuant to the Japanese Radio Law (電波法). This device should not be modified (otherwise the granted designation number will become invalid).
  • Page 19 Trademark: Louis Vuitton Rating (voltage): 5V/1.5A max., 5V/0.1A max. Manufacturer : Louis Vuitton Malletier, 2 rue du Pont Neuf 75001 PARIS, FRANCE. Manufacture/country of origin: China Operation is subject to the following two conditions: This device may not cause harmful interference, and •...
  • Page 20 Russia Product name: Bluetooth speaker Model no. QAC Trademark: Louis Vuitton Rating (voltage): 5V/1.5A max., 5V/0.1A max. Manufacturer: Louis Vuitton Malletier Manufacture/country of origin: China Detailed specification: Qualcomm QCS 404 • WIFI 802.11 b/g/n/ac with limited band base on global certification requirement, connectivity range up to 100m. (2.4G / 5G band3, band4) •...
  • Page 21 15W maximum rated audio output power 60-20kHz   Max Input power: 20V/1.5A/30W, 15V/2A/30W, 12V/2.5A/30W, 9V/3A/27W, 5V/3A/15W Digital interface audio amplifier with EQ setting and supply voltage control (TAS5825P from TI)  3-microphone array can be used for telecommunication (BT HFP), microphone can be muted/disconnected ...
  • Page 22 Singapore South Korea...
  • Page 23 As this radio equipment has the possibility of radio interference, this equipment cannot be used for any services related to human life safety. Conformity assessment information: Company name of Applicant: Louis Vuitton Malletier  Manufacturing date: 2021   Manufacturer/country of origin: China Equipment name/model name: QAC ...
  • Page 24 Taiwan Product name: Bluetooth speaker Model name: QAC Trademark: Louis Vuitton Malletier RF Spec: Peak Gain 0.15db Peak Rated Voltage: 3.7V; Rated Power: 314.5mW NCC caution statement: For low-power radio frequency equipment that has been certified, companies, firms, or users are not allowed to change the frequency, increase the power, or change the characteristics and functions of the •...
  • Page 25 R33D93 ROHS • For low-power radio frequency equipment that has been certified, companies, firms, or users are not allowed to change the frequency, increase the power, or change the characteristics and functions of the original design without approval. The use of low-power radio frequency equipment must not affect flight safety and interfere with legal communications;...
  • Page 26 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Danger of explosion when the battery is in a state of charge for a long time. When disposing CNS 15364, it should be handled properly. United Arab Emirates...
