DeWalt D55168 Instruction Manual

Oil free portable air compressor
Hide thumbs Also See for D55168:
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
GUIDE D'UTILISATION
MANUAL DE INSTRUCCIONES
D55168
Oil Free Portable Air Compressor
Compresseur d'air portatif sans huile
Compresor de aire sin aceite portátil
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-800-4-D
WALT • www.dewalt.com
E
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA
DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES
DE USAR EL PRODUCTO.

Advertisement

Table of Contents
loading

Related Manuals for DeWalt D55168

Summary of Contents for DeWalt D55168

  • Page 1 If you have questions or comments, contact us. Pour toute question ou tout commentaire, nous contacter. Si tiene dudas o comentarios, contáctenos. 1-800-4-D WALT • www.dewalt.com INSTRUCTION MANUAL INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA GUIDE D'UTILISATION DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.

  • Page 2: Pump/Motor Specifi Cations

    FIG. 1 D55168 Air Compressor A. On/Off Switch F. Check Valve B. Air Tank Pressure Gauge G. Safety Valve C. Regulated Pressure Gauge H. Air Tank Drain Valve D. Pressure Regulator I. Pressure Switch E. Quick Connect Pump/Motor Specifi cations...

  • Page 3: Defi Nitions: Safety Guidelines

    • lead from lead-based paints Defi nitions: Safety Guidelines • crystalline silica from bricks and cement and other masonry products The definitions below describe the level of severity for each signal word. Please read the manual and • arsenic and chromium from chemically-treated lumber pay attention to these symbols.
  • Page 4 • If electrical sparks from • If spraying flammable materi- compressor come into con- als, locate compressor at tact with flammable vapors, least 20 feet (6.1 m) away DANGER: RISK TO BREATHING (ASPHYXIATION) they may ignite, causing fire from spray area. An addi- or explosion.
  • Page 5 Attachments & accessories: • Exceeding the pressure • Follow the equipment rating of air tools, spray guns, manufacturers WARNING: RISK OF BURSTING air operated accessories, recommendation and never Air Tank: The air tank on your Air Compressor is designed and may tires, and other inflatables exceed the maximum allowable be UM coded (for units with air tanks greater than 6 inch diameter)
  • Page 6 • Electrical Grounding: • Make certain that the Failure to provide adequate electrical circuit to which the grounding to this product compressor is connected could result in serious injury provides proper electrical WARNING: RISK OF HOT SURFACES or death from electrocution. grounding, correct voltage and WHAT CAN HAPPEN HOW TO PREVENT IT...
  • Page 7 • Attempting to operate • Any repairs required on this • Equip area of operation with a compressor with damaged or product should be performed fire extinguisher. missing parts or attempting by a D WALT factory service • Do not op er ate machine with to repair compressor with center or a D WALT authorized...
  • Page 8 REGULATOR FEATURES The regulator (D) controls the air pressure shown on the outlet ON/OFF SWITCH pressure gauge. Pull the knob out and turn clockwise to increase Place this switch (A) in the ON position to provide pressure and counterclockwise to decrease pressure. When the automatic power to the pressure switch and desired pressure is reached push knob in to lock in place.

  • Page 9: Installation

    The portable air compressor is equipped with a cord having a MOTOR OVERLOAD PROTECTOR grounding wire with an appropriate grounding plug. The motor has a manual thermal overload protector. If the motor 1. The cord set and plug (M) with this unit overheats for any reason, the overload protector will shut off the contains a grounding pin (L).

  • Page 10: Voltage And Circuit Protection

    • in good condition Location • no longer than 50 feet Place the air compressor in a clean, dry and well ventilated area • 12 gauge (AWG) or larger. (Wire size increases as gauge num- at least 12" (30 mm) away from the wall or other obstructions that ber decreases.

  • Page 11: Preparation For Use

    LIFTING 6. Pull the knob (D) out and turn clockwise to increase pressure and counterclockwise to decrease pressure. When the desired Always use two people when lifting and lift from pressure is reached push knob in to lock in place. the recommended lift points (O).

  • Page 12: Operating Procedures

    3. Open the drain valve (turn lever counter-clockwise) fully to 2. Turn regulator knob (D) counterclockwise until fully closed. Ensure permit air to escape and prevent air pressure build up in the air regulated pressure gauge reads 0 PSI (0 kPa). tank during the break-in period.

  • Page 13: Maintenance Chart

    Maintenance Chart dryers). This condensate contains lubricating oil and/or substances which may be regulated and must be disposed of in accordance with Daily local, state, and federal laws and regulations. Before Every or after each 1. Ensure On/Off switch (A) is in the OFF position. Yearly each hours...

  • Page 14: Air Compressor Pump Intake And Exhaust Valves

    Baltimore, MD 21286, call 1-800-4-D WALT (1-800-433-9258) or visit replacement. our website www.dewalt.com. CAUTION: The use of any other accessory not recommended for use with this tool could be hazardous. Use only accessories rated equal to or higher than the rating of the air compressor.
  • Page 15 GLOSSARY CFM: Cubic feet per minute. SCFM: Standard cubic feet per minute; a unit of measure of air delivery. PSI: Pounds per square inch; a unit of measure of pressure. kPa (kilopascal): Metric pressure measurement. 1 kilopascal equal 1000 pascals. Code Certification: Products that bear one or more of the following marks: UL, CUL, ETL, CETL, have been evaluated by OSHA certified independent safety laboratories and meet the applicable Underwriters Laboratories Standards for Safety.
