Summary of Contents for Twothousand TT-BC265E
- Page 1 Reach In Refrigerator User Manual Reach In Refrigerator User Manual NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
- Page 2 Reach In Refrigerator User Manual NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
- Page 3 Reach In Refrigerator User Manual NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
- Page 4 Reach In Refrigerator User Manual INDEX 1. Introduction 2. Manufacturer’s retained rights and responsibility 3. Transportation and storage 4. Commissioning 4.1 Positioning 4.2 Initial hygiening 4.3 Positioning of components and accessories 4.4 Connection to electrical 4.5 Connection to drains 4.5.1 Gastronorm,pastry,and ventilated ice-cream models 4.5.2 Base, fish, combinations and static ice cream models 5.
- Page 5 Model Net weight Packing weight and volume TT-BC265E 198 kg 213kg 2.7 m3 The above mentioned values are approximate. Whilst awaiting by definitive collection, these should be stored within a Protected and covered environment at a temperature between -25’C+ 55’C, with ambient humidity between 30/95%.Do not stack more than two items (fig.1) and position by means of lifting as indicated in fig.1.
- Page 6 Reach In Refrigerator User Manual Ensure that, in respect of the dimensions (fig.2), the space reserved for The equipment permits its correct utilization and ease of maintenance. After carefully unpacking the display case, remove the white PVC protective film and all of the manufacturer’s material which safeguards The item in transit.
-
Page 7: Technical Characteristics
5.2 Absorbed loadings The absorbed loadings are registered in the following table: Cabinet model Rating absorbed loading watt TT-BC265E 650 W Refrigerants are: R134A, R404A. 5.3 Noise and vibration The sound level of the equipment fitted with integral hermetic condensing unit does not exceeded 70 DB, it is therefore not necessary sound insulation. - Page 8 Reach In Refrigerator User Manual food, fish, pastry. Ultranegative tables (-15°C+- 20°C): storage for long periods of frozen foods, ice cream, pastry, and freezing of short quantities of fresh foodstuffs of little dimensions. 6. USE 6.1 Activation (except for static ice cream models) (fig.8-17) These cabinets are activated by switched and an electronic control panel.
-
Page 9: Maintenance
Reach In Refrigerator User Manual prolonged openings of the door. Wait a few moments before reopening the door just after it has been closed. Do not load the unit over the load limit marked by symbol posted on the internal back wall (=V=V=). 6.3 Defrosting 6.3.1 Timing of defrosting The electric control panel is preset to automatically execute four defrosting cycles within twenty four... - Page 10 Reach In Refrigerator User Manual The electronic control panel is correctly regulated (see. 6.1.4) The device is neither in the defrosting phase nor the post-defrosting phase. The evaporator (internal walls in the static model) is not covered with frost (see paragraph ...
- Page 11 Reach In Refrigerator User Manual Electrical components and cables. Electrical compressor. Plastic materials. Refrigerant fluid which must not be discharged into the atmosphere. ALL THE RESPONSIBILITY FOR THE FAILURE TO RESPECT THE EXISTING LOCAL STATUTES ARE THE RESPONSIBILITY OF THE OWNER.
- Page 12 Reach In Refrigerator User Manual NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
