Mania BASSBOX Quick Start Manual

INSTRUCTIONS

BASSBOX PORTABLE
BLUETOOTH SPEAKER

PACKAGE CONTENTS

•
Speaker
•
Manual
•
Micro-USB charging cable
•
3.5 mm AUX audio cable
•
Carrying strap

TECHNICAL SPECIFICATIONS

•
Input: 5 V ⎓ 0.5 A
•
Frequency: 80 Hz–20 kHz
•
Power: 2 × 5 W
•
Material: ABS
•
Size: 9.5 × 9.9 × 22 cm
•
Battery capacity: 1200 mAh
•
Connection range: 10 m

HOW TO USE

O PARTS ON THE BOTTOM OF THE
SPEAKER
You can access these parts by opening the rubber
flap on the bottom of the speaker.
(1) This is the micro-USB charging port. Use the
included cable to charge the device. On a
full charge, the battery can last 5–6 h.
Charge for at least 2 hours before first use.
(2) This is the AUX audio port. Use the 3.5 mm
cable that's included with the device, but it
works with any such cable. You can connect
the speaker to any other device that
supports AUX with a 3.5 mm cable to play
music or media directly through the
speaker.
(3) This is a standard USB port. Connect a USB
stick to play MP3 music directly from it
through the speaker.
(4) This is the TF card slot. Play music directly
from a micro SD/TF card through the
speaker.

O BUTTONS ON TOP OF THE SPEAKER

(5) Press the Bluetooth button once to search
for available devices. Turn on Bluetooth on
your phone and find TG-125 in your
available devices and connect to it to play
music from your phone.
(6) This is the volume down/previous song
button. If you press it once, the speaker will
play the previous song. Press and hold the
button to lower the volume of the speaker.
(7) This is the power button. Press and hold to
turn the speaker on or off.
(8) This is the mode button. Press it to switch
between different modes (Bluetooth/TF
card/FM radio/USB stick/AUX).
(9) This is the volume up/next song button.
Press it to play the next song. Press and
hold the button to raise the volume of the
speaker.
(10) This is the play/pause button. Press it to
play or pause media from your
phone/AUX/USB stick/TF card. In Bluetooth
mode, press the button to answer or hang
up a call. Press the button twice to call the
last number from your call list. In FM mode,
press this button to search for radio
stations, then press it again to stop
