Super Shot 7' Hockey Table
Item 64-3012
SUPER SHOT
7' HOCKEY TABLE
Replacement Parts
Order direct at www.gldproducts.com
or call our Customer Service department at
(800) 225-7593
8 am to 4:30 pm Central Standard Time
Item 64-3012
May 2012
UPC Code 7-19265-53477-8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Super Shot 64-3012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GLD Products Super Shot 64-3012

Summary of Contents for GLD Products Super Shot 64-3012

  • Page 1 GLD Products Super Shot 7' Hockey Table Item 64-3012 SUPER SHOT 7' HOCKEY TABLE Replacement Parts Order direct at www.gldproducts.com or call our Customer Service department at (800) 225-7593 8 am to 4:30 pm Central Standard Time Item 64-3012 May 2012...
  • Page 2 GLD Products Super Shot 7' Hockey Table Item 64-3012 Staple your receipt here. Important: A copy of your receipt will be needed to activate your warranty (see page 16).
  • Page 3 Email: gld@gldmfg.com Web: www.gldproducts.com This manual may have been updated. For the latest manual visit the GLD Products website. Place your package near the location where it will be used. Carefully unpack all components and verify you have all the correct pieces.

  • Page 4: Parts Identifier

    GLD Products Super Shot 7' Hockey Table Parts Identifier Item 64-3012 Parts Identifier Part Part Part Illustration/ Illustration/ Illustration/ No./ No./ No./ Order Number Order Number Order Number Qty. Qty. Qty. Leg A Side Panel End Panel Order No. 4-146 Order No.

  • Page 5: Product Registration

    GLD Products Super Shot 7' Hockey Table Item 64-3012 IF YOU HAVE A WARRANTY CLAIM, CALL US FIRST Please see page 16. GLD Products Available 8 am to 4:30 pm Central Standard Time S84 W19093 Enterprise Drive Muskego, WI 53150 USA...

  • Page 6: Assembly Tips

    GLD Products Super Shot 7' Hockey Table Item 64-3012 Assembly Tips Make sure you understand the following before you begin to assemble your game table. 1. READ THIS MANUAL all the way through before beginning assembly. 2. When installing parts that have more than one bolt, start ALL bolts in that part by hand before tightening anything.
  • Page 7 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 1 - ASSEMBLE THE TABLE 1. Lay the table top bottom side up on a flat surface. The fan should already be installed. 2. Position the side panel (#1) so the grooves on the inside surface line up with the braces.
  • Page 8 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 2 - ASSEMBLE THE OUTER LEG 1. Select one of the leg pieces (#3 or #4) and lay it flat on the floor. 2. Position the leg center piece (#5) to line up the four screw holes with the pre-drilled holes in the leg piece.
  • Page 9 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 3 - ASSEMBLE THE INNER LEG 1. Select one of the inner leg (#6) pieces. Do not bend the hinge of the leg backwards. Damage will occur. 2. Position the leg piece with the assembly from Step 2. Notice that the leg gets wider at one end.
  • Page 10 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 4 - ASSEMBLE THE LEG BASE 1. Position a leg assembly with the small end up. 2. Place a leg base (#7) on top. The four screw holes will be over the pre-drilled holes in the outer pieces.
  • Page 11 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 5 - ASSEMBLE LEGS TO TABLE TOP 1. Position a leg assembly onto one of the table top corners. 2. Finger start four bolts (#14) through the leg into the holes in the panels. These holes have a threaded nut in place.
  • Page 12 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 6 - TURN THE TABLE OVER The table is ready to be turned over. USE AT LEAST TWO PEOPLE TO LIFT THE TABLE ASSEMBLY AND TURN IT OVER TO REST ON THE LEGS.
  • Page 13 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 7 - ASSEMBLE HAND GRIP 1. Screw a hand grip (#15) into the flipper at each end of the table. 1-800-225-7593 www.gldproducts.com...
  • Page 14 GLD Products Super Shot 7' Hockey Table Item 64-3012 STEP 8 - ADJUST THE LEVELERS 1. Turn each leg leveler until the table rests level. 2. Check with a carpenters level placed cross-wise and length wise on the table top.
  • Page 15 GLD Products Super Shot 7' Hockey Table Item 64-3012 Care and Use of your Table • This product is intended for INDOOR use only. • DO NOT sit, climb, or lean on the table. • DO NOT drag the table when moving it. This will damage the legs.

  • Page 16: Day Limited Warranty

    GLD Products Super Shot 7' Hockey Table Item 64-3012 90-DAY LIMITED WARRANTY The Manufacturer warrants to the original retail purchaser that this product is free from defects in material and workmanship under normal use and conditions for a period of ninety (90) days from the date of original purchase.

  • Page 17: Register Your Product

    Complete this form, include a copy of your receipt, fold, tape (do not staple) and return within 10 days of purchase. This protects your warranty and will help us develop new products! GLD Products Warranty Department S84 W19093 Enterprise Drive Muskego, WI 53150 USA Fold here second.
  • Page 18 2. How did you become aware of this product? Select two. Saw in an advertisement Saw it in the store Saw or used a friend’s or relative’s Recommended by another person Received as a gift Other 3. Rate your satisfaction with each of the following? Excellent Good Fair...

  • Page 19: Shipping Address

    Mail To: GLD Products S84 W19093 Enterprise Drive Super Shot 7' Hockey Table Muskego, WI 53150 USA · 1-800-225-7593 FAX 800-841-6944 Item 64-3012 Email: gld@gldmfg.com Web Site: www.gldproducts.com Parts Re-Order Form Name Date Address Phone-Day City Phone-Evening State Email Unit Total Order No.
  • Page 20 GLD Products Super Shot 7' Hockey Table Item 64-3012 1-800-225-7593 www.gldproducts.com...
