INTERIOR SYSTEMS: ASSEMBLY INSTRUCTIONS
INTERIOR SYSTEMS CORNICE 566
Version 4 Up to date April 2010
(Hanging rod / Socket for hanging rod)
ACCESSORIES:
1_
3_
5_
7_ & 8_
1_Bottom connector one-sided (type A) (82.10.001)_
2_Bottom connector one-sided (type B) (82.10.002)_
3_Bottom connector both-sided (82.10.003)_
4_Cover profi le 362 mm (82.11.020) (with drilling for hanging rod)_
5_Cover (82.10.009)_
6_Wall connector (82.10.006), Spacer (82.10.016), Position plate (82.10.007),
screws and dowels_
7_Hanging rod connection (82.10.012)_
8_Hanging rod (82.23.020)_
2_
4_
6_

Advertisement

loading
Need help?

Need help?

Do you have a question about the CORNICE 566 and is the answer not in the manual?

Questions and answers

Summary of Contents for raumplus CORNICE 566

  • Page 1 INTERIOR SYSTEMS: ASSEMBLY INSTRUCTIONS INTERIOR SYSTEMS CORNICE 566 Version 4 Up to date April 2010 (Hanging rod / Socket for hanging rod) ACCESSORIES: 7_ & 8_ 1_Bottom connector one-sided (type A) (82.10.001)_ 2_Bottom connector one-sided (type B) (82.10.002)_ 3_Bottom connector both-sided (82.10.003)_ 4_Cover profi...
  • Page 2: Distance To The Wall

    _ASSEMBLY Distance to the wall 185 mm 22 mm Please make sure that you start in the corner...
  • Page 3: Preparation For The Installation

    _ASSEMBLY Preparation for the installation Slide the caps onto the frame before the assembly. After the alignment and installation of the wall attachment. you won`t be able to attach the caps on the side of the wall anymore.
  • Page 4 _ASSEMBLY...
  • Page 5 _ASSEMBLY Now start the adjustment Art.-Nr.: 82.10.001 Art.-Nr.: 82.10.002 Art.-Nr.: 82.10.002 Art.-Nr.: 82.10.001 Art.-Nr.: 82.10.004 Cover profi le Art.-Nr.: 82.11.020 with drillings for socket for hanging rod...
  • Page 6 _ASSEMBLY...
  • Page 7 _ASSEMBLY After the assembly and alignment you can begin with the wall attachment. SW 13 Afterwards, adjust all frames and slide the cover until it reaches the fl ooring. Spacer To affi x the frame, you can place another wall attachment in the lower third.
  • Page 8 _ASSEMBLY Use the height adjustment elements of the cabinet to adjust any imbalances in the fl oor. Hexagon socket 8 mm...
