Vizeri VZ460 User Instructions

For User Videos Go Here:
www.vizeriled.com/light
Thanks for choosing Vizeri flashlights, the LED lighting of
a new generation. Vizeri uses the highest quality materi-
als and high efficiency LED designs.

Features

1. The VZ460 is a high power focusing, zoom flashlight.
A convex mirror is used to change the focus from spot
to flood by rotating the head of the light. The
micrometer-like linear scale on the barrel of the light
enables you to set the light to precise zoom levels
whenever you want.
2. The aircraft-quality aluminum body has a non-slip
surface knurling to ensure that the light doesn't slip
out of your hand.
3. Multiple battery choices are available so you'll never
worry about dead batteries.
4. A constant current circuit chip maintains brightness
regardless of battery output.
5. A specially designed diffuser enables the light to be
used for camping, emergency signal, or a lamp in
power outages.

Specifications

Lamp Cree XLM T6 LED with lifespan of 100,000 hours
460 lumens
Max Brightness
Output Levels Five modes (High-Med-Low-Strobe-SOS) (Constant
current circuit chip maintains constant brightness)
Battery Options 3*AAA ; 2*CR123 batteries; 2*16340 Li-ion batteries or
1*18650 Li-ion batteries
Power Source
3-12 volts DC
Input Voltage
Burn Time High: 1.5 hours; medium: 5 hours, super low: 50 hours
Premium Type III hard-anodized anti-abrasive nish
Material
Exterior Color Black
Vacuum coated aluminum optical re ector
Re ector
Throw Beam 984 feet (300 meters)
Lens Optical lens
Tactical end click switch
Switch
Construction Waterproof to IPX7 standard
Anti-drop height of 1.5 meters (~ 59")
Impact Resistant
Size With AAA batteries: 4.25" (length) x 1.1" (body
diameter) x 1.3" (head diameter) (108 mm x 28 mm
x33 mm)
Weight 3.75 ounces (106.2 grams) without batteries
Optional remote switch, bike mount, orange di user
Accessories
Di user 32.5mm white di user for use as camping or
emergency lamp.
Note 18650 li-ion battery is used with extension tube
added and battery case taken out.
VZ460 User Instructions

Accessories Included

Lanyard, O-ring, red silicone button cap, battery exten-
sion tube, nylon holster, diffuser, AAA battery carrier
User Instructions
1. Install batteries. When powered by AAA batteries,
the extension tube must be removed and the AAA
battery carrier used.
2. Battery check: ensure the batteries are positioned in
the correct direction as shown in the diagram.
3. Power switch: press the button at the tail to turn the
light on or off.
4. Modes: There are five lighting modes: High-Mid-Low-
Strobe-SOS
5. Mode selection: The light memorizes the last mode
it was in for a period of at least 5 seconds.
change modes, turn the light ON and press the button
HALF-way (IT SHOULD NOT CLICK) until you get to
the mode you want. Wait for 5 seconds. Turn the light
OFF. Wait for 5 seconds. When you turn it on again it
will still be in last mode you left it in.
light off and quickly turn it on again the light will
go to the next mode. You must wait at least 5
seconds before you turn the light on again for it
to remember the last mode.
To
If you turn the
