- Page 1 7 D AY W I R E L E S S F O R E C A S T E R WEATHERFX FOR GOLF Quick Start Guide MODEL# 960071C Lit #: 98-1429/04-09...
-
Page 2: Step 1: Install The Software
Step 1: Install the Software Insert the CD, click the “Golf FXi Setup Wizard” button and follow the on-screen directions to install the Golf FXi software on your PC (Windows 2000 or later, with an “always on” internet connection). Step 2: Connect the Transmitter Connect the USB Transmitter to your PC’s USB port. - Page 3 Step 3: Start the Golf FXi Application, Set Locations and Units Double click the “Golf FXi” icon on your desktop. When the application opens, move your cursor to the top (left) box, then click the orange “Edit Location” box when it appears (3a).
- Page 4 Step 4: Set-up the Receiver Unit (LCD Display) Insert 4x AA batteries into the Receiver, or connect its supplied AC adapter. The Receiver’s display initializes and reads “Searching for PC” (press the SEARCH button on the back of the unit if this does not appear). Attach the easel stand to the Receiver and place it near your PC so you can see its display while you complete the setup.
-
Page 5: Temperature Range
Step 5: Transmit Weather Data from the PC to the Receiver Click “Send to Receiver” on the Golf FXi program window (5a). The red LED on the USB Transmitter will glow, then blink while data is transferred from the PC software to the Receiver. - Page 6 Button/Controls Reference Button Name Function Location Initiates search for PC – puts receiver on Back of Unit SEARCH standby to receive data from USB transmitter Press (repeatedly) to select hour format, wind speed and Back of Unit UNITS temperature units (use +/- to change setting) Back of Unit BRIGHTNESS Press to select backlight brightness level (High, Low or Off)
-
Page 7: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY Your Bushnell Golf FXi is warranted to be free of defects in materials and workmanship for one year after the date of purchase. In the event of a defect under this warranty, we will, at our option, repair or replace the product, provided that you return the product with return postage prepaid. - Page 8 For further questions or additional information please contact: Bushnell Outdoor Products 9200 Cody, Overland Park, Kansas 66214 (800) 423-3537 • www.bushnell.com NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT.
