INDEX Buttons on remote controller ....................1 Introduction for icons on display screen ................1 Introduction to the buttons of the remote controller ............2 Operation guide ........................8 Replacement of batteries of the remote controller ............... 8...
Wireless remote controller YAP1F6 Introduction to the buttons of the remote controller Note: This is a general use remote controller that can be used with multifunction air conditioners; For some function, that might not be available on the unit, if you press the corresponding button on the remote controller, the unit will keep the original running status.
Page 5
Wireless remote controller YAP1F6 Note: ● To avoid the emission of cool air, after starting up the heating mode, the indoor unit will delay 1~5 minutes to blow air (actual delay time depends on the room temperature). ● Set temperature range from remote controller: 16~30℃ (61-86°F); Fan speed: auto, low speed, low-medium speed, medium speed, medium-high speed, high speed.
Page 6
Wireless remote controller YAP1F6 Note: ● Keep that button pressed during more than 2s to make the louver swing back and forth from left to right, and then loosen the button, the unit will stop swinging and the actual present position of guide louver will be kept immediately.
Page 7
Wireless remote controller YAP1F6 Note: ● Under on and off status, you can set T-OFF or T-ON simultaneously. ● Before setting T-ON or T-OFF, please adjust the clock time. ● After starting up T-ON or T-OFF, set the constant circulating valid. After that, air conditioner will be turned on or turned off according to setting time.
Page 8
Wireless remote controller YAP1F6 button Press this button to achieve the on and off of healthy and fresh air functions in the operation status. Press this button for the first time to start the fresh air function; The LCD displays " ".
Page 9
Wireless remote controller YAP1F6 Energy-saving function Under cooling mode, press "TEMP" and " CLOCK" buttons simultaneously to start up or turn off energy-saving function. When energy-saving function is started up, "SE" will be shown on remote controller, and air conditioner will adjust the set temperature automatically according to ex-factory setting to reach to the best energy-saving effect.
Controlador por cable YAP1F6 Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "▲" or " " button to set your required temperature. (Temperature can’t be adjusted under auto mode).
Page 11
Controlador por cable YAP1F6 Subject to modification without prior notice.
