VANITY WITH TOP
MODEL #LWF30AVG
Français p. 8
Español p. 15
1
PACKAGE CONTENTS
C
PART
A
B
HARDWARE CONTENTS
Note: Hardware shown not actual size.
AA
x 1
Touch-up Pen
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
WARNING
Do not stand on vanity. Use vanity on level ground. Base
vanity supports a maximum weight of 200 lbs. Exceeding
maximum weight limit will compromise the integrity of the
vanity structure and could cause the vanity to fail.
CAUTION
Failure to follow cautions could result in serious injury.
Do not hang from the vanity.
Do not taking off the vanity top to avoid damaging the vanity.
Clean all fluids from the stone surface to prevent stains. Wipe off the soap or toothpaste immediately to prevent
permanent damage to the stone surface.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required (not included): Silicone compound, Phillips screwdriver, Level, Stud Finder, Pencil, Variable Speed Drill.
DESCRIPTION
QUANTITY
A
Vanity Top (preassembled)
1
B
Vanity Base
1
C
Backsplash
1
Maximum load 200 lb. (90.71 kg)
Maximum load 10 lb. (4.5 kg)
Maximum load 30 lb. (13.7 kg)
2
