Summary of Contents for Eplus P436.CE
- Page 1 ELECTRO-HYDRAULIC 4-POST PARKING LIFT P436.CE ASSEMBLY MANUAL Ver.20.1.9...
- Page 2 SKILLED AND AUTHORIZED PERSONNEL ONLY SHOULD BE ALLOWED TO PERFORM THESE OPERATIONS, FOLLOW ALL INSTRUC- TIONS SHOWN BELOW CAREFULLY, IN ORDER TO PREVENT POSSIBLE DAMAGE TO THE CAR LIFT OR RISK OF INJURY TO PEOPLE. BE SURE THAT THE OPERATING AREA IS CLEARED OF PEOPLE. P436.CE ASSEMBLY MANUAL...
- Page 3 Step To disassembly the package and remove all components and accessories. P436.CE ASSEMBLY MANUAL...
- Page 4 Step To install security lock plate and beam. make slide block of beam assembly from the top of column slide into column. Pay attention to the direction of the column and beam. P436.CE ASSEMBLY MANUAL...
- Page 5 Step To install the lock plate to the top plate with washers and nuts. To install the top plate to the columns. Pay attention to the direction of the top plate. 5 mm P436.CE ASSEMBLY MANUAL...
- Page 6 Step To lift up 4 columns. P436.CE ASSEMBLY MANUAL...
- Page 7 Step Place the sub runway. Place the main runway upside down side of column. P436.CE ASSEMBLY MANUAL...
- Page 8 Step Pull the piston rod of cylinder and pulley block to the end,pull the steel cable tighten. To install the oil pipe. P436.CE ASSEMBLY MANUAL...
- Page 9 Step Place the main runawy. P436.CE ASSEMBLY MANUAL...
- Page 10 Step To fix the bottom plates and runways to the beam with bolts and washers. P436.CE ASSEMBLY MANUAL...
- Page 11 Step To install steel cables. P436.CE ASSEMBLY MANUAL...
- Page 12 Step To install steel cables. P436.CE ASSEMBLY MANUAL...
- Page 13 Step To install steel cables. 5 mm P436.CE ASSEMBLY MANUAL...
- Page 14 Step To install mounted plates of control box and power unit. To install the control box and power unit. P436.CE ASSEMBLY MANUAL...
- Page 15 Step To install oil pipe to power unit. Fill in hydraulic oil to oil tank. P436.CE ASSEMBLY MANUAL...
- Page 16 Step To connect the wire. DZ4-63 CJX2 D1810 Power Motor Limit switch P436.CE ASSEMBLY MANUAL...
- Page 17 Step Press the up botton to raise the runway to the height of approx 800mm. Make sure all 4 locks well locked insde of ladders at the same height. P436.CE ASSEMBLY MANUAL...
- Page 18 Step To intall the lock release lever and connecting rod. P436.CE ASSEMBLY MANUAL...
- Page 19 Step To intall the lock release lever and connecting rod. P436.CE ASSEMBLY MANUAL...
- Page 20 2-3mm leave 2-3mm space P436.CE ASSEMBLY MANUAL...
- Page 21 Step To intall ramp and stoper according to the drivring direction. P436.CE ASSEMBLY MANUAL...
- Page 22 Step To intall the caster kit (optional). Lowering the lift to the end, the caster kit will support the lift. Move the lift to a suitable location for installation. P436.CE ASSEMBLY MANUAL...
- Page 23 Step Remove the caster kit. Run up and down several tims to check without loading. To fix well the columns. P436.CE ASSEMBLY MANUAL...
