Frigidaire FFU14FC2CW Factory Parts Catalog

Frigidaire ffu14fc2cw: supplementary guide

Download this manual

PRODUCT NO.

BASE MODEL NO.

FFU14FC2CW1

FFU14FC2CW

MARKET

North America

WIRING DIAGRAM - # 216857900

OWNER'S GUIDE - # 216802800 / ENERGY GUIDE - # 21679308

SERVICE DATA SHEET - # 216857900

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

FACTORY PARTS CATALOG

SERIES

COLOR

134A

white

Publication No.

5995392668

030711

-EN/SERVICE /MLR

365

FREEZER

VOLTS

115

UPRIGHT FREEZER

Base Model:

FFU14FC2CW

Page 1 PRODUCT NO. BASE MODEL NO. FFU14FC2CW1 FFU14FC2CW MARKET North America WIRING DIAGRAM - # 216857900 OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 21679308 SERVICE DATA SHEET - # 216857900 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
Page 2 Publication No FFU14FC2CW 5995392668 DOOR P08D0261 07/03...
Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC2CW DOOR PART NO DESCRIPTION 216522306 Gasket,door seal ,white 216527617 Panel-inner door,frzr 216557816 Panel-outer door,white 240449705 Nameplate,white 08016354 Door Stop 5303313518 Washer,sealing 216140200 Handle,recessed ,white 08009392 Gasket,white 08005520 Screw,door stop mtg ,4.0 x 0.7-19.7 ,...
Page 4 5995392668 07/03 CABINET P08C0652...
Page 5 POS. NO 13 # 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC2CW CABINET PART NO DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 216604300 Breaker Kit w/corners,45.13" long, no lock slot 216603400 Breaker Kit w/corners,22.13" long, top or bottom...
Page 6 Publication No FFU14FC2CW 5995392668 SYSTEM 07/03...
Page 7 POS. NO 23 # 29 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FFU14FC2CW SYSTEM PART NO DESCRIPTION 5300123788 Condenser 5308000110 Strap-evap/heater,aluminum ,(2) 216634500 Drier-filter 216898900 Harness-main 216740000 Heater-defrost 216737400 Evaporator 216565700 Heat Exchanger 216727600...
