Frigidaire FFU14F3AW3 Factory Parts Catalog

Frigidaire ffu14f3aw3: supplementary guide

Hide thumbs Also See for FFU14F3AW3:

Download this manual See also: Use and Care Manual

PRODUCT NO.

BASE MODEL NO.

FFU14F3AW3

FFU14F3A

MARKET

North America

WIRING DIAGRAM - 216857900

OWNER'S GUIDE - 216802800

SERVICE DATA SHEET - 216857900

ELECTROLUX HOME PRODUCTS, INC.

P.O BOX 212378, AUGUSTA , GA 30917

FACTORY PARTS CATALOG

SERIES

134A

ENERGY GUIDE - 216795301

Publication No.

5995376661

020809

-EN/SERVICE /KC

365

FREEZER

COLOR

VOLTS

white

115

FREEZER

Model numbers:

FFU14F3AW3

Page 1 PRODUCT NO. BASE MODEL NO. FFU14F3AW3 FFU14F3A MARKET North America WIRING DIAGRAM - 216857900 OWNER’S GUIDE - 216802800 SERVICE DATA SHEET - 216857900 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917 FACTORY PARTS CATALOG SERIES COLOR 134A...
Page 2 Publication No FFU14F3AW3 5995376661 DOOR 08/02...
Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFU14F3AW3 DOOR PART NO DESCRIPTION 216522306 Gasket,door seal ,white 216527618 Panel-inner door,white ,frzr 216557800 Panel-outer door,white 240415201 Label-nameplate,white 08016354 Door Stop 5303313518 Washer,sealing 216140200 Handle,recessed ,white 08005520 Screw,door stop mtg ,4.0 x 0.7-19.7 ,flat hd,metric...
Page 4 Publication No FFU14F3AW3 5995376661 CABINET 08/02...
Page 5 POS. NO 13 # 14 # 16 # 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFU14F3AW3 CABINET PART NO DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 216604300 Breaker Kit w/corners,45.13" long ,no lock slot 216603400 Breaker Kit w/corners,22.13" long ,top or bottom...
