SUPPORTPLUS FF8296 Quick Start Manual

THREE or FOUR STEP SAFETY LADDER WITH HANDRAILS
Please read all instructions thoroughly before use. Keep instructions for future reference.
CAUTION:
DO NOT EXCEED WEIGHT LIMIT OF 300 LBS.
DO NOT use on slippery or uneven surfaces, scaffolding, or unstable bases.
DO NOT use ladder if it is damaged, worn, or if ladder has been exposed to fire or chemical corrosion.
DO NOT attempt to repair damaged or missing parts.
DO NOT use ladder for anything other than its intended use. Ladder is for HOUSEHOLD USE ONLY.
DO NOT overreach while standing on ladder or attempt to move ladder while standing on it.
WARNING: Metal ladder conducts electricity. DO NOT make contact with live electrical wires.

SAFETY GUIDELINES:

 When using ladders, basic safety precautions should always be
followed.
 Inspect all parts prior to each use to insure that all parts are
securely fastened and in good working condition.
 Keep step ladder dry and clean, free from grease, oil, mud, snow,
wet paint, and other slippery materials.
 Ladder is meant for one person only.

ASSEMBLY INSTRUCTIONS:

*Note:
A. Handrails are labeled left and right. Right and left sides are determined
by standing in front of the ladder.
B. Parts included: Bolts (4), Nuts (4), Washers (4)
C. Tools needed (not included): Ratchet, 10mm Socket, Pliers
1. Attach the top bar to the lower part of ladder body.
Figure 2a
2. Attach the handrails by lining up the bottom hole in the handrail with the
bottom hole in the frame of the ladder, insert the bolt through the
handrail and frame and place the washer and nut on. Do not tighten. See
figure 3.
Thank you for your purchase from Support Plus.
Figure 2b
Figure 3
Figure 1
Top bar
