Sunbeam Products 183952 Quick Start Manual

HOW TO USE
1.
Add litter to the FILL line in the Litter Tray (A) (see Fig. 9).
Your Automatic Litter Box works with most litter brands,
but clumping-type litter works best with this system.
2.
Locate the Power Adapter and plug it in to the outlet
Figure 9
on the side of the Detachable Motor (B). The outlet is
located underneath the Motor on the left side when
facing the Rake Assembly (E), as shown in Figure 10.
3.
Plug the Power Adapter into a standard household
wall outlet. The Control Panel LED lights will blink in
sequence while the unit is powering up and the first
Cleaning Cycle will begin automatically.
NOTE: If the Litter Box does not complete one Cleaning
Cycle, or if you hear the motor running but the Rake does
Figure 10
not move, please go back and review all previous steps.
4.
Choose the Cleaning Frequency on the Control Panel
by pressing the SELECT Button. The Litter Box will
automatically perform one Cleaning Cycle at the time
Select
chosen. For example, if you select "Every 4 Hours", the
Sleep Hourly Every 4 Every 8
Mode Hours Hours
Litter Box will complete a Cleaning Cycle once every 4
hours, as shown in Figure 11.
Figure 11
© 2015 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved.
Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
Due to continuing product development, the product inside the packaging may look slightly different than the
one on the package. Sunbeam Products, Inc. is a subsidiary of Jarden Corporation (NYSE: JAH). Made in China.
The ARM & HAMMER™ name logo and associated marks are trademarks of Church & Dwight Co., Inc.
These marks are used under license by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions
P.N.: 183952
LITTER BOX
QUICK START GUIDE
A. LITTER TRAY
B. DETACHABLE
C. SENSOR
D. CONTROL PANEL
E. RAKE ASSEMBLY
SPR-060815-247P
SELF-CLEANING
LITTER BOX
SELF-CLEANING
C
D
B
A
H
F. WASTE RECEPTACLE
LID w/ ODOR FILTER
MOTOR G. WASTE RECEPTACLE
H. WASTE RECEPTACLE
LID HOLDER
E
F
G
