Summary of Contents for Purus BSC2HCN
- Page 1 USER MANUAL & INSTALLATION GUIDE MODEL NUMBER BSC2HCN...
-
Page 2: Table Of Contents
Service Alert Table ..................... 21 Operation Precautions ..................9 Specifications ....................24 System Operation ....................10 Installation Guide ....................25 Touchpad Features .....................11 Dispensing Water ....................13 Draining Purus System ..................14 Filter Change Guide................... 15 How To Remove Tubing From Quick Connect Fitting ......17... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS PRÉCAUTIONS DE SÉCURITÉ WARNING ATTENTION TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO POUR ÉVITER TOUT RISQUE D’INCENDIE OU D’ÉLECTROCUTION, RAIN OR MOISTURE. N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. POWER SYSTEM SYSTÈME DU POUVOIR This unit operates on voltage of 120V 60Hz in U.S.A., 230V 50Hz in Cet appareil fonctionne sur une tension de 120 V 60 Hz aux États-... -
Page 4: Unit Overview
UNIT OVERVIEW OVERALL SIZE WIDTH: 6.29in (160mm) DEPTH: 16.53in (420mm) HEIGHT: 15.98in (406mm) -
Page 5: Touchpad Overview
ON during ThermaRinse operation. When activated, cold water will not dispense. SERVICE LED: The Purus system is equipped with performance monitoring software, utilizing a combination of blinking lights and beeps to help diagnose system performance issues. Refer to “Service Alert Table” pages 21-23. -
Page 6: Installation Precautions
INSTALLATION PRECAUTIONS CAUTION! When dispensing hot water or operating the ThermaRinse • Allow enough clearance from the wall so that tubing connected function, please keep hands, and to the back of the unit will not kink or bind. Two (2) Stem Elbow especially children away from the Fittings are included with the installation kit to angle the tubing dispense zone to prevent potential... -
Page 7: Touchpad Features
TOUCHPAD FEATURES • Press the ThermaRinse Button for 3 seconds to activate the ThermaRinse feature (LED ON). The ThermaRinse cycle can be SERVICE INDICATOR canceled at any time by pressing the ThermaRinse button again for 3 seconds. If ThermaRinse cycle is canceled, cold water must reach 50°F. -
Page 8: Dispensing Water
Then press and hold the Dispense button to dispense cold water. The LED will remain ON during dispense. Press and hold the Dispense button to dispense room temperature DRAINING THE PURUS SYSTEM water. 1. Turn Hot Switch OFF. -
Page 9: Filter Change Guide
FILTER CHANGE GUIDE 6. Swivel filter bottom to angle out. Rotate filter to the left and pull Estimated Avg Filter Life = 6 months down to remove. 1. Shut off inlet water line. 2. Press Dispense Button until no water comes out. This will relieve pressure inside the filter. -
Page 10: How To Remove Tubing From Quick Connect Fitting
HOW TO REMOVE TUBING FROM QUICK CONNECT FITTING USING STEM ELBOWS STEP 1 • Use Stem Elbow Fittings to angle tubing connections to Water In Apply pressure (Press down) on the collet rim with a thumbnail or and Water Out ports away from wall. other flat tool such as a flat head screwdriver, being careful not to •... -
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOMS CHECKPOINT SYMPTOMS CHECKPOINT Abnormal water Verify last filter replacement date. Average Water dispense As a safety measure, dispense cycle is limited taste. filter life = six (6) months. suddenly shuts off. to 30 seconds. Re-start the dispense cycle to continue water dispensing. -
Page 12: Service Alert Table
TROUBLESHOOTING GUIDE (CONTINUED) SYMPTOMS CHECKPOINT SERVICE ALERT ISSUE DESCRIPTION Unit suddenly stops Confirm the following: Service light Overheating of Signals overheating in the operating • Power cord connected to an active AC outlet blinks RED and cooling system. cooling system. Hot, Cold and and circuit breaker for that outlet operating GREEN. -
Page 13: Specifications
SERVICE ALERT TABLE (CONTINUED) SYSTEM SPECIFICATIONS SERVICE ALERT ISSUE DESCRIPTION ITEM / MODEL BSC2HCN Service light ThermaRinse Signals a problem with INPUT VOLTAGE (As 120VAC 60Hz / 220~240VAC 50Hz blinks Malfunction ThermaRinse cycle. Thermarinse Requested) RED and GREEN Hot Water has failed to reach alternately target temperature of 158°F+... -
Page 14: Installation Guide
INSTALLATION GUIDE TOOLS NEEDED INSTALLATION PARTS NEEDED POWER TOOLS NEEDED... - Page 15 * Tee Fitting Option: If 1/4˝ tubing already exists under your sink, the Tee Fitting may fitting, then insert BLACK Tubing into Stem Elbow. be used in place of Adaptor Valve to connect BLUE Tubing from Tee Fitting to Purus system. WE’RE ALMOST THERE – PRIMING YOUR PURUS SYSTEM Cut the existing line and insert each end into the straight portion of the Tee, then insert the BLUE tube into the bottom end of the Tee.
