IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline
If you have any problems with this product or require any
replacement fittings please contact Customer Services Tel:
0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-
• We suggest you spend a short time reading through this leaflet and then follow the simple step-
by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.

PRODUCT INFORMATION

• Made from honeycomb board,particle board & MDF with a wood effect finish.
• Made in China

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching or
damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
763922 ,721139 SQUARE TO RECTANGLE TABLE
ASSEMBLY INSTRUCTIONS.
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 763922 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 763922

  • Page 1 763922 ,721139 SQUARE TO RECTANGLE TABLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS PARTS STEP ONE 1. Insert 8 x bolts (C) into nuts fixed on panels 2 (x4) and turn bolts (C) clockwise until tight by hands. STEP TWO 1. Glue and insert 4 x wooden dowels (A) into panel 3. 2.
  • Page 3 STEP THREE 1.Glue and insert 4 x wooden dowels (A) into panel 6. 2. Attach panels 2 (x2) to panel 6 . 3. Slot 2 X metal pieces (D) onto bolts (C ) and thread 2 X springs (F) onto bolts (C ) then screw 2 X metal nuts (E) with spanner (G) until tight.
  • Page 4 STEP SIX 1. Attach panels 4 (x2) to panels 2 (X4) with 8 x screws (I) using a screwdriver until tight. STEP SEVEN 1.Carefully lift the unit upright. Two person requited 2.Attach panels 5 (x2) to panel 1 with 6 x screws (H) using a screwdriver until tight as shown in diagrm.
  • Page 5 2. Do not allow the tops to slam together when open and closing as this way cause damage to the panels. 3. Push the button of latch (J) underneath into the hole as illustration. Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT...
