PRODUCT NO.
BASE MODEL NO.
FFU09C2CW1
FFU09C2CW
MARKET
North America
WIRING DIAGRAM - # 216803100
OWNER'S GUIDE - # 216802800 ENERGY GUIDE - # 216794701
SERVICE DATA SHEET - # 216803100
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
white
Publication No.
5995398061
031030
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
UPRIGHT FREEZER
Model number:
FFU09C2CW
©2003 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

Related Manuals for Frigidaire FFU09C2CW

Summary of Contents for Frigidaire FFU09C2CW

  • Page 1 PRODUCT NO. BASE MODEL NO. FFU09C2CW1 FFU09C2CW MARKET North America WIRING DIAGRAM - # 216803100 OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216794701 SERVICE DATA SHEET - # 216803100 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
  • Page 2 Publication No FFU09C2CW1 5995398061 DOOR 10/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFU09C2CW1 DOOR PART NO DESCRIPTION 216522300 Gasket-door 216527206 Panel-inner door,frzr 216564201 Panel-outer door,white 216892800 Nameplate 08016354 Door Stop 5303313518 Washer,sealing 216140200 Handle,recessed ,white 08005520 Screw,door stop mtg ,4.0 x 0.7-19.7 ,flat hd,metric 216443600 Bearing,hinge ,top 216503200...
  • Page 4 Publication No FFU09C2CW1 5995398061 CABINET 10/03...
  • Page 5 POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFU09C2CW1 CABINET PART NO DESCRIPTION 216502600 Plug,drain ,interior 216604500 Breaker,hinge side 216603500 Breaker,top 216707200 Knob,temp control 216707300 Cover-control housing 216834500 Control-temperature 216823500 Clamp,cap tube ,cold control 5300052943 Screw-clamp,truss hd cr ,control 216503300 Ramp,door closer 5303205738...
  • Page 6 Publication No FFU09C2CW1 5995398061 SYSTEM 10/03...
  • Page 7 POS. NO 29 # 36 # 37 # 38 # 40 # # = Fast-moving Parts * = Non-Illustrated Parts FFU09C2CW1 SYSTEM PART NO DESCRIPTION 5303304537 Condenser 216847802 Trim-shelf,white ,evap 216634500 Drier-filter 216793400 Harness-ext,main 3091418 Support-shelf,front LH 08037928 Support-shelf,front RH 216474600 Support-rear shelf 216225700...
