Bio-Toilet

user manual

version 070721

TG1B2/BT0707

Table of Contents

Need help?

Do you have a question about the TG1B2 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOMEBIOGAS TG1B2

Page 2: Table Of Contents
Maintenance Troubleshooting Warranty CAUTION: DO NOT begin using the HomeBiogas toilet unless you have completed system activation according the the HomeBiogas User Manual. The system cannot properly break down waste before activation and this will make the system produce unpleasant smells.
Page 3: Introduction
The HomeBiogas toilet is an add-on to the HomeBiogas domestic biogas system that allows users to turn human waste into clean energy in the form of cooking gas. The HomeBiogas digester only provides primary and partial wastewater treatment for the connected HomeBiogas toilet. While rich in nutrients, effluent from the system requires further treatment according to local wastewater treatment regulations.
Page 4 overview of toilet installation: 1. installing the toilet in a suitable location and connecting it to the system mounting the toilet bowl, seat & cover connecting the waste-water outlet into the digester installing bidet/connecting the flush-water source to the toilet...
Page 5 2. planning a suitable effluent management system & connecting the effluent output from the homebiogas digester option 1 (preferred): connect to existing sewage system option 2: connect to existing septic tank option 3 (If option 1 and 2 not possible):...
Page 6: Location Planning
location planning To ensure a smooth installation process and a well-functioning bio-toilet after installation, it is important to properly plan for the toilet’s location, mounting surface, and plumbing connections to the system, as well as a suitable effluent management method. You can install the bio-toilet indoors as a replacement for a regular toilet, or construct an outhouse for the toilet nearer to your biogas system.
Page 7 LESS THAN 1.2m ABOVE the toilet discharge elbow, and positioned HIGHER than the fertilizer outlet vented loop. In this type of installation, the toilet can be located only up to 5m (16ft) from the HomeBiogas system. ≤1.2m...
Page 8: Installing The Toilet
LUBRICANT stabilizing cord flush reservoir water 5 hose-clamps lubricant filter for waste pipe (for homebiogas system (for monthly combined outlet) maintenance) Parts/Materials to prepare (not supplied) • Flexible, reinforced sanitation hose (38mm/1.5in) of suitable length to connect toilet to system.
Page 10 Mounting the toilet bowl and attaching the toilet seat The toilet is shorter than a regular home toilet. It must be bolted down securely onto the floor or on a raised platform. If installing onto a platform, it should be level, rigid and strong enough to support the weight of an adult. Do not mount the toilet on shipping pallets or other weak surfaces.
Page 11 3. Prepare plastic seat fittings (2 plastic bolts and 4. With the seat and cover facing cover-side up, slide nuts, 2 rectangular washers) bolts into position on the seat joints. 5. Fit both the rectangular washers in place over the 6.
Page 12 setting up the fresh/greywater reservoir for flushing the toilet You can install a bidet beside the toilet both for Alternatively, connect the toilet's water inlet to a suitable cleaning up and as a water source. water reservoir (e.g. a large covered bucket). You can fill the Using a bidet will simplify the process of flushing the reservoir with tap water, or use rainwater/well water/other toilet.
Page 13 Water reservoir: 1. Attach water filter to one end of the 19mm hose 2. Pass the other end of the pipe through the included in the kit - this is the water inlet pipe bucket’s lid so the filter is in the bucket when the connected to the flush water reservoir.
Page 14 Connecting the wastewater outlet into your HomeBiogas system There are 2 ways to connect the toilet to your Homebiogas system, depending on the location of your toilet and system. We recommend using option 1 where possible, with the toilet placed higher than the system.
Page 15 6. Snap off the plastic circle on the Fertilizer Outlet 7. Insert the discharge pipe into the system from cover of the HomeBiogas system. the round hole on the cover. Push the pipe into the digester until the vented loop is flush with the...
Page 16: Effluent Management
With the Bio-toilet connected, the HomeBiogas system’s liquid fertilizer should be safely diverted directly to a treatment solution WITHOUT potential for user contact. The effluent should NOT be fed directly to plants. A drainfield is a bed with layers of differently-sized gravel, used to remove contaminants/impurities from the digester’s effluent before it enters groundwater.
Page 17 1. Measure and prepare piping of the correct length required to connect the system’s fertilizer outlet to the drainfield location. 2. Prepare perforated 2”ø distribution pipe (HomeBiogas 2.0 - 1m / 4.0 - 2m / 7.0 - 3m). Drill two rows of holes in a 60-degree arc, at roughly 15cm intervals along the 2” pipe.
Page 18 1. Measure and prepare piping of the correct length required to connect the system’s fertilizer outlet to the mulch basin location. 2. Prepare perforated 2”ø distribution pipe (HomeBiogas 2.0 - 1.5m / 4.0 - 3m / 7.0 - 4.5m). Drill two rows of holes in a 60-degree arc, at roughly 15cm intervals along the 2” pipe.
Page 19: Using The Toilet
DO NOT exceed the recommended daily feeding amounts or the system will be unable to properly digest the waste. HomeBiogas 2.0 - 6 liters + 25 flushes / 4.0 - 12l + 50 flushes / 7.0 - 18l + 75 flushes...
Page 20: Maintenance
maintenance Regular cleaning Clean the toilet bowl with all-natural cleaners or vinegar. Avoid chemical cleaners such as bleach or Clorox as these will kill the bacteria in the system. Do not use abrasive pads on any part of the toilet. Clean with a dry cloth only Regular maintenance Lightly lubricate the piston metal rod of the bio toilet pump with the silicone...
Page 21: Troubleshooting
troubleshooting • Fit vented loops Bowl fills when toilet not in use • Check bottom valve (16) and joker valve (33) Wastewater re-appears in bowl • Fully shut flush control lever Bowl does not empty & difficult to push handle • Check joker valve (33) or discharge hose for blockage down • Remove pump and check for blockage...
Page 22 Bowl Regular 29096-1000 Top Valve Seat Seat & Cover 58104-1000 Hinge Set 58105-1000 Top Valve Gasket 29042-0000 Hose Regular Toilet 29035-1001 O-Ring (Flush Lever) – Intake Seal 58107-1000 Flush Control Lever – Intake Elbow 58107-1000 Screw (Flush Lever) – Base, Plug + O-Ring Assy 29041-1000 Buffer –...
Page 23: Warranty
WARRANTY HOMEBIOGAS LIMITED WARRANTY WARRANTS THIS PRODUCT TO BE FREE OF DEFECTS AND WORKMANSHIP FOR A PERIOD OF 1 YEAR. THE WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER EXPRESS OR IMPLIED WARRANTIES, GUARANTEES, CONDITIONS OR TERMS OF WHATEVER NATURE RELATING TO THE GOODS PROVIDED HEREUNDER, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY EXPRESSLY DISCLAIMED AND EXCLUDED.
