Summary of Contents for Adhesive Dispensing 12oz
- Page 1 12oz Size Barrel Filler USER GUIDE...
- Page 2 The 900-120 is built to accept all 12oz (360cc) cartridges. You can use pre-filled 12oz supplied cartridges or empty cartridges from us. This user...
-
Page 3: Table Of Contents
We strive to develop strong partnerships by delivering cost effective solutions that provide savings in assembly time and raw materials. So your confidence and trust in Adhesive Dispensing Ltd is of the utmost importance to us. Meets applicable CE requirements. -
Page 4: Specifications
Specifications Capacity: 360cc, 360ml (12oz) Initiation: Pneumatic Dispenser Air Input: 0 to 100psi (0 to 6.9 bar) Pressure Vessel: Anodised Aluminium Pressure Cap: Cast Aluminium Base Stand: Steel and Stainless Steel Rod Weight: 1.2kg (without filled cartridge) -
Page 5: First Steps
First Steps Step 1: Unpack the shipping box and use the supplied checklist to make sure all items are present. If any items are missing, please contact us immediately. Step 2: Ensure the area where you are setting up the equipment has access to compressed air. -
Page 6: Setup
Locate the reservoir pressure chamber and remove the cap (5) by turning counter clockwise. Insert a 12oz size cartridge reservoir that is pre-filled with your assembly fluid, in the retainer (7) . Remove the storage cap from the large end of the cartridge. - Page 7 Typical Setup This system is designed to work with a manual or timed dispenser for ON/ OFF control. Fittings are supplied to connect to most dispensers.
-
Page 8: Reservoir Filling
Syringe Filling Pressurise the reservoir pressure chamber (15) by turning the knob on your air dispenser pressure regulator clockwise. Adjust to a pressure that is appropriate to the fluid you are filling. Some common settings are as follows: 5psi for low viscosity fluids 80psi for high viscosity fluids. - Page 9 Retainer cap gasket is Buna. Size Clear Opaque Quan ty Size Part # Amber Black Per Pack 12oz TS120C –KIT 903-NW 903-DW 903-BW 905-NW 905-DW 905-BW 10cc 910-NW 910-DW 910-BW 30cc...
-
Page 10: Component Selection Guide
Dispense Component Selection Guide Cartridge Reservoir Each cartridge system comes with an air cap and retainer Part # Part Size 918-032-000 Retainer 12oz 16-3/4” 1-3/4” 918-001-004 12oz Part of above dimensions Accessories Each cartridge system comes with an air cap and retainer... -
Page 11: Troubleshooting
Troubleshooting Problem Possible Solution No Fluid Flow Check that air supply is properly connected. Check air in from mains supply and air feed from dispenser to syringe filling system. Air pressure is too low. Gradually increase the air pressure until fluid flows. Air Pressure Leaking Check all connections to make sure they are secure. -
Page 12: Warranty
Warranty One Year Limited Warranty Adhesive Dispensing Ltd (ADL) warrants its product to be free from defects in materials and workmanship for a period of one year from the date of purchase. Under this warranty, ADL will repair or replace any defec ve part or, at its own op on, the complete value regardless of fault.
