PRODUCT NO.
BASE MODEL NO.
FFC18C8CB0
FFC18C8CB
MARKET
North America
WIRING DIAGRAM - # 216801000
OWNER'S GUIDE - # 216802800 / ENERGY GUIDE - # 216794306
SERVICE DATA SHEET - # 216801000
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
134A
black
Publication No.
5995393252
030728
-EN/SERVICE /MLR
365
FREEZER
VOLTS
115
CHEST FREEZER
Base Model:
FFC18C8CB
©2003 Electrolux Home Products, Inc.
All rights reserved

Advertisement

loading

Related Manuals for Frigidaire FFC18C8CB

Summary of Contents for Frigidaire FFC18C8CB

  • Page 1 PRODUCT NO. BASE MODEL NO. FFC18C8CB0 FFC18C8CB MARKET North America WIRING DIAGRAM - # 216801000 OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216794306 SERVICE DATA SHEET - # 216801000 ELECTROLUX HOME PRODUCTS, INC. P.O BOX 212378, AUGUSTA , GA 30917...
  • Page 2 Publication No FFC18C8CB0 5995393252 DOOR 07/03...
  • Page 3 POS. NO 47 # 79 # # = Fast-moving Parts * = Non-Illustrated Parts FFC18C8CB0 DOOR PART NO DESCRIPTION 216481304 Gasket-door,black 5303925107 Lock Assy 216702900 Key,lock 216893202 Panel-inner door\lid,white 216141100 Plug-foam hole,black 216130021 Panel-outer door\lid,black 216822900 Switch,light/lamp ,ramp 216846400 Light Bulb/Lamp 216817600 Socket,light/lamp ,25 W 216897601...
  • Page 4 Publication No FFC18C8CB0 5995393252 CABINET 07/03...
  • Page 5 POS. NO 21 # # = Fast-moving Parts * = Non-Illustrated Parts FFC18C8CB0 CABINET PART NO DESCRIPTION 216909801 Catch-lock,black 216818900 Support,lock catch clip 216502600 Plug,drain ,interior 216073906 Plug-drain,black ,exterior 216111105 Breaker,black ,hinge side 216111705 Breaker-lock side,black 216110805 Breaker,black ,ends 216873600 Knob-control 216844500 Control-temperature...
  • Page 6 Publication No FFC18C8CB0 5995393252 SYSTEM 07/03...
  • Page 7 POS. NO 29 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FFC18C8CB0 SYSTEM PART NO DESCRIPTION 5303280307 Condenser 216634500 Drier-filter 216890300 Harness-main 216890200 Harness,low voltage- ,w/thermistor 216056400 Clip,compressor mtg ,SPRING 5308002681 Grommet,compressor 5303212615 Support,compressor 216784500 Compressor,w/o electricals 216649300 Controller-regulator LP 216649100...
