Frigidaire FFC13M2AW2 Factory Parts Catalog page 7

134a series
Hide thumbs
1
2
3
4
5
6
7

Advertisement

POS. NO
1
4
5 #
22
27
28
29 #
30
32
42
43A
47
55 #
86
# = Fast-moving Parts
* = Non-Illustrated Parts
FFC13M2AW2
SYSTEM
PART NO
DESCRIPTION
5303925238
Condenser
216634500
Drier-filter
216792300
Harness-main
216056400
Clip,compressor mtg ,SPRING
5308002681
Grommet,compressor
5303212615
Support,compressor
216856700
Compressor,w/o electricals
216649319
Controller
216694500
Clip,controller
216232700
Washer,flat ,1"OD x 0.531"ID
5303212614
Clip,harness mount
216629600
Screw,hex washer head ,10-16 x 0.500 ,tapping
218909901
Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
216036600
Screw,ph washer head ,8-32CA x 0.500 ,thread forming
7
Publication No.
5995379582
10/02
