- Page 1 OPERATOR’S MANUAL Quick-Tach Adapters Models MQTP, MQTP-GLOBAL, MQTP-CHALM- ERS-500, MQTP-MASSEY/AGCO, MQTP-TV140 Serial Number 13105- Manual# 96412 JULY 2021 ENGLISH COPYRIGHT © 2021 MESSER REPAIR AND FABRICATING, LLC SAUK CENTRE, MN PRINTED IN USA ALL RIGHTS RESERVED...
-
Page 2: Using This Manual
Introduction Using This Manual Your tractor loader operator’s manual contains instructions to safely operate the tractor loader. Anyone who operates a tractor loader with this attachment installed must first read, understand and follow the instruc- tions in the tractor loader operator’s manual. This manual contains instructions to safely operate and service the attachment. -
Page 3: Manufacturer Contact
Introduction continue or change specifications, models or design without notice and without incurring obligation. Loader Compatibility Confirm your tractor loader’s Rated Operating Capacity (ROC) in the tractor loader operator’s manual. Confirm your attachment’s ROC in SPECIFICATIONS in this manual. Do not install the attachment on the tractor loader if the combined weight of the attachment and attachment load will exceed the tractor loader ROC during operation because this may cause difficulty in controlling the trac- tor loader or may cause tractor loader damage. - Page 4 Product Identification Identification Numbers Record your product information to provide when you contact the dealer or manufacturer. Quick-Tach Adapters MQTP, MQTP-GLOBAL, MQTP-CHALMERS-500, MQTP-MASSEY/AGCO, MQTP-TV140 Serial Number 13105- Serial Number Location Purchase Date Dealer Dealer Phone Model Serial #...
-
Page 5: Specifications
Specifications MQTP Model Length x Width x Height 112 x 46 x 10 cm (44 x 18 x 4 in.) Weight 45 kg (100 lbs.) Rated Operating Capacity 2268 kg (5000 lbs.) MQTP-GLOBAL Model Length x Width x Height 114 x 53 x 15 cm (45 x 21 x 6 in.) Weight 57 kg (126 lbs.) - Page 6 Safety Wear Protective Equipment • Wear gloves to protect hands from burns if hydraulic couplers be- come hot during operation. • Never wear sandals or other light footwear when operating or servic- ing the attachment. Wear protective footwear when handling blades or heavy parts.
- Page 7 Safety technician. • Before raising or lowering the attachment be sure the area is clear of bystanders. • Do not operate the tractor loader or the attachment if you are under the influence of alcohol, drugs, or medications which may cause drowsiness.
-
Page 8: Safety Decals
Safety hydraulic hoses from the tractor loader. • Always securely block the attachment to prevent accidental release of the lifting mechanism when inspecting or servicing the attach- ment. Hydraulic Fluid Safety • Read and understand the hydraulic safety information in the tractor loader operator’s manual before operating or servicing the attach- ment. - Page 9 Installing and Removing Installing the Quick-Tach Adapter on the Tractor Loader Picture Note: For easier installation on some loader models you may need to tilt the Adapter at an angle as shown. IMPORTANT AVOID DAMAGE! The wedge pins in the Adapter may be damaged if they are extended during installation.
-
Page 10: Installing And Removing
Installing and Removing Installing on Tractor Loader ( Model MQTP, MQTP-GLOBAL) 1. Follow the instructions in the tractor loader operator’s manual to install the attachment and exit the operator station safely. 2. Follow the instructions to attach the tractor loader to the Adapter at the attaching points (A). - Page 11 Installing and Removing Installing on Tractor Loader (Model MQTP-MASSEY/AGCO) 1. Follow the instructions in the tractor loader operator’s manual to install the attachment and exit the operator station safely. 2. Follow the instructions to attach the tractor loader to the Adapter at the attaching points (A).
- Page 12 Installing and Removing Attaching Quick-Tach Adapter on Tractor Loader to Skid Steer Attachment (All Models) 1. Move the wedge levers (A) to the unlocked (up) position. 2. Tilt the Adapter forward, and drive the tractor forward until the top edge of the Adapter attaching plate is under the top flange (B) of the skid steer attachment.
- Page 13 Installing and Removing 5. Move the Adapter wedge levers (A) to the locked (down) position. 6. Follow the instructions in the tractor operator’s manual to park the tractor and exit the operator station safely. IMPORTANT AVOID DAMAGE! The skid steer attachment may come off the Adapter if it is not secured to the attaching plate.
- Page 14 Installing and Removing 7. Check to be sure the Adapter wedge pins (C) extended into the holes in the bottom of the skid steer attachment mounting frame. If not, move the Adapter wedge levers to the unlocked (up) position and repeat installation.
- Page 15 Installing and Removing 1. Follow the instructions in the tractor loader operator’s manual to remove the attachment and exit the operator station safely. 2. Fully lower the tractor loader arms and the attachment to level ground. Removing from Tractor Loader ( Model MQTP, MQTP-GLOBAL) 1.
- Page 16 Installing and Removing Removing from Tractor Loader (Model MQTP-MASSEY/AGCO) 1. Follow the instructions in the tractor loader operator’s manual to remove the attachment and exit the operator station safely. 2. Follow the instructions to remove the tractor loader from the Adapter at the attaching points (A).
-
Page 17: Theory Of Operation
Operating Pre-Operation Inspection Before starting operation, inspect the area you will be operating in and inspect the attachment. Inspect the Work Area 1. Confirm the area is clear of bystanders including animals. Establish a safety zone by keeping bystanders and animals beyond a 100 foot radius around the attachment when operating. -
Page 18: Transporting The Attachment
Operating 2. Follow the instructions in the tractor operator’s manual to park the tractor and exit the operator station safely. 3. Perform the pre-operation inspection. 4. Follow the instructions in your skid steer attachment operator manual to operate the attachment. Transporting the Attachment On the Loader Check to be sure the attachment is correctly installed on the tractor load-... -
Page 19: Service Intervals
Servicing Service Intervals Every 8 hours or daily: • Grease the wedge pins. • Inspect the attachment for damage and wear. Replace parts as need- • Check and tighten all hardware. Lubrication Recommended Grease Standard Lithium Lubricating the Wedge Pins 1. - Page 20 Replacement Parts Model MQTP...
-
Page 21: Replacement Parts
Replacement Parts Replacement Parts Contact Messer Repair and Fabricating, LLC for replacement parts. Part numbers may change without notice. Item Qty. Part Number Part Description 11160 Body Weldment 11504 MIR Wedge Lever, Right 11504 Wedge Lever, Left Shoulder Bolt, 5/8 - 11 x 5/8 Disc Spring, 3/4 x 1-1/2 OD Zinc Shoulder Bolt, 1/2 - 13 x 3 Flat Cap Bolt, 1/2 - 13 x 7/8... - Page 22 Replacement Parts Model MQTP-GLOBAL...
- Page 23 Replacement Parts Replacement Parts Contact Messer Repair and Fabricating, LLC for replacement parts. Part numbers may change without notice. Item Qty. Part Number Part Description 11644-P Body Weldment 11504 MIR Wedge Lever, Right 11504 Wedge Lever, Left Shoulder Bolt, 5/8 - 11 x 5/8 Disc Spring, 3/4 x 1-1/2 OD Zinc Shoulder Bolt, 1/2 - 13 x 3 Flat Cap Bolt, 1/2 - 13 x 7/8...
- Page 24 Replacement Parts Model MQTP-CHALMERS-500...
- Page 25 Replacement Parts Replacement Parts Contact Messer Repair and Fabricating, LLC for replacement parts. Part numbers may change without notice. Item Qty. Part Number Part Description 11883-P Body Weldment 11504 MIR Wedge Lever, Right 11504 Wedge Lever, Left Shoulder Bolt, 5/8 - 11 x 5/8 Disc Spring, 3/4 x 1-1/2 OD Zinc Shoulder Bolt, 1/2 - 13 x 3 Flat Cap Bolt, 1/2 - 13 x 7/8...
- Page 26 Replacement Parts Model MQTP-MASSEY/AGCO...
- Page 27 Replacement Parts Replacement Parts Contact Messer Repair and Fabricating, LLC for replacement parts. Part numbers may change without notice. Item Qty. Part Number Part Description 10946-P Body Weldment 11504 MIR Wedge Lever, Right 11504 Wedge Lever, Left Shoulder Bolt, 5/8 - 11 x 5/8 Disc Spring, 3/4 x 1-1/2 OD Zinc Shoulder Bolt, 1/2 - 13 x 3 Flat Cap Bolt, 1/2 - 13 x 7/8...
- Page 28 Replacement Parts Model MQTP-TV140...
- Page 29 Replacement Parts Replacement Parts Contact Messer Repair and Fabricating, LLC for replacement parts. Part numbers may change without notice. Item Qty. Part Number Part Description 09649-P Body Weldment 11504 MIR Wedge Lever, Right 11504 Wedge Lever, Left Shoulder Bolt, 5/8 - 11 x 5/8 Disc Spring, 3/4 x 1-1/2 OD Zinc Shoulder Bolt, 1/2 - 13 x 3 Flat Cap Bolt, 1/2 - 13 x 7/8...
-
Page 30: Warranty
Warranty MESSER REPAIR & FABRICATING, LLC Limited Warranty and Terms and Conditions of Sale The following limited warranty, and terms and conditions of sale (the “Limited Warranty”) apply to all equipment, products, parts, and goods (any of the forego- ing are referred to herein as “Equipment”) sold by Messer Repair & Fabricating, LLC (“Messer”): 1. - Page 31 Warranty 5. Location of Warranty Repairs. All warranty repairs pursuant to this Limited Warranty shall be made at Messer’s corporate manufacturing plant, or other loca- tion as determined by Messer, at its discretion. Purchaser shall be responsible for and pay for any transportation expenses necessary for Limited Warranty repairs. 6.
