Summary of Contents for KOKEN LM-066
Page 1
Model LM-066 Instruction Manual Thank you for purchasing the LM-066 Fetal Head Extractor for Obstetric Model. Please read this instruction manual carefully to ensure correct use of the product, and store it in a safe place for easy access. KOKEN CO., LTD.
Page 2
Handling and Safety Precautions These precautions should be strictly observed in order to ensure safe, long-term use of the product. In particular, the following precautions should be carefully observed: Ignoring the messages displayed with this icon, and handling the product improperly, may cause bodily injury or property damage.
1. Outline and Features Outline Fetal delivery simulations used to be done by hand, requiring a great deal of physical effort. As the number of conventional simulations increased, users could no longer deliver as intended. This Fetal Head Extractor reduces the fatigue brought on while pushing by hand, eliminates inconsistent operation, and enables the user to simulate stable crowning.
2. Components and Configuration Fetus support board Underarm placement pegs Handle Crank Obstetric assistant model main body support board Fetus support board lock knob Main body support clamp Main body support clamp arm...
3. Handling the Model 3-1 Remove the fetus support board Grasp the handle, use your other hand to pull out the lock knob, and then pull the handle towards you to remove the board.
Page 7
3-2 Attach an obstetric assistant model main body (1) As illustrated below, the setting position for the LM-016 obstetric assistant model main body differs from that of the LM-063 obstetric assistant model main body. Adjust the clamp arm accordingly to properly attach the main body type to be used. (The clamp arm of the main body slides easily in both directions.) [LM-063 Attachment position] [LM-063 Attachment position]...
Page 8
(2) Adjust the clamp arm to the appropriate attachment position, and then set the main body close to the clamp arm. (3) Tighten the clamp by hand to secure the main body to the board.
Page 9
3-3 Attaching the fetal model (1) Place the fetal model on the fetus support board so that its armpits are resting on the underarm placement pegs. Position the fetus model's armpits above the pegs as shown here. (2) Apply a generous amount of glycerin by hand to the head, shoulders, and body of the fetal model.
Page 10
3-4 Attach fetus support board to obstetric assistant model main body support board (1) Align the rails of the support boards of the fetal model and obstetric assistant model so that they fit comfortably together, then hold the handle and crank to slide the fetus support board forward.
Page 11
3-5 Simulate delivery Rotate the crank in a counterclockwise direction to simulate crowning. Once the head emerges as shown above, remove the fetus support board, and use your hands to manually deliver the fetus as done in previous simulations. To remove the fetus support board, use your right hand to pull out the lock knob, grasp the handle with your left hand, and...
4. Caring for the Model If glycerin residue remains on the fetus support board etc. during/after the simulation, dampen some gauze with water and wipe it clean. Do not wash the Fetal Head Extractor with water. * For proper care of the main bodies of fetal model and obstetric assistant model, refer to their respective instruction manuals.
